STOVES 083645101 Manuale utente
USER GUIDE
A commitment to:
Stoves Range Electric Induction Part Number: 083645101 Date: 30/04/18
To contact Stoves about your appliance, please call:
Calls are charged at the basic rate, please check with your telephone service provider for exact charges
Alternatively general, spares and service information is available from
our website at: www.stoves.co.uk
Glen Dimplex Home Appliances, Stoney Lane, Prescot, Merseyside, L35 2XW
Warranty Registration
0800 952 1065
*Please call our Customer Care team for extended
warranty
Spares Store
0344 815 3745
Customer Care Helpline
0344 815 3740
In case of difculty within the UK
To contact us by email:
To register your appliance by mail:
Please complete the warranty
card and return to the address
supplied
To register your appliance online:
www.stoves.co.uk
Your new appliance comes with our 12-month guarantee, protecting you against electrical and
mechanical breakdown. To register, please complete the registration form included, register online
or by phone. For full terms & conditions of the manufacturer’s guarantee, please refer to the web-
site above. In addition, you may wish to purchase an extended warranty. A leaet explaining how to
do this is included with your appliance.
Our policy is one of constant development and improvement, therefore we cannot guarantee the
strict accuracy of all of our illustrations and specications. Changes may have been made subse-
quent to publishing.
GB - Great Britain þ
IE - Ireland þ
DE - Germany
ES - Spain
FR - French
IT - Italy
PL - Poland
NL - Netherlands
SE - Sweden
CN - China
NZ - New Zealand
AU - Australia
Countries of destination:
Thank you for buying this British-built appliance from us.
This user guide book is designed to help you through each step of owning your new product.
Please read it carefully before you start using your appliance, as we have endeavored to answer as
many questions as possible, and provide you with as much support as we can.
General information, spares and service information is available from our website.
If you should nd something missing from your product or have any questions that are not covered in
this user guide, please contact us (see contact information inside the front cover).
European Directives
As a producer and a supplier of cooking appliances we are committed to the protection of the
environment and are in the compliance with the WEEE directive. All our electric products are
labelled accordingly with the crossed out wheeled bin symbol. This indicates, for disposal
purposes at end of life, that these products must be taken to a recognized collection points,
such as local authority sites/local recycling centres.
This appliance Complies with European Community Directives (CE) for household and similar electrical
appliances and Gas appliances where applicable.
This appliance conforms to European Directive regarding Eco design requirements for energy-related
products. Our policy is one of constant development and improvement, therefore we cannot guarantee
the strict accuracy of all of our illustrations and specications - changes may have been made subse-
quent to publishing.
Disposal of Packaging Material
The packaging materials used with this appliance can be recycled. Please dispose of the packaging
materials in the appropriate container at your local waste disposal facilities.
UK ONLY GAS WARNING:
If you smell gas, Do not try to light any appliance. Do not touch any electrical switch.
Call the Gas Emergency Help line at 0800 111999
INTRODUCTION
WARNING
• If the hob surface is cracked, broken or shattered, switch off the
appliance to avoid the possibility of electric shock and call for a
service engineer’s visit.
• The appliance and its accessible parts become hot during use.
Care should be taken to avoid touching heating elements. Children
less than 8 years of age shall be kept away unless continuously
supervised. This appliance can be used by children aged from 8
years and above and persons with reduced physical sensory or
mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning the use of
the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• Do not use a steam cleaner on any cooking range, hob or oven
appliance.
• Metallic objects such a knives, forks, spoons and lids should not
be placed on the hob surface since they can get hot.
• After use, switch off the hob element by its control and do not rely
on the pan detector.
• The appliance is not intended to be operated by means of an
external timer or separate control system.
• If the cooker is placed on a base, measures have to be taken to
prevent the appliance slipping from the base.
• Unattended cooking on a hob with fat or oil can be dangerous and
may result in re.
• NEVER try to extinguish a re with water, but switch off the
appliance and then cover the ame with a lid or damp cloth.
• Danger of re: Do not store items on the cooking surfaces.
• Only use hob guards designed by the manufacturer of the cooking
appliance or indicated by the manufacturer of the appliance in
the instructions for use as suitable or hob guards incorporated in
the appliance. The use of inappropriate hob guards can cause
accidents.
• This induction hob complies with the applicable EMC and EMF
SAFETY
standards. Therefore it should not interfere with other electronic
units. Persons tted with a pacemaker or any other electrical
implant should clarify with their doctor or the producer of the
implant, whether there implant is adequate and fail-safe. Please
place pans centrally on the cooking zones. The British Heart
Foundation provide additional advice regarding using induction
hobs when a pacemaker is tted.
• During use the appliance becomes hot. Care should be taken to
avoid touching heating elements.
• Do not modify this appliance.
• Do not place articles on or against the appliance.
• Servicing should be carried out only by authorised personnel.
CAUTION
• The cooking process has to be supervised. A short term cooking
process has to be supervised continuously.
• This appliance must not be installed behind a decorative door in
order to avoid overheating.
• Fire Safety Advice
If you do have a re in the kitchen, don’t take any risks - get every-
one out of your home and call the Fire Brigade.
Ifyouhaveanelectricalreinthekitchen:
• Pull the plug out, or switch off the power at the fuse box - this may
be enough to stop the re immediately
• Smother the re with a re blanket, or use a dry powder or carbon
dioxide extinguisher
• Remember: never use water on an electrical or cooking oil re.
• Other Safety Advice
• There is a risk of electric shock, so always make sure you have
turned off and unplugged your appliance before starting. Always
allow the product to cool down before you change a bulb.
• This appliance must be earthed.
• The appliance must never be disconnected from the mains supply
during use, as this will seriously affect the safety and performance,
SAFETY
particularly in relation to surface temperatures becoming hot and
gas operated parts not working efciently.
• GAS WARNING! - If you smell gas: Do not try to light any
appliance, Do not touch any electrical switch. Contact your local
gas supplier immediately.
SAFETY
Getting to know your product
Note: Your appliance layout may differ depending on the model.
Hob 90/100/110cm
Hob control panel
Control Panel 90cm
USING YOUR APPLIANCE
Oven
Oven controls
Clock/Programmer
Grill Oven
Top Oven
Oven Selector Control
Thermostat indicator
Thermostat indicator
Thermostat indicator
Control Panel 90cm (Deluxe)
Control Panel 100/110cm
Fascia
Top Oven
Fanned
Oven
Multifunction
Oven
Fascia Fascia
90cm 90cm Deluxe 100/110cm
Top Oven
Multifunction
Oven
Fanned
Oven with
Splitter
Top Oven
Multifunction
Oven
Fanned
Oven
Slow
Cook
USING YOUR APPLIANCE
Oven
Oven Selector Control
Grill
Clock/Programmer
Oven Oven
Oven controlsOven controls
Oven controls
Oven controls Oven
Top Oven/Grill Split Cavity
Oven Top Oven/Grill
Oven Selector Control
Clock/Programmer
Thermostat indicator
Thermostat indicator Thermostat indicator
Thermostat indicator
Thermostat indicator
Thermostat indicator
Top Oven
Appliance functions
Note: Your oven may not have all of the functions shown here. We recommend for best cooking results,
please preheat your oven for 15 minutes and 3-5 minutes for grilling.
Only slow cook using the dedicated function. When using the multifunction oven, rstly select the
fanned oven feature.
Intense Baking Defrost
Base Heat with Fan Conventional Oven
SSlow Cook Fanned Oven
Fanned Grill Low Grill
Oven Selector Control Single Grill
Conventional Grill Dual Grill
Top Heat Base Heat
Lights Only Pizza Function
Bread Proving Keep Warm
Oven Selector Control Electric oven
OFF
OFF
S
120
140
160
180
200
220
240
260
USING YOUR APPLIANCE
Ovens and Grill
When using the top oven or main oven, the white thermostat indicator light will come on until the
selected temperature is reached.
When the Top oven/grill or grill is switched on, the cooling fans come on to keep the fascia and control
knobs cool during cooking/grilling. The cooling fans may operate when the main ovens are in use,
depending on the temperature setting. The fans may continue to operate for a period after the oven/grill
has been switched off. During use the fan may cycle on and off, this is normal.
Important: Never put items directly on top the base of the oven, or cover the oven base with foil, as
this may cause the element to overheat. Always position items on the shelf.
The left hand main oven will not operate if the programmer is set to Auto, see clock/programmer
section.
Top Oven - Grill
THE DOOR MUST BE CLOSED WHEN THE GRILL IS USED FOR FANNED AND CONVENTIONAL
GRILLING
Main Oven - Grill
THE DOOR MUST BE CLOSED WHEN THE GRILL IS USED FOR FANNED AND CONVENTIONAL
GRILLING.
Tall Oven - Grill (90cm Deluxe only)
THE DOOR MUST BE OPEN WHEN THE GRILL IS USED.
USING YOUR APPLIANCE
