MDVR402 Series
Introduction & Warnings
Before installing please read the following warnings carefully. Stortech CCTV
strongly recommends that all connections and installations are carried out by
qualified personnel.
PLEASE READ THIS BEFORE ATTEMPTING INSTALLATION AND USE
The recorder uses a DC power supply; input DC range is 8V 36V. Please pay
attention to VDD and GND when connecting the power. DO NOT make the DVR
short circuit.
• Initial power must be over 30W (Specific power consumption will vary
depending on the external equipment).
• Power supply must be over 60W.
• From the vehicle supply to the DVR all power cables must be able to
withstand 5 Amps or more.
• Install the equipment in the dry and avoid damp, drip, water spray etc.
• To extend the life of the equipment, please install the low vibration part of
the vehicle; we recommend a horizontal installation position.
• The equipment must be installed in the vehicle interior with adequate
ventilation. Do not install in a closet type environment.
• Ensure that equipment is away from any heat source in the vehicle, is not
covered and is located as far as possible from an electromagnetic
environment, which may cause strong interference.
• Ensure that passengers and drivers cannot interfere or damage any
components of the equipment.
• The installation and all materials must bear the correct fuse rating.
• It is recommended that the power cords are kept away from heat any source
and are sealed to prevent water and oil ingress that may result in short
circuit.
• In the absence of professional guidance, please do not open or attempt to
install the equipment.
Attention: The device will automatically format the hard disk/SD card to pre allocate
the storage space before starting to record video.
