1. INTRODUCTION
Thank you for choosing Squarell interfaces, which are used around the world in trucks, buses, vans
and personal vehicles to collect and analyze vehicle data and improve your fleet performance.
The REMOTE is the one box solution that combines a vehicle data interface with modem functionality.
The compact design houses everything you need to provide your customers with high quality vehicle
data, versatile connectivity and advanced Squarell solutions.
The Remote communicates over the LTE Cat-M network and has 2G fallback. The modem supports
TCP and MQTT communication protocols and you can extend the telematics device with solutions such
as Remote Tachograph Download, vehicle diagnostics (Advanced Tell Tales), driver coaching (Driver
Awareness Panel), Event Data Recorder (EDR) and more.
Thanks to its extensive communication protocols and expandable hardware and software, Squarell
offers you a versatile all-in-one telematics solution.
REMOTE benefits
•All-in-one telematics solution
•High quality data from every vehicle
•Expandable with advanced Squarell solutions
•Control and ownership of your data
•Patented data reader with flexible baud rate
•Plug-and-play installation
•Single point of contact: vehicle data + modem
•Application to configure, update and upgrade your solution
•Compact design, developed and assembled in the Netherlands
1.1 Glossary
RS-232
The Squarell interfaces provide more data than the standard FMS data. The interface has ASCII
output. With our configuration, a full functioning telematics interface can be created within hours.
CANcliQ
The Squarell CANcliQ reads CAN signals without making a wire-to-wire connection. The non-
intrusive technology guarantees that only data can be read from and not sent to the vehicle CAN Bus.
This avoids liability matters, warranty issues or possible wrong connections.
K-Line
When the vehicle has a Digital Tachograph, the Squarell device can be connected to the tachograph to
retrieve real-time tachograph data.
J1708
If a vehicle doesn’t have a CAN Bus, a J1708 DatacliQ can be connected directly to the vehicle J1708
bus. The diode function protects the vehicle J1708 bus from outside interference. The J1708 Interface
can be used to retrieve even more available vehicle data. So the FLEX can provide CAN Bus data and
J1708 data.
DatacliQ
The Squarell DatacliQ reads vehicle signals (CAN, J1708, ISO 11992) without making a wire-to-wire
connection. The non-intrusive technology guarantees that only data can be read from and not sent to
the vehicle CAN Bus. This avoids liability matters, warranty issues or possible wrong connections.
