Security Pole

Assembly Instructions:

FIGURE 1

NOTE: The Security Pole is designed to be used with

ceiling heights that range from 7 to 10 foot ceilings.

Determine where you plan to use this product and

the height of the ceiling before continuing the assembly

process.

1. Take all parts out of the box and lay them on a flat

surface as shown in Figure 1.

2. If you have a 7 foot ceiling, do not use Extension Tube

(ITEM-2). Attach the Upper Frame (ITEM-1) directly to

ITEM-3 by aligning the holes in ITEM-1 and ITEM-3 and

inserting the Clevis Pin (ITEM-6) through the holes.

After the Clevis Pin is inserted, place the Cotter Pin

(ITEM-7) through the hole of the Clevis Pin and bend the

end of the Cotter Pin to secure the Clevis Pin as shown

in Figure 2.

3. If you have an 8 to 10 foot ceiling, attach the Upper

Frame (ITEM-1) to the Extension Tube (ITEM-2) by

aligning the holes and inserting the Clevis Pin and Cotter

Pin as shown in Figure 2.

4. The Extension Tube (ITEM-2) has 2 sets of holes

marked “A” and “B” in Figure 1. The set of holes marked

“A” are for an 8 foot ceiling. The set of holes marked “B”

are for a 9 or 10 foot ceiling.

FIGURE 2

5. Attach the Extension Tube (ITEM-2) to (ITEM-3) by

aligning the appropriate ceiling height set of holes,

marked “A” or “B” of (ITEM-2) with the mating holes in

the Upper Tube (ITEM-3) and inserting the Clevis Pin

and Cotter Pin as previously done in Step 2.

6. Attach ITEM-5 to ITEM-4, as shown in Figure 1, by

aligning the slots in ITEM-4 with the internal pin in ITEM-5

so the slots straddle the internal pin to prevent rotation

between ITEM-5 and ITEM-4, and as shown in Figure 3.

FIGURE 3

7. Insert the threaded portion of ITEM-3 into ITEM-4 and

place the Safety Pole in the desired location with ITEM-5

on the floor and ITEM-1 on the ceiling.

NOTE: Make sure the Plastic Washer (ITEM-11) is placed

between the Adjustment Nut (ITEM-8) and the Washer

(ITEM-9) as shown in Figure 1 before inserting ITEM-3 into

ITEM-4.

8. Secure the Safety Pole between the floor and the ceiling,

the Adjustment Nut (ITEM-8) must be tightened in a

clockwise direction with the included wrench (Item not

shown). Tighten the lower Adjustment Nut until the Safety

Pole is secured between the floor and the ceiling.

NOTES:

If the Safety Pole does not appear to be securely fastened

between the floor and ceiling, loosen the Adjustment Nut

(ITEM-8) and make sure the length of the Safety Pole is

perpendicular to the floor and ceiling before tightening the

Adjustment Nut (ITEM-8) again as previously done in Step

8. If additional securing is needed, two Wood Screws

(ITEM-10) can be installed into the ceiling joists as shown

in Figure 4 and two screws can be installed through the

Base Foot (ITEM-5) into the floor.

Slight movement of the pivoting handle is normal and safe.

This movement allows the locking pin to easily lock into 8

user friendly positions. Pull the pin and rotate the curved

handle. Release the handle and continue to rotate the

curved handle until the spring loaded pin locks the handle

into the desired position.

FIGURE 4

WARNING: Please read before

using this product.

1. Serious injury or death can result if the Safety Pole is

not properly installed. Standers Inc. is committed to

providing safe products and informing the user of

ways to prevent accidents.

SAFETY PRECAUTIONS:

Regularly check the Security Pole to make

sure the pole is tightly secured between the

floor and ceiling.

Make sure the Security Pole axis is installed

at 90 degrees relative to the floor. All

protective rubber pads must be in contact with

the floor and the ceiling.

Additional safety measures should be taken

for users that are a high risk. High risk users

include those who are not mentally conscious

(including those individuals under

medication), users who have size or weight

conditions, or any condition that impair their

ability to use the Security Pole without

assistance.

The Security Pole uses a spring loaded pin

that allows the handle to rotate and lock into

several user positions. Make sure that the

rotating handle is in a locked position before

using the product. If the rotating handle is not

locked before using, the user may fall and

serious injury or harm could result.

If you have any concerns or questions

regarding these precautions, please contact

Standers at 1-800-506-9901.

2. If you are suffering from an ailment or injury or are

taking medications that affect your balance or ability

to stand or sit down, you should first consult with a

physician before using this product. If the product is

not used properly, serious injury or harm could result.

3. The product was not intended to carry the full weight

of an individual. This product is only intended to

provide balance and support while sitting and

standing.

4. The product instructions must be carefully followed to

ensure that the product is properly assembled and

positioned. Failure to follow the instructions could

result in serious injury to the user(s) of the product.

5. Children should not be allowed to hang on or play

with the product.

6. DISCLAIMER: Neither Standers, Inc. nor the

manufacture is liable for any harm or injury that may

result or has resulted from the improper use or

assembly of the product.

Limited Warranty

Congratulations on your purchase of your Standers

brand product. We hope that it will ease your daily living.

Please read the following warranty statement for your

protection.

Standers, Inc. warrants to the original purchaser that

this product will be free from defects in material and/or

workmanship for 1 year from the date of purchase.

During the warranty period, Standers, Inc. will correct

any defects in material or workmanship, at no charge.

The original purchaser, however, must prepay shipping

cost. Any replacement parts will be new and are

warranted for the remainder of the original warranty or

thirty (30) days from the date of shipment, whichever is

longer. The original purchaser must notify Standers, Inc.

during the warranty period in writing of the defect in

workmanship or material. This warranty is not

transferable and covers only normal use. NO SHIPPING

CHARGES ARE REFUNDABLE.

The warranty does NOT cover the following:

Damage during shipment other than original

shipment to retailer.

Damage caused by unauthorized attachments,

alterations, or modifications.

Damage caused by the use of the product for

purposes other than those for which the product

was designed or intended.

Damage caused by any other abuse, misuse,

mishandling or misapplication.

Under no circumstances shall Standers, Inc. be liable

for any special, incidental, or consequential damages

based upon breach of this limited warranty, breach of

contract, or strict liability.

THERE ARE NO WARRANTIES WHICH EXTEND BEYOND

THE DESCRIPTION ON THEFACE HEREOF. ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL

IMPLIED WARRANTIES OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE), ARE HEREBY

DISCLAIMED.

Some states do not allow limitations on how long

an implied warranty lasts, so the above limitation may not

apply to you. This warranty gives you specific legal right,

and you may also have other rights, which vary from

state to state.

To obtain service under this warranty, you can

reach Standers Inc. at 74 Canterbury Circle, Logan, Utah

84321.

Please read Safety Precautions and

Instructions before using this product.
