Standard Horizon QUANTUM GX2360S Manuale

GX2360SPage 60

9.3 PA/FOG OPERATION

When the RAM+ is connected to the QUANTUM it is capable of controlling the

30W Public address, 4 fog horns, bells, and whistles.

9.3.1 Operating the PA / Hailer

1. Press and hold the [NAV]key then select PA with the []or

[]key.

2. Press the [CALL/SET]key.

3. Press the PTT switch and speak into the microphone.

4. To turn up the PA Volume, press the PTT switch and press

the []or []keys to adjust the Audio output level. The

level can be set from 0 to 30W.

5. To adjust the listen back volume, (while in listenback mode)

press the [VOL]Key, then press the []or []key to the

desired listen back volume.

To exit from the PA Hailer mode, press the [CALL/SET], [16/9],

or [WX]key.

9.3.2 Operating the FOG Horn

The QUANTUM is capable of sending 4 pre-programmed fog signals and also

Horn, Siren, Aground and Anchor signals.

FOG 1: POWER BOAT UNDERWAY

FOG 2: POWER BOAT STOPPED

FOG 3: SAIL BOAT, FISH VESSEL, TOW VESSEL

FOG 4: VESSEL UNDER TOW

1. Press and hold the [NAV]key then select FOG with the []

or []key.

2. Press the [CALL/SET]key.

3. Select the one of the eight functions described above with

the []or []key and press the [CALL/SET]key.

4. On the “Horn” and “Siren” modes, press the PTT switch to

activate the tone through the HAIL/PA speaker.

Press the []or []keys to adjust the Audio output level.

The level can be set from 0 to 30W.

5. To adjust the listen back volume, (while in listenback mode)

press the [VOL]Key, then press the []or []key to the

desired listen back volume.

To exit from the FOG or other signaling mode, press the [16/9],

[WX], or [CALL/SET]key.
