OPERATION GUIDE / START UP
WARNING: Always keep the marker powered OFF or on SAFE until you are ready to fire.
1. Always attach a barrel blocking device over the tip of the barrel for safety precautions when the marker is not in use.
2. Kingman recommends having the marker in the “SAFE” position before use. To operate, push the safety
button from the “PUSH SAFE” side of the trigger frame. This will position the marker in a lock safe mode. To
disengage the safety button in a safely manner, point the marker in a safe direction, and push the safety button
towards the “PUSH FIRE” side of the trigger frame.
3. Place the barrel plug or barrel blocking device over the barrel for safety precaution when the marker is not in use.
4. Attach the CO2 / Compressed air tank to the C/A Adapter. HELPFUL TIP: Make sure to have the CO2 /
Compressed air tank filled before attaching. Tighten the tank clockwise in the markers C/A Adapter until it is
snug. If an air leak occurs between the tank and the C/A Adapter, replace with a urethane bottle o-ring. NOTE:
O-rings in the markers parts kit are not supplied to attach with a CO2 / Compressed Air Tank. IMPORTANT:
You should never need to use any hand tool to attach a CO2 / Compressed Air Tank to the C/A Adapter.
5. Attach the elbow and a paintball loader to the markers feed neck. NOTE: Fill your paintball loader with only
.68 caliber paint.
6. Cocking the marker. Pull the Top Cocking Knob rearward until the Delrin Bolt latches. CAUTION: Should you
let go of the Top Cocking Knob before it latches, your marker may fire.
7. Remove barrel plug or barrel blocking device over the barrel.
8. CAUTION: With the safety button released in the FIRE position the marker is LIVE. By pulling the trigger
will fire a paintball. IMPORTANT: In a safe direction or in a designated playing field should you only test the
markers capability.
9. Performing a velocity (fps) check. Turning the Velocity Adjuster & Spring Guide clockwise will increase
the velocity (fps). Counter-clockwise will decrease the velocity (fps). NOTE: Your marker is intended to be
used in a paintball facility with the proper paintball protection. IMPORTANT: Kingman recommends using a
chronograph to ensure the marker’s Velocity is under 300 (fps).
10. Detach the paintball loader and all paintballs from the marker. When finished playing remove the paintball
loader and vertical elbow from the marker. CAUTION: There may be a paintball in the markers breach; take a
couple of shots in a safe direction to make sure the barrel and Receiver are empty.
11. Place the barrel plug or barrel blocking device over the barrel for safety precaution when the marker is not in
use. This will help avoid any accidental discharge.
12. Kingman recommends having the marker in the “SAFE” position after use.
13. Unscrew the CO2 / Compressed air tank from the markers C/A Adapter. By turning the tank counter-clockwise
will detach from the markers C/A Adapter. CAUTION: Never expose any skin underneath the C/A Adapters
bleed hole when removing the tank. This can run the risk of getting skin burn from the releasing of the GAS.
IMPORTANT: You should never need to use any hand tool to detach a CO2 / Compressed Air Tank.
14. Store the marker in a paintball bag or in a safe place. HELPFUL TIP: Before / after use of the marker, make
sure to fasten all Screws. Screws can become loss cause of vibration. It’s a good practice to lubricate your
marker before and after each use, especially when storing the marker for an extended period of time. Add a
few drops of paintball gun oil on the Striker O-ring (SEE DISSEMBLE / REASSEMBLE). Before storing the
marker, make sure to have the marker in the uncocked position. This way the main spring does not lose its
tension.
IMPORTANT
• Firing velocity may vary according to altitude and climate conditions.
• Before using your marker in play, you must always first perform a “SAFE VELOCITY TEST”. This can only be
accomplished by using a testing device called a “Velocity Chronograph” and can be performed at a paintball dealership
or a local playing field. NOTE: This product is intended to be used at a velocity no greater than 300 feet per second
(FPS). This product is NOT intended to be used at any distance less than 25 feet without EYE/FACE PROTECTION.
• This paintball marker may have excess gas after the removal of the CO2 / Compressed air tank. Please remove
all paintballs and discharge the remaining gas safely.
• Never store a CO2 / Compressed air tank attached on the marker while not supervised.
