starlight FCF-02WH Manuale utente
1
USER MANUAL
Stove Oven
FCF-02WH
FCF-03WH
2
Please first read this manual!
Dear Customer, We desire you take the most advantage of this
product, which is produced in the modern facilities and subject
to meticulous control procedures. For this reason, please read
the entire manual carefully before you use the product and
keep the manual under hand for future reference. If you transfer
the product to anybody else, give the manual together with it.
User manual help you use the product quickly and reliably.
Read the user manual before you install and operate
the product.
Definitely comply with the instructions on safety.
Keep the user manual as easily accessible for future
use when required.
Read other documents given together with the product
as well.
Remember this user manual may also apply to the other
models.
Differences between the models are clearly indicated in the
manual.
3
Symbols and Description:
The following symbols take place in the user manual:
1-Important information and useful hinds on use
2-Warning against dangerous situations in terms of life and
property
3-Warning against fire risk
4-Warning against hot surfaces
4
Table of Contents
1) Your product 5
General Appearance 5
Technical Specifications 6
2) Important Safety Instructions 7
General Safety 7-8
Safety for children 9
Intended use 10
3) Installation 10
Prior to use of the product 10-11
Connections 11
Gas connection 11-12
Leakage control 13-14
Waste of the product
Destruction of the packaging 13
Future Transportation procedures 14
Disposal of the old product 14
4) Preliminary preparation 15
First use 15
First cleaning 15
Description of use of the stove 16
5) Maintenance and cleaning 17
General information 17-18
Cleaning of the control panel 18
5
1) Your Product
GENERAL APPEARANCE
A. Strong burner
B. Normal burner
C. Auxiliary burner
D. Upper grill
6
E. Body
F. Control switch
Technical Specifications
TECHNICAL SPECIFICATIONS OF THE PRODUCT
Specifications
G30
30mba
r
Inject
or
Single
Stove
Dual
Stove
Triple
Stove
Quartet
Stove
Quartet
Stove
Quartet
Stove
Quartet
Stove
Quartet Stove
Gas
Category
13B/
P
13B/P
13B/P
13B/P
13B/P
13B/P
13B/P
13B/P
13B/P
Strong
burner
Ø
0.65
1.85
kW
1.85
KW
1.85
kW
1.85 kW
1.85 kW
1.85 kW
1.85 kW
1.85 kW
Normal
burner
Ø
0.60
1.50
KW
1.50
KW
2x1.50KW
2x1.50KW
2x1.50KW
2x1.50KW
2x1.50KW
Auxiliary
Burner
Ø
0.50
1 KW
1 KW
1 KW
1 KW
1 KW
1 KW
Your stove is designed to operate by G30 29mbar (LPG) gas.
It is not possible to convert the stove to operate by
different gases.
Use 1.5 kg/300mm SS Pressure-reducing valve on your
stove as per TSE standards.
This product is designed to operate outdoors only.
Technical specifications may be changed without prior
advice in order to improve product.
Figures given in the manual are schematic and they may
not exactly match with your product.
The declared values on the markings of the products or
in other printed documents provided together with the product
are values obtained in laboratory as per the respective
standards. These values may vary depending on the use and
environment of the product.
7
1) Important safety instructions
This section contains safety instructions that may help
prevent risks of personal injury or property damage. If you fail
to observe these instructions, the warranty will become invalid.
General Safety
This product is not designed by any handicapped
people, mentally, physically and sensually or by any
people having no knowledge and experience (including
children) unless they are attended by a person that
may assume their safety or give directions for use of it.
The children will be supervised and they will never be
allowed playing with the product.
If venturies of your stove becomes clogged due to food
overflow, contact with the authorized service center
and have the eye of the stove unclogged.
If the product is damaged or has any visible defect, do
not operate the product.
Do not perform any repair or modification on the
product.
Do not use the product when your discernment is
impaired due to taking drugs and/or alcohol.
Always call authorized service center for installation
and repair operations. The manufacturing company
may not be kept responsible for any damage that may
arise as a result of operations by unauthorized persons
and the warranty will become invalid as a result of it.
Be careful when using alcohol in your food.
Alcohol evaporates at high temperature and when it
comes into contact with hot surfaces, it blazes up and
cause fire risk.
Do not heat the closed tin cans and glass jars.
Pressure to develop may cause burst of the jar.
8
Do not bring flammable materials near when the
product operates because its sides may be hot.
This equipment should be kept away from the
flammable materials.
The product may get hot when operating. Do
hot the hot departments, inner parts and heating parts
of the furnace.
The product and its parts accessible by hand
are hot when using.
The product may be hot after use of it. If you
have to touch it, wear heat-resistant gloves.
Do not move the stove when using it
Keep all ventilation channels unobstructed around
them.
After each use of the product, make sure the pressure-
reducing valve is closed..
Do not use sharp and piercing materials to clean inside
and glass of the product; such materials may give
damage to your product.
As hot oil may cause fire risk, always be alert when the
product operates.
In case of any possible fire, do not attempt to
extinguish the fire with water; immediately cut off the
power connection of the product and cover the burning
part by help of a wet blanket.
Do not use steam cleaning agent.
Do not product the product any nylon, flammable and
any materials not resistant to a
temperature of 100oC.
Pans to be placed on the furnace heaters should be in
proper sizes.
9
When you feel gas smell (leakage, close the pressure-
reducing valve immediately.
Safety for children
During and after operation of the product, the exposed parts of
the product will remain hat until it gets cool; keep the children
away from it.
CAUTION: During operation of the grill, the accessible
parts may be hot. Keep small children away from it.
It is risky that children below 8 years old to contact with
the product when they are not attended by an adult
person.
This product may be used by the children above 8
years old and/or by any physically, sensually or
mentally handicapped people if they are informed
about the risks and proper operation of the product is
shown to them.
Children should not play with the product. Cleaning
and maintenance of the product may not be performed
by the children not supervised by the adult people.
Packaging materials may be risky for the children.
Keep them at such places out of reach of the children
and sort them out according to the waste instructions
and dispose them.
