StarTech.com ATXPOW350PRO Manuale utente

ATXPOW350PRO

Reliable High-Performance

350 Watt ATX 12V Power Supply

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference in a residential installation. This equip-

ment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio com-

munications. However, there is no guarantee that interference will not occur in a particu-

lar installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an en-

dorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this doc-

ument, StarTech.com hereby acknowledges that all trademarks, registered trademarks,

service marks, and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

Instruction Manual

Table of Contents

Introduction ..................................................................... 1

Features ..................................................................................1

Installation....................................................................... 2

Speciﬁcations.................................................................. 3

Technical Support........................................................... 4

Warranty Information...................................................... 4

Instruction Manual

Introduction

Thank you for buying a StarTech.com 350-Watt heavy-duty power supply.

Guaranteed compatible with Pentium 4 (and below) processors, the high-

quality ATXPOW350PRO is a reliable way to ensure that optimum power

is delivered your computer’s demanding components. A dual ball-bearing

temperature-controlled fan adjusts its speed to maintain an optimum

operating environment for heat-sensitive components.

Features

•IdealforPentium3,Pentium4,andAMDAthlonprocessors

•Constructedfromthehighestqualitycomponentstoassurealonglife

•ProvidesextrapowercapacityforPCserverswithseveralharddrives

•Providestheextracurrentrequiredby1GHzandfasterCPUs

•Automaticallydetectstemperatureandadjustsfanspeedtomaintain

optimal performance

•UsessuperiorEMI/RFIpowerltrationsystemensuresystemcompo-

nents receive clean, stable power

Contents

This package should contain:

• 1xATXPOW350PROpowersupply

• 1xpowercord

WARNING! Computer parts can be severely damaged by static electricity.

Be sure that you are properly grounded before opening your computer

case. StarTech.com recommends that you wear an anti-static strap when

installing any computer component. If an anti-static strap is unavailable,

discharge yourself of any static electricity build-up by touching a large

grounded metal surface (such as the computer case) for several seconds.

Also make sure that your computer is turned off and unplugged before

attempting to open your computer case.

Instruction Manual

Installation

NOTE:Checkthepowersupplyvoltagebeforeinstallation.Itshouldbe

the same as your local power voltage (115V for North America and 230V

formostoftheEuropeancountries).Changethevoltagesettingifneces-

sary.

1.Makesurethatyourcomputeristurnedoffandunplugged.Removethe

power cord from your old power supply.

2. Remove the cover of your system (see your computer’s user manual

for details, if necessary).

3.Disconnectallthepowerconnectorsfromthemotherboardandthe

 peripheraldevicessuchasharddrives,oppydisks,etc.Makesure

there are no devices connected to the existing power supply.

4. Remove the existing power supply from your computer case and

replace it with the new StarTech.com power supply.

5. Connect the power connectors to your motherboard and peripheral

devices.

6. Close your computer case.

7. Connect the power cord to the StarTech.com power supply.

ATXPOW350DF Connectors

Instruction Manual

Specications

Dimensions 5.9 x 3.35 x 5.87 inches (150 x 85 x 149mm)

Output Power 350W

Fan Type Ball bearing

Connectors FCC,UL,CSA,CE,TUV,CB

Connectors 6x4-pin-LP4-female

2 x small-internal-power

1 x 20-pin-ATX-motherboard-adapter

1 x 4-pin extended ATX power 12V plug

MTBF 100,000 hrs. @ 25ºC

Safety Approvals FCC,UL,CSA,CE,TUV,CB

AC Input Voltage 115V ~ Current 8A

Voltage 230V ~ Current 4A

Frequency5-~60Hz

DC Output + 3.3V (30A)

+ 5V (40A)

+ 12V (18A)

-5V (1A)

-12V (1A)

+ 5V Standby (2.5A)

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commit-

ment to provide industry-leading solutions. If you ever need help with your

product, visit www.startech.com/support and access our comprehensive

selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a three year warranty.

In addition, StarTech.com warrants its products against defects in materi-

als and workmanship for the periods noted, following the initial date of

purchase.Duringthisperiod,theproductsmaybereturnedforrepair,

or replacement with equivalent products at our discretion. The warranty

covers parts and labor costs only. StarTech.com does not warrant its

products from defects or damages arising from misuse, abuse, alteration,

or normal wear and tear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSA

LLP (or their ofcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or

exclusions contained in this statement may not apply to you.

StarTech.com has been making “hard-to-nd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government, education

and industrial facilities to name just a few. We offer an unmatched

selection of computer parts, cables, A/V products, KVMand Serv-

erManagement solutions, serving a worldwide market through our

locationsintheUnitedStates,Canada,theUnitedKingdomand

Taiwan.

Visit www.startech.com today for complete information about all

our products and to access exclusive interactive tools such as the

CableFinder,PartsFinderandtheKVMReferenceGuide.
