MST660 Owner’s Manual Page 1
FEATURES
•Detachable face panel: Guards against theft by allowing you to remove
the face panel, rendering the stereo unusable. A carry case for the
detachable face panel is included.
•All Electronic Controls: The Bass, Treble, Volume, Balance and Fader
functions are all controlled by touch buttons for greater long term
reliability.
•8 Times Oversampling Digital Filter: Provides superb sound with high
data integrity.
•Anti-vibration/Anti-shock CD Mechanism: Ensures your music is not
disrupted by boat movement.
•Random, Repeat and Intro-scan Functions: Takes the effort out of
playing CDs or locating specific tracks on your CD.
•Audible Cue/Review: Helps you to advance or retrace a track at high
speed while monitoring it’s progress.
•Auto Loading: Simply insert the CD into the slot and the servo mechanism
takes over automatically.
•18 FM and 12 AM Pre-set Memories: Store up to 18 FM stations and 12
AM stations in memory for easy recall.
•Auto Pre-set Memory System: Automatically locates and stores local
stations into memory for you.
•Seek and Manual Tuning: Select stations yourself or let your radio find
them for you.
•Local/DX Switch: Adjusts your radio’s sensitivity for distant or local
reception when seeking or scanning.
•Preview Scan: Steps through your pre-set station memories, pausing
briefly on each to let you decide whether you wish to select that station.
•FM Stereo/Mono Switch: Lets you manually disable stereo operation for
improved reception in weak signal areas.
• Clock: Shows the time at the touch of a button.
•RCA outputs: Provides a separate low level output for connection to
external equalizer/booster-amplifier systems.
•Water Resistant Housing: Built into a special water resistant marine
housing made from corrosion-proof materials with a transparent
splash-resistant front cover.
•LCD Display: Easy to read under all lighting conditions with orange
backlighting for night time use.
MST660 I.M.-2 21/12/99 1:26 PM Page 3
PRECAUTIONS
•If you are connecting your MST660 for the first time or have just
reconnected your boat battery and you are experiencing problems with the
MST660’s operation, we suggest you try resetting the unit. The reset
button is located under the removable face panel (see page 5 for
instructions on removing and refitting the face panel). Simply press the
reset button with a ball point pen or similar. You can then refit the
face panel.
•Do not insert anything other than audio compact discs into the disc slot.
The CD mechanism contains precision laser equipment which could be
damaged by inserting foreign objects.
•The station memories and clock time are retained only while the red
‘Battery’ lead is connected (see Installation section). If the battery is
disconnected or switched off at the master switch, or if the unit is removed
from the vessel, the station memories will be lost and the clock will need to
be reset.
Handling Compact Discs
•Handle the CD by its edge. Avoid touching the disc’s surface.
•Store your CDs away from direct sunlight or heat sources. Keeping the CD
stored in its original case will help to keep it flat.
•Clean the CD with a soft cloth. Clean from the center to the outer edge (see
diagram) rather than in a circular motion. Do not use solvents.
Page 2 Owner’s Manual MST660
Reset
Button
Handling Cleaning
MST660 I.M.-2 21/12/99 1:26 PM Page 4
CONTROLS
1. SELect Button: Press to select the next available control. The options
available are Volume, Bass, Treble, Balance and Fader.
2. +Control Button: Increases the setting of the selected control (Volume,
Bass, Treble, Balance or Fader).
3. –Control Button: Decreases the setting of the selected control (Volume,
Bass, Treble, Balance or Fader).
4. Press BND to set the frequency band to FMI, FMII, FMIII, AMI or AMII.
5 & 6. TUNE Buttons.
•In Radio mode, the TUNE buttons are used to manually tune the radio to
the desired frequency. Press to tune lower in frequency and to tune
higher in frequency. Press and hold or for 1 second to automatically
tune to the next clear station.
•In CD Play mode, press to advance to the next track or to step
backwards to the previous track. Press and hold to retrace the current
track at high speed or to advance forward through the current track at
high speed. When advancing or retracing the current track, the music can
be heard playing at high speed in the speakers so that you can monitor it’s
progress.
Moisture Condensation
Your MST660 uses optical laser technology. Occasionally, damp or humid
conditions may cause condensation to appear on the lenses inside the unit.
Should this occur, the unit may not operate correctly. Simply eject the CD and
leave the unit turned on for a while until the moisture evaporates.
MST660 Owner’s Manual Page 3
EJ
8 Times Oversampling
+
–
SEL BND
REL
LOC MUT
AMS M/S
DSP
PWR
1SCN 2RPT 3RPT
A-B 6MEM
CLR
4RDM 5PGM
1
2
3
4 5
6
7815
17
910 11 12 14 16 13
18
19
20
21
22
23
LOC
CH
MST660 I.M.-2 21/12/99 1:26 PM Page 5
•In CD Program mode, press or to select a track number for
programming.
•In Clock setting mode, press to change the minutes and to change
the hours.
7. Press the SCN (Scan) button to play the first 10 seconds of each track on
the CD.
8. The RPT (Repeat) button causes the current track on the CD to be played
repeatedly.
9. The RPT A-B (Repeat Selection) button allows a selection of music on the
CD to be played repeatedly.
10. Press the RDM (Random) button to play all the tracks on the CD once in
random order.
11. Press PGM to play up to 24 tracks on a CD in preprogrammed order.
12. Press MEM/CLR to add or remove selected tracks from the
pre-programming memory. If added to memory, these tracks are then
played using the PGM button.
13. Buttons 1to 6are used to store and access preset station memories.
•To store a preset station in memory, select the required station, then press
and hold a preset memory button for 1 second.
•To recall a station from the preset memory, simply press a preset memory
button briefly.
14. When CD is playing, press the button to pause the CD. Press
again to resume normal play.
When radio is playing, press to return to a CD.
15. Press the AMS button to step through the stations in the preset
memories, pausing briefly on each station.
Press and hold the AMS button to automatically locate and store the
6 strongest local stations from the selected band into the preset station
memories.
16. Press the PWR button to turn the MST660 ON or OFF.
17. Press the M/S button to select Mono or Stereo reception on the FM band.
18. Press the MUTE button to temporarily drop the output level to a very low
volume. Press the MUTE button again (or the volume +or – buttons) to
restore the output volume to normal levels
19. Press the button to stop CD play and eject the CD. The unit switches
to radio mode.
20. Press the LOC button to select between local and distant stations when
tuning.
21. Press the DSP (Display) button to display the clock on the LCD. The LCD
Page 4 Owner’s Manual MST660
MST660 I.M.-2 21/12/99 1:26 PM Page 6
REMOVAL AND FITTING THE FACE PANEL
Removal
Before removing the face panel, turn the unit OFF by pressing the PWR
button.
1. Press the release button to release the left-hand end of the
face panel.
2. Lift the front panel out towards you.
After removing the face panel, place it inside the supplied case to protect it
from damage. Do not leave it in a position where it could be exposed to direct
sunlight.
Refitting
1. Make sure the face panel is the right way up as it cannot be attached
upside down.
2. Fit the right-hand end of the face panel into the tabs inside the right-hand
end of the unit.
3. Gently press the left-hand end of the face panel into place until it clicks.
Only light pressure is required.
MST660 Owner’s Manual Page 5
automatically reverts back to the previous display after 5 seconds.
Press and hold the DSP (Display) button for 2 seconds to enter the clock
setting mode.
22. Insert the CD into this slot with the label facing upwards.
23. Press REL button to unlock face panel for removal.
Release
Button
MST660 I.M.-2 21/12/99 1:26 PM Page 7
Page 6 Owner’s Manual MST660
INSTALLATION
Location
The MST660 is designed to be mounted in several different ways to enable it
to be installed in the most convenient position. Although the unit is water
resistant when the front cover is closed, care should be taken to locate it
where it will not be subjected to spray or rain. The unit should be mounted
with an angle of less than 20° to the horizontal plane (see diagram) and in a
position that is free from direct sunlight and excessive vibration.
Upright or Overhead Mounting
1. Attach the two gimbal knobs and the self-adhesive rubber washers to the
MST660 and slide the unit into the mounting bracket. Ensure the rubber
washers are between the bracket and the CD player’s case. Tighten the
knobs firmly.
2. Temporarily position the MST660 in the desired location and roughly mark
the location of the bracket edges. Now, remove the unit from the bracket
and reposition the bracket to mark the mounting hole positions. A range of
mounting holes is provided to suit most installations.
3. Screw or bolt the bracket into position. The mounting method will depend
on the material to which the bracket is being attached.
4. Slide the MST660 back into the bracket slots and adjust for the correct
position before tightening the gimbal knobs. Remember to avoid
exceeding the maximum mounting angle of 20°.
5. Complete the antenna lead and electrical wiring as described later.
20˚
20˚
20˚
20˚
Flush Mount
Overhead Mount
Upright Mount
✔
✔
✔
✘
MST660 I.M.-2 21/12/99 1:26 PM Page 8
MST660 Owner’s Manual Page 7
Flush Mounting
The MST660 can be neatly flush mounted into a panel or bulkhead so that just
the controls and the protective cover are visible. There are two flush mounting
options available. The best option for you will depend on your particular
situation.
•If the space behind the bulkhead or panel you have selected has a suitable
support shelf and the area is fully accessible, you can use the supplied
escutcheon panel as described later.
•If the space behind the bulkhead or panel is largely inaccessible or there is
no additional support shelf, we recommend you use the optional CMB60
flush mounting kit (available as an accessory). This kit is more robust, is
fully self supporting and allows the MST660 to be installed from the front.
Installation using the supplied Escutcheon Panel.
1. Select a suitable location on a panel or bulkhead. Examine behind the
bulkhead to determine the best method of support for the CD player.
2. Place the escutcheon on the panel or bulkhead in the required position
and mark around the outside edge of the escutcheon slot wall.
3. Remove the escutcheon and measure the marks. They should measure
approximately 7.87'' wide and 2.76'' high. If not, check the diagram above
to ensure that you measured the correct edge.
Escutcheon
IMPORTANT DRAW
AROUND THIS EDGE
2.76"
7.87"
Using the Optional Flush Mounting Kit
MST660 I.M.-2 21/12/99 1:26 PM Page 9
Page 8 Owner’s Manual MST660
4. If your measurements are correct, carefully cut the slot around the marked
lines, ensuring that you maintain the curves in each corner. Mark and drill
the four 0.08'' holes in the bulkhead to accept the locating pins at each
corner of the escutcheon.
5. Trial fit the escutcheon to ensure it fits securely against the panel. If all is
well, place a small dab of glue on each locating pin and press the
escutcheon into place. Temporarily hold with tape if necessary.
6. With the escutcheon firmly glued in place, slide the MST660 through the
slot from the front and push it all the way in, while leaving a clearance for
the front cover to hang in the open position. Open the cover if necessary
to ensure the correct clearance.
7. Holding everything in position, mark the location of the internal support
bracket(s). Drill the required holes and fit the bracket(s) as required to hold
the MST660 firmly in place.
Note: If using the perforated metal support strip, mount it to the rear of the
MST660 as shown in the diagram below.
8. Complete the antenna lead, speaker and power wiring as described later.
ELECTRICAL WIRING
DC Connections
Caution: The MST660 is designed for vessels with a 12 Volt negative ground
electrical system only!
OR
Perforated Strip Escutcheon
Mounting Bracket
Bolt
Washers
MST660 I.M.-2 21/12/99 1:26 PM Page 10
Indice
