SSV Works SS-B65 Manuale utente

SS-B65

Polaris Slingshot

Behind Seat 6.5” Speaker Pod

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030

www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751

!

Please read and understand these

instructions completely before

installation to avoid possible injury, or

damage to the accessory or vehicle.

WARRANTY INFORMATION:

All SSV Works enclosures are covered by a limited lifetime warranty against

defects in material or workmanship. All SSV Works Electronics are covered by

a limited 1 year warranty against defects in material or workmanship. All SSV

Works Speakers are covered by a limited 1 year warranty against defects in

material or workmanship. Labor for replacement of defective components is

not covered. Contact SSV Works for further warranty information.

TOOLS NEEDED FOR INSTALLATION

- T25 Torx driver - T40 Torx driver - 2.5mm Hex driver - 5/8” Drillbit

A. Use a T25 Torx driver to remove upper screws from the headrest

frame (2 places).

C. Use a 2.5mm hex driver to remove screws from the front of the

headrest pod (2 places).

B. Use a T40 Torx driver to Remove lower screws from the headrest

frame (4 places). Remove headrest frame.

D. Unscrew and remove gas cap and gas cap nut (driver side only).

A

C

B

D

G. Insert the rear tab of the speaker pod into the notch on the vehicle,

then lower into place

E. Remove the headrest by lifting from the front

H. Re-install gas cap nut (driver side only). Re-install gas cap (driver

side only). Re-install screws in the front of the speaker pod (2 places).

Re-install headrest frame.

F. Drill an opening for the speaker pod harness in location shown

SS-B65

G

E

H

F

© 2016 SSV Works, Oxnard, CA 93030 SS-B65 Rev. A 12-29-16

For proper sound, ensure the speaker polarity is correct connect the “+” to the “+” and the “-“to the “-“from the speaker wire to the amplier. If using

with an SSV Works complete system refer to the amplier wiring instructions for more detailed wiring information.

WIRING INSTRUCTIONS

“+”

“+”

“

-

”

“

-

”

Amplier
