StarTech.com SLIMDVDRW8U2 Manuale utente

External USB 2.0 DVD-RW Drive

SLIMDVDRW8U2 Instruction Manual

Actual product may vary from photo

External Slim USB 2.0 8x DVD-RW Drive

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Instruction Manual

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Drive Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Instruction Manual

Thank for purchasing a StarTech.com External Slim USB 2.0 8x DVD-RW Drive. A

perfect notebook accessory, now, you can copy and transfer data for efficient backups,

without needing a built-in DVD-RW drive. The attractive, discreet casing of this device

blends perfectly with your laptop, and its thin, yet durable design fits handily into your

notebook carrying case for times when you are on the move.

IInnttrroodduuccttiioonn

Features

BBeeffoorreeYYoouuBBeeggiinn

•Slim 12.7mm height drive design

•Supports mini CDs

•Hot swappable plug and play installation

•No power adapter required

•Includes Nero 7 Essentials software

•Software requirements: Windows: 98SE, ME, 2000, XP, Vista.

MAC OS 10.4 or higher

System Requirements

•A PC or Mac computer with at least one available USB port. If no external power

supply is to be used, two USB ports must be available.

•External Slim USB 2.0 8x DVD-RW Drive

Package Contents

•USB 2.0 Cable

•Power Adapter

•Includes Nero 7 Essentials software

This package should contain:

•CD (W98SE Driver)

•User Manual

Instruction Manual

IInnssttaallllaattiioonn

Once the drive is powered and connected to the host computer, the necessary drivers

will need to be installed.

Front Panel Rear Panel

Eject/Load button

Emergency Eject pinhole

Read/Write indicator

Power port (optional)

USB ‘B’ Port

Windows 98/98SE

1. Connect the “B” type connector provided by the included USB cable into the USB ‘B’

slot located on the rear panel of SLIMDVDRW8U2.

If you have multiple USB ports available on the host computer,

connect both of

the remaining connectors on the USB cable to available USB ports on the host

computer.

If you only have one USB port available on the host computer,

you are required

to use the power adapter provided. Connect the remaining USB connector

(connector attached to the main cable directly) to the available USB port. Insert the

cylindrical metal connector provided by the included power adapter, into the power

port on the rear panel of the drive. Connect the remaining end of the power adapter

to an available power outlet.

Hardware Installation

Once the drive is powered and connected to the host computer, Windows will detect

the presence of the connected drive, and request the driver CD. Insert the included

Driver CD into the existing CD/DVD-ROM drive, and follow all prompts (i.e. Next, Finish)

to complete installation.

Software Installation

Instruction Manual

MAC OS 10.4 or higher

Once the drive is powered and connected to the host computer, Windows will detect the

presence of the connected drive and automatically install the necessary software. Follow

all prompts (i.e. Next, Finish) to complete installation.

Windows ME, 2000, XP, Vista

Once the drive is powered and connected to the host computer, the operating system

will detect the presence of the connected drive and automatically install the necessary

software.

Drive operation

Once installation has concluded, you will be able to use the DVDRW drive as though it

were installed within the computer. To insert a DVD/CD, press the Eject/Load button,

located on the front panel of the drive. This will open the tray for use. Close the drive by

pressing the button again.

Instruction Manual

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

SSppeecciiffiiccaattiioonnss

Regulatory Certifications

DVDRW Drive: UL, CE, TUV, CB, RoHS

Power Adapter: FCC, UL/cUL

Interface USB 2.0

Form Factor External Slim 5.25” Enclosure with DVD Drive Plastic enclosure

Connectors USB Type B Female

Power Adapter 5VDC, 2.0A

Buffer Memory 2MB

Error rate Soft Read Error (Less than 10-9 )

Hard Read Error (Less than 10-12 )

Operating Temperature 5 ~ 50° C

Storage Temperature -30 ~ 65° C

Relative Humidity Range Operating 5 ~ 90% (No condensation)

Storage 5 ~ 95% (No condensation)

Dimensions 165 x 135 x 23 mm (L x W x H), 6.5 x 5.3 x 0.9” (L x W x H)

Weight 350 g (12.34Oz)

Read capability 8X DVD-ROM, 24X CD-ROM, 8X CD+R, 4X CD+RW

Write capability 5X DVD-RAM, 8X DVD-R, 4X DVD-RW

24X DVD-R, 10X DVD-RW, 2X DVD–R DL, 2.4X DVD+R DL

Revised: 2 October 2007 (Rev. A)

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer

Parts”. Since 1985, we have been providing IT professionals with the

quality products they need to complete their solutions. We offer an

unmatched selection of computer parts, cables, server management

solutions and A/V products and serve a worldwide market through our

locations in the United States, Canada, the United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products

and to access exclusive interactive tools such as the Parts Finder and the

KVM Reference Guide. StarTech.com makes it easy to complete almost

any IT solution. Find out for yourself why our products lead the industry in

performance, support, and value.
