To operate this DAB adaptor, you will need to securely fit the antenna
onto your vehicle’s windscreen, and then connect the antenna to the
DAB adaptor via anthenna jack. Please follow the instructions below:
1. Remove the product out of its packaging and dispose of the packaging
in the correct manner.
2. Open the driver side door of your vehicle and carefully remove the
interior panel from the right-hand frame of the windscreen. This will
reveal a metal pillar.
Important: Please refer to your vehicle’s handbook for
safe and proper removal of the interal panel.
3. With the antenna, carefully remove the protective paper from both
the clear adhesive film and the black adhesive film. Discard both
protective papers in the correct manner.
4. Then attach the black adhesive film to the metal pillar and the
transparent film onto the windscreen. Please ensure that you attach
the antenna properly so that you can reinstall the panel later.
5. Thread the antenna’s wiring along the metal pillar, towards the bottom
and allow the connector-end of the wire to rest on your vehicle’s
dashboard. Ensure you have enough wire to connect the DAB adaptor
when mounted on either the dashboard or air vent mount.
Important: Becareful not to overstrech the wire when doing so.
6. Reinstall the panel back. Important: Please refer to the vehicle
handbook for safe and proper installation.
7. Mount the antenna to either the air vent or dashboard (see Mounting
The DAB adaptor).
8. Connect the antenna to the DAB adaptor.
9. Plug in the DAB adaptor to your vehicle’s 12V socket and switch on
your vehicle to turn on the DAB adaptor.
Vent Clip
To attach the vent clip, loosen the rotary shaft,
then insert the ball joint of the vent clip into
the socket. Once inserted, tighten the rotary
shaft to secure the vent clip in place.
To mount the DAB adaptor using the vent clip,
press the button to open the clip so that it can
be slotted into the vehicle’s air vent. Once the
vent clip is in the air vent, release the button
to secure in place.
Dashboard/Windscreen
To mount the DAB adaptor to your dashboard
or windscreen, you will need to attach the vent
clip to the DAB adaptor (see section above).
With the vent clip in place, insert the clip onto
the central fixing console.
Important: If you intend to mount the DAB adaptor
using the central fixing console, please note that the
adhesive backing can only be used once. We advise
that you first position the console in different places
on your windscreen/dashboard before peeling off the
white protective film.
Once you have found your desired position to
mount the console, carefully peel off the white
protective film from the reverse side of the
central fixing console to reveal the adhesive
backing and secure the console onto your
dashboard/windscreen.
Set Up & Installation Mounting the DAB Adaptor
