Stack ST700 Manuale utente
200227-001
Quartz
kRPM
Model ST700 Dash
Display System
ST542059–001
1. Install the ST700 Dash Display System and connect it to
the switched battery circuit, for example the ignition (B+)
and the battery negative (B–).
2. Install and connect the controls (following the instruc-
tions that start on page 13).
3. Connect the ST700 Dash Display System ‘ES’ wire to the
ignition low tension circuit.
4. Connect the sensors supplied with your system.
5. Turn on the ignition.
6. Use the Demonstration Mode to check that the ST700
Dash Display System is functioning normally.
7. Take the ST700 Dash Display System out of its demon-
stration mode by changing the setting for the number of
cylinders. See page 53 for instructions.
8. Use the Driver button to select the display layers
described on page 32.
9. Use the Rotary control to select the Memory Review and
Setup modes as described on page 44.
10.Use the rotary control to set up the ST700 Dash Display
System.
QuickStart
ST700 Dash Display System Contents
© Stack 1
CONTENTS
CONTENTS 1
INTRODUCTION 3
How to use this manual 5
Safety Issues 6
Unpacking and Inspection 7
INSTALLATION 8
Product Installation 8
Wiring Harness 9
ST700 Dash Display System Display 12
Controls 13
Engine Speed Measurement 14
Lap Timing Sensor option 16
Trackside I.R. Beacon (optional) 18
Manual Lap Timing (optional) 20
Wheel Speed Sensor 21
Pressure Sensor options 23
Oil pressure switch 25
Temperature Sensor options 25
Battery connection 27
OPERATION 28
Switch functions 28
Contents ST700 Dash Display System
2
Power–on the ST700 Dash Display System 31
Changing the display layers 32
Lap and Split Times 37
Manual Split Timing Setup 39
Automatic Split Timing Setup 41
Hillclimb and Sprint Operation 42
MEMORY AND SETUP 43
Memory review features 44
Setup mode 47
TESTING 60
MAINTENANCE 62
Troubleshooting 62
Specification 72
Contact details 75
INDEX 79
ST700 Dash Display System Introduction
© Stack 3
INTRODUCTION
Thank you for selecting the ST700 Dash Display System from Stack as
your choice of vehicle's instrumentation—we feel sure that you are go-
ing to be delighted by your purchase!
The ST700 Dash Display System is a superb quality instrument that in-
tegrates a number of performance functions into a single display prod-
uct. The functions enabled on your unit are specific to your selection.
However, any ST700 Dash Display System can be upgraded to include
any combination of the available functions.
Functions on all ST700 Dash Display Systems:
❑Engine RPM—with maximum RPM telltale
❑Any two of pressure and temperature sensors
❑Vo l t m et e r g a u g e s
❑Vehicle speed (user–selectable MPH or km/h)
❑Peak value recall and intelligent alarm on all monitored engine
parameters
❑Adjustable backlighting intensity
❑Programmable sequential shift lights with four selectable patterns
and adjustable brightness
❑User– configurable setting to suit most vehicles
Introduction ST700 Dash Display System
4
Optional functions available:
❑Odometer and tripmeter (user–selectable Miles or Kilometres)
❑Lap and split–time memory
❑Corner and maximum straight speed read-out
❑User selectable acceleration and deceleration timer and ¼ mile time
❑Plug–in lap timing and data acquisition options
❑White or black dial face options offering a choice of RPM scales with
optimised ranges
The ST700 Dash Display System requires a connection to the vehicle
battery supply, the engine ignition system and the various sensors fitted
to the vehicle to provide the full range of measurements.
If your ST700 Dash Display System includes the option to trigger lap
times automatically, you will also require a vehicle–mounted infrared
(IR) sensor and a track–side IR beacon.
Refer to the following section of this user guide for instructions to install
the ST700 Dash Display System.
Depending on the model you have chosen, your ST700 Dash Display
System might not include some of the features described in this user
guide.
ST700 Dash Display System Introduction
© Stack 5
How to use this manual
This manual tells you how to:
Install the ST700 Dash Display System display instrument and its wiring
harness
Install and connect the standard and optional sensors on a vehicle
Configure the ST700 Dash Display System for your vehicle
Operate and read the ST700 Dash Display System during and after a
run
Throughout this manual, you will see the following symbol:
These are special or important notes and tips that you should read
and understand.
Introduction ST700 Dash Display System
6
Safety Issues
You must take note of the following safety advice when you install the
ST700 Dash Display System on your vehicle:
Follow the instructions to attach all components of the system se-
curely to the vehicle so that they do not vibrate loose and fall off.
The wiring harness supplied with the ST700 Dash Display System
is certified for use in high temperature applications up to 105°C
(221°F). Do not substitute wires that have a lower temperature rat-
ing than this. Contact Stack for advice if you are in any doubt.
Route all wires and the wiring harness so they do not snag against
any moving parts of the vehicle.
Do not apply sharp bends or other severe stresses to the wiring
harness.
Avoid positioning the sensors or their wires close to any sources
of intense heat or vibration or close to the leads of the ignition HT
or fuel injection systems.
Use cable clips to secure the wiring harness.
Use suitable glands or grommets to protect the wiring harness
where it passes through vehicle bulkheads or panels.
