Stoane Lighting inter-lux Pipien Manuale utente
IMPORTANT: All wiring connections must be made before switching on mains power.
IP66 Dust tight and protected against powerful jets of water.
SL Type S 2.85VF1.4W @ 500mA
Please retain these instructions for future reference
Installation and Maintenance Instructions
Pipien
410 381 1497 inter-lux.com answers@inter-lux.com
Inter-lux reserves the right to make technical changes without notice.
1
Electrical Supply
Installation must be carried out by a qualified electrician in
accordance with BS 7671:2008 Wiring Regulations.
230/240V AC 50/60Hz mains supply to a suitable SELV
LED Driver.
Site conditions: LED equipment is more susceptible to
static damage and over voltage than previous technology.
Before handling or connecting to the mains supply ensure
that all Stoane Lighting (SL) products are protected from
static discharge and that the mains supply is to regulation.
(230V +10 -6%)
Mains cables must be double insulated, strain relieved
and separated from E.L.V output cables.
This unit requires a constant current driver. 500mA Max.
Observe polarity:
Positive (+) is marked as RED.
Incorrect supply or reverse polarity can cause irreparable
damage.
All connections must be made before switching on mains.
If the supply is energised prior to making the connections
to the fitting then the resulting surge will damage the LED.
Multiple LEDs should be wired in series, refer to driver
instructions for minimum/maximum load.
The entire dimming control circuit source must be of SELV
insulation class.
Maintenance:
All lighting equipment is delicate and easily damaged
through misuse or inappropriate installation (mechanical
or electrical). Repairs and replacements may cause
delays and will be chargeable. Contact SL for support if
required.
All Stoane Lighting products are covered by a five year
Warranty and a 25 year Duty of Care. Products are
designed to be upgraded, adapted and refreshed using
our comprehensive ReNew service. For more information
on our ReNew service and for full Warranty terms and
conditions visit stoanelighting.com or contact us at the
address shown.
The light source contained in this luminaire shall only be
replaced by the manufacturer or his service agent or a
similar qualified person.
If the external flexible cord of this luminaire is damaged, it
shall be exclusively replaced by the manufacturer or his
service agent or similar qualified person in order to avoid
a hazard.
Installation
Check that the mounting surface is suitable for the
installation of this fitting.
Step 1 Make mains connections to SELV LED driver
and extra low voltage connections to the
fitting.
Step 2 Secure the fitting to the mount surface with
2 x suitable fixings.
Ensure supply driver and connectors are housed
indoors OR in a suitably IP rated enclosure. Cable
ends must be suitably waterproofed. Inspect supply
cables before installation to ensure there is no
damage which will allow water to enter the fitting.
The IP rating stated is applicable only when the fitting
has been installed as per these instructions.
Care must be taken when handling any ingress
protection seals, glands or "O" rings to ensure they
are kept clean, unblemished and replaced exactly in
their required location and suitably fastened home.
After opening the sealed portion of the luminaire for
any reason, SL recommends running the fitting for 15
minutes with the lid open to expel moisture before
closing it up. This will prevent condensation on the
lens and protect the fitting from corrosion.
WARNING: Do not look at exposed LED lamps in
operation. Eye injury can result.
Cleaning:
Fully isolate the fitting and allow to cool.
Clean the fitting with a slightly damp lint free cloth
from a mild solution of soap and water. The fitting
must be completely dry before reconnecting power.
Incompatible or abrasive chemicals can damage the
fitting, contact SL for advice if required.
Pipien
410 381 1497 inter-lux.com answers@inter-lux.com
Inter-lux reserves the right to make technical changes without notice.
2
1
2
500mA SELV supply
(Constant current)
Secure to mounting surface
with 2 suitable fixings.
Pipien
410 381 1497 inter-lux.com answers@inter-lux.com
Inter-lux reserves the right to make technical changes without notice.
3
Hold the central section
when unscrewing the bezel
Spacer Optic
retaining
clip
Optic Bezel
Optic Change
Fully isolate and allow fitting to cool sufficiently before
handling. Always perform an optic change in a clean and
dry environment.
Step 1 Access the existing optic by holding the central
section of the fitting and unscrewing the bezel.
(Note:The back section is secured with additional
thread locker and should not be opened)
Step 2 Carefully remove the spacer and the optic
retaining clip from the bezel with a small
screwdriver (or similar) and allow the optic to fall
out.
Step 3 Insert the new optic into the optic retaining clip
and replace the spacer, optic and retaining clip
into the fitting.
Step 4 Screw the bezel back into the body until fully
tightened.
Pipien
410 381 1497 inter-lux.com answers@inter-lux.com
Inter-lux reserves the right to make technical changes without notice.
4
Tilt adjustment
Adjustment
To adjust the tilt and pan of the fitting use a 2mm Allen
key to loosen off the tilt and pan lock fixings.
Once the desired angle is achieved lock off the fixings.
DO NOT adjust the flat tip grub fixing
DO NOT over tighten the fixings as this could damage the
lock and cause it to no longer function.
Pan adjustment
Pipien
410 381 1497 inter-lux.com answers@inter-lux.com
Inter-lux reserves the right to make technical changes without notice.
5
Series Wiring
SUPPLY
Installation must be carried out by a qualified electrician in
accordance with BS 7671:2008 Wiring Regulations.
230/240V AC 50/60Hz mains supply.
Mains cables must be double insulated and strain relieved.
Observe polarity:
Positive (+) is marked as RED.
Incorrect supply or reverse polarity can cause irreparable damage.
All connections must be made before switching on mains.
Ensure supply driver and connectors are housed indoors OR in a
suitable IP rated enclosure.
Ensure LEDs are connected in ‘series’ as shown below to the LED
drivers.
Mains
Output +
-
LED
Driver
LED
LED
LED
LED
Use suitable
connectors
Pipien
410 381 1497 inter-lux.com answers@inter-lux.com
Inter-lux reserves the right to make technical changes without notice.
6
