Streamline STREAMBOX TR50.SL-BC Manuale utente

STREAMLINE

Products for the Pure Water Cleaning Industry

InstructIon Manual

PRODUCT

STREAMBOX™

50 Litre Trolley System.

PART NUMBER

• TR50.SL-BC

• TR50.SL-BC-SFC5

• TR50.SLF-BC

• TR50.SLF-BC-SFC5

WARRANTY

Covered for one year from

recorded date of purchase.

(See back page for further

details).

Packed By_____________ Checked By_______________

Date ____/____/____

RESIN FILTER OPTION

If the trolley is ﬁtted with this option, connect the hose from the out-

let of the streambox to the inlet of the blue resin ﬁlter. (LH connction)

Connect the hose from the outlet of the resin ﬁlter (RH connection)

to the hose reel or pole.

If the trolley has no resin ﬁlter, connect the

hose from the outlet of the Streambox to

the hosereel or pole. Fill the water

container. The unit is now carrying in

excess of 40kg of weight. Extreme care

should be taken when transporting or

wheeling the unit around.

Insert the check valve riser into the full

container and screw the lid on.

The check valve prevents water loss whilst changing containers.

FILTER SERVICING (IF FITTED WITH THIS OPTION)

Regular meter readings should be taken using the enclosed TDS

meter to ensure that the system is producing pure water. When the

water TDS no longer registers 000, remove the blue resin ﬁlter from

the trolley and unscrew to top black head. Draw the riser tube from

the resin contents. Dispose of the spent resin in a responsible man-

ner. It is not harmful to the environment. Once the empty vessel has

been ﬂushed out with water, reﬁll the ﬁlter housing with new resin

leaving an air gap of approximately 2”. Carefully push the riser into

the resin. Shake the ﬁlter housing in order to allow the riser to ‘bot-

tom’. Clean the sealing edge of the housing before securing the top.

THE PUMP PRE-FILTER

The pump pre-ﬁlter ensures that

the ingoing tap water is free of any

debris or sand particles. Any

accumulation of debris can be

removed by unscrewing the ﬁlter

and ﬂushing it out. Reconnect in

the same manner. No debris

should be allowed in to the pump

as this can cause the pump to fail.

The pump also has a built in pressure switch. When switched on it

will pump until it has reached the maximum pressure setting before

cutting out. This is a safety feature to protect the pump. Never leave

the pump stored under pressure as this may lead to pump failure.

The pump runs o a rechargeable battery. You should be able to

operate for up to 8 hours on a single charge.

CHARGING

To charge the battery, use charger

supplied. Connect XLR plug into

charging socket on the trolley

and connect 3 pin plug to mains.

Further details relating to charger

can be found in the charger

instructions, included with the

charger.

STREAMLINE

®WARRANTY

The warranty on Machines and Equipment is for 1 year from RECORDED DATE

OF PURCHASE.

THIS WARRANTY EXCLUDES NORMAL MAINTENANCE ITEMS, including but

not limited to HOSES, FILTERS, O-RINGS, DIAPHRAGMS, VALVES, GASKETS,

CARBON BRUSHES and damage to motors and other components as a result

of failure to replace normal maintenance items. THIS LIST IS NOT

EXHAUSTIVE.

If VARITECH receives notice of such defects during the warranty period,

STREAMLINE

®will either, at its opinion, repair or replace components which

prove to be defective.

Replacement parts will only be supplied under warranty, upon the inspection

and approval of the defective parts by

STREAMLINE

®.

Should it be necessary to supply replacement parts before the opportunity to

inspect, these will be charged at current prices and credit will only be issued

upon subsequent inspection and warranty approval by

STREAMLINE

®.

The customer is responsible for the cost of return of the defective part. If

warranty is approved,

STREAMLINE

®will pay for the cost of the repaired or

replacement part.

REPLACEMENT PARTS SUPPLIED UNDER WARRANTY WILL BE

GUARANTEED FOR THE REMAINDER OF THE ORIGINAL PARTS WARRANTY

AND NOT FROM THE INSTALLATION DATE.

This warranty excludes the following conditions and circumstances which are

at the discretion of

STREAMLINE

WEAR AND TEAR, MISUSE, ABUSE, IMPROPER MAINTENANCE, FROST

DAMAGE, THE USE OF CHEMICALS OTHER THAN THOSE SUPPLIED OR

APPROVED BY

STREAMLINE

®, IMPROPER INSTALLATION OR REPAIR,

UNAUTHORISED MODIFICATION, INCIDENTAL OR CONSEQUENTIAL COSTS,

LOSS OR DAMAGE, SERVICE, LABOUR OR THIRD PARTY CHARGES, THE

COST OF RETURNING DEFECTIVE PARTS TO

STREAMLINE

®.

This warranty constitutes the exclusive remedy of any purchaser of a

STREAMLINE

®unit and is in lieu of all other warranties, express or implied,

including without limitation any implied warranty of merchantability or ﬁtness

for use, to the fullest extent permitted by law. In no event shall any implied

warranty of merchantability or ﬁtness for use exceed the term of the

applicable warranty stated above and

STREAMLINE

®shall have no other

obligation or liability.

These rights cannot be transferred to a third party.

August 2010

WHY

STREAMLINE®

FLEXIBILITY

•

STREAMLINE®

systems can be built according to

customers’ exact requirements.

• For non-standard systems, the user’s needs or

speciﬁcations are listened to and turned into reality.

QUALITY

• Whilst price is important, quality is remembered long

after price is forgotten.

• We insist on sourcing brand name products from

around the world, only of a reputable quality, and

bring them together under the

STREAMLINE®

name.

• All

STREAMLINE®

products carry a full one year’s

warranty, according to the manufacturers’ standard

terms and conditions of sale.

SERVICE

• We have an in-house technical helpline able to answer

most of your questions relating to the capabilities and

functionalities of all

STREAMLINE®

products.

• If we get it wrong, we will put it right. If you are sent

a wrong item, we will immediately attend to sending

you the correct item and arrange a collection of the

wrong item without any quibbles.

•

STREAMLINE®

is backed by a comprehensive range

with massive stocks providing you with a ‘one stop

shop’ for all your requirements.

YOU ARE IN SAFE HANDS
