Stromtank S 5000 Manuale utente

S-5000 High-power

OWNER‘S MANUAL

2 3

FOREWORD

Time to make the

best of what you

already own.

Congratulations! You are about to install and

use a device from the Stromtank range. You

have chosen a high-tech device that will play

a central role to hear the excellent quality of

your audio components. Stromtank has been

designed to separate your hi-system comple-

tely from the grid to supply clean, undisturbed

grid power to achieve the next level of music

quality with your hi-system.

4 5

PRECAUTIONS

Important safety instructions. Read carefully and keep for future reference!

When the Stromtank is running, it generates voltage that can be po-

tentially lethal. Work on or close to the installation must only be carri-

ed out by thoroughly trained and qualied personnel. Do not attempt

to carry out on-going maintenance of this product yourself. There are

NO USER SERVICEABLE PARTS INSIDE the unit. Do not open the chas-

sis or remove any of its screws. In case of any service needs contact

your Stromtank dealer.

When working on the electrical installation, it is important to be cer-

tain that the source of DC voltage coming from the battery as well as

the source of AC voltage coming from a generator or electric circuit

have been disconnected from the electrical installation.

Even when the Stromtank has been disconnected from the supply

sources (AC and DC), a dangerous voltage may remain at the out-

puts. To eliminate this risk you must switch the Stromtank OFF using

the ON/OFF button. After 10 seconds the electronics are discharged

and intervention may take place without any danger. All elements

connected to the Stromtank must comply with the applicable laws

and regulations.

Persons not holding written authorisation from manufacturer are not permitted to

proceed with any change, modication or repairs that may be required. Only origi-

nal parts may be used for authorised modications or replacements.

The Stromtank is only designed for indoor use and must under no circumstances be

subjected to rain, snow or other humid or dusty conditions. The maximum speci-

cations of the device shown on the type plate must be adhered to.

The weight of Stromtank can be up to 300 Ibs / 135 kg depending upon the

model. Use an appropriate lifting method as well as help from a third party

when installing the equipment.

TABLE OF CONTENTS

Unpacking .................................................................................

Front view .................................................................................

Rear view ...................................................................................

Rear Panel .................................................................................

Installation / Operation ...........................................................

Display Operation ....................................................................

Advanced Features ..................................................................

Maintenance ............................................................................

Storage ......................................................................................

Specictions .............................................................................

Quality and Warranty...............................................................

6 7

UNPACKING

ATTENTION: The weight of the Stromtank can be up to 300 Ibs /135 kg depending

upon the model. Use an appropriate lifting method as well as help from a third

party when installing the equipment.

While the Stromtank is still in its case, please move it to a location near the place where

it will be installed. Remove all jewelry including watches, rings and belts from your per-

son to avoid damage to the exterior of the Stromtank during removal and installation.

At rst remove the cardboard box. Then carefully unscrew the upper screws (Torx

size T25) on the wooden case [Fig.1] and remove the top board [Fig.2].

When unpacking, check that the equipment has not been damaged during transpor-

tation and all items listed below are present. If anything is missing it has to be indi-

cated immediately to your dealer. Check the packaging and the Stromtank carefully.

Package contents:

After checking unscrew the screws (Torx size T25) on the front board to open it [Fig. 3].

ATTENTION: Do not hold the Stromtank unit on its front and do not lift it!

Push the unit from the rear side out of the case [Fig 4].

The nish of the Stromtank is extremely delicate. We suggest wearing the supplied

gloves when handling the Stromtank to avoid abrasion or ngerprints caused by oils

from the skin, etc.

Place the Stromtank on a level surface with an adequate ventilation. Make sure the

surface that will support this component can safely hold its weight up to 300 Ibs.

There should be at least 3 inches of clearance space on each side and 3 inches of

clearance at the top as well as above the unit.

Remove the cloth that covers the Stromtank to protect its nish. Save the cloth in

the box to use it again if you ever need to ship the Stromtank.

1 Stromtank unit

1 locking key

1 AC power cord

1 owner manual

1 vacuum cup

1 pair non-slip gloves

1 warranty card

1 microbre cloth

8 9

FRONT VIEW REAR VIEW

display

brightness

switch

ampere meter

front button

connecting plate

lock / unlock

for transport safety

10 11

REAR PANEL – Hubbel duplex

REAR PANEL – SCHUKO SOCKETS

7 power indicator

8AC input

9 main switch ON / OFF

lock / unlock for transport safety

ground terminal

1 thermal magnetic fuse

2converter port

3BMS port

4emergency charge input

5AC outlets

6fuse (10A - 230V/16A-120V

slow blowing)

7 power indicator

8AC input

9 main switch ON / OFF

lock / unlock for transport safety

ground terminal

1 AC outlets

2thermal magnetic fuse

3converter port

4BMS port

5emergency charge input

6fuse (10A - 230V/16A-120V

slow blowing)

INSTALLATION / OPERATION

Before you start with the installation take care that no audio parts are connected

with the Stromtank and the unit is not connected with the electric circuit.

To install the Stromtank and connect it with your audio equipment please follow the

steps in order.

1. Make sure that the position of the main switch at the rear is in OFF position.

2. Connect the AC input with a power cord to the next available grid outlet.

ATTENTION: Never connect Stromtank’s AC input with its AC outlets. This will

cause damage to the unit!

3. Insert the supplied key into the key switch, turn it into a horizontal position and

remove the key from the switch.

4. Push the main switch at the rear in ON position. The green LED above must

light up now. After a few seconds the ampere meter at the front is illuminated

by a blue light.

5. Plug your audio AC cords into the AC outlets. It is important to make certain

that all audio units are in OFF position. For best sound results we recommend a

cable length of AC-out power connection between STROMTANK and hi equip-

ment of max. 5 meters.

6. Switch on the fuse switch next to the AC outlets.

7. Turn on your connected audio equipment. ATTENTION: One after the other!

8. To select pure power OFF-grid mode and enjoy best music with stable AC

amplitude, pure sinewave and crystal controlled frequency push the left button

at the front and the light of the meter will change to a green illumination. Or

go to grid mode (switch left button again) for charging and on-grid music listening.

Turn on your audio system. To hear the best quality of your audio components it is

recommended to start with ON-grid mode. This allows Stromtank to warm-up and

shakedown the system.

ATTENTION: Stromtank must always be connected with the ground of the power cord.

12 13

DISPLAY OPERATION

The illuminated display at the top of the Stromtank indicates the state of charging

in 10 steps from 10 % up to 100 %. When all 10 indicators are illuminated the unit is

fully charged (100 %). If only one indicator is shown the unit is nearly empty (state

of charging: 10 %).

If Stromtank is in o-grid mode and reaches a rest capacity of 10 % it automatically

switches back to electric circuit for recharging (the light at the ampere meter chan-

ges to blue illumination). As soon as the battery capacity reaches 20 % it is possible

to switch back to o-grid mode.

This security function ensures that the battery cannot totally be discharged, e.g. if

you forget to switch the unit to on-grid mode (charging) after a music session.

ATTENTION: Do not forget to switch back to ON-grid mode for charging the batteries.

If the display shows a red lighting LED check that the AC-in power cord of Stromtank

is connected properly to the electric circuit. The red LED also indicates that the AC-in

fuse is blown.

ADVANCED FEATURES

Stromtank - Inverter

The Stromtank is equipped with a high-performance inverter, which supplies a per-

fect and very precise sine wave. Any unit designed for the 230V –50 Hz / 115V – 60 Hz

electric circuit can be connected to it without any problem, up to the rated power out

of the Stromtank. The Stromtank is protected against overloads and short-circuits.

Thanks to the largely over-dimensioned performance level, loads up to three times

higher than the Stromtank’s rated power can be faultlessly supplied for short peri-

ods (3 sec) of use, thus allowing the load to be started up without any problem.

Automatic Load Detection (Load Search)

In order to save battery energy, the Stromtank stops and automatically goes into

load search mode when the detected load is lower than the sensitivity (2,5 W). It

automatically goes back into operation when a power consumer greater than this

value demands it.

In load search mode (standby), the system will thus consume minimal power from

the battery.

Blue / Hybride Mode

In this mode the current taken on AC-Input is a sinusoid in phase with voltage. That

means only active power is taken from the generator. The Stromtank compensates

harmonics and reactive current from the source.

This function also avoids fast speed change on the generator due to loads jump.

Battery Undervoltage Protection

Stromtank switches o the AC-output group automatically in case the batteries re-

ach undervoltage level. Before it will be switch o there will be an acoustic alarm

signal for approx. 1 minute. If the red LED on the top is lighting check if Stromtank

is connected by AC-in power cord to the electric circuit. When the red LED on the

top disappears the charging mode started (front meter shows charge current). If the

connection works and the red LED is still on check the AC-input fuse.

14 15

MAINTENANCE

STORAGE

The Stromtank requires no user maintenance other than to keep it clean. Like a

piece of furniture the Stromtank has a ne, highly polished nish that can be easily

damaged. Do not rub or polish the nish and do not allow objects to come in contact

with it.

To clean the Stromtank rst unplug the unit from the electric circuit. To wipe o n-

gerprints and other grease spots spray a small amount of mild detergent dissolved

in water onto the supplied microber cloth and gently wipe the surface with the

cloth.

Caution! The cloth must never be dripping wet! If water or other uids enter the cabi-

net, you risk damaging the unit. Do not spray any liquid directly onto the Stromtank.

Never use scouring pads, steel wool, scouring powders or harsh chemical agents,

alcohol, thinners, benzine, insecticide or other volatile substances, as these can per-

manently scratch and destroy the surface.

If you need to transport or ship the Stromtank, make sure to use the original pa-

cking material. Allow the unit to cool down for at least one hour before you wrap or

package it.

The equipment must be stored in a dry environment at an ambient temperature of

between 10° C (50° F) and 45° C (113° F).

16 17

SPECIFICATIONS

Input AC parameters on grid

Input voltage range 100 – 120 Vac / 200 – 240 Vac

Input frequency 45 to 65 Hz (auto sensing)

Input current max. 16 Aac (transfer relay)

Output AC parameters o grid

Output voltage 100 – 130 Vac / 210 – 245 Vac (pure sine wave +/- 2 %)

Output frequenzy 50 Hz/ 60 Hz +/- 0.05% (crystal controlled)

Harmonic distortion < 2%

Continues power @ 25° C 1,500 VA

Power 3 sec. @ 25° C 5,600 VA

Battery power unit

Battery type LFP - Lithium Iron Phosphate (LiFePO4)

Nominal battery voltage 48 Vdc

Nominal capacity 100 Ah

Terminal area

AC output receptacles 3x Furutech high performance schuko sockets

3x Hubbel duplex, Hospital spec. grade

AC output fuse thermal-magnetic circuit breaker

AC input connection ICE 320 - C14 (fuse 10AT / 16 AT*)

Interface converter, BMS*, emergency charger*

* only for use with Stromtank software and charger

Design and specications are subject to change without notice.

18 19

QUALITY AND WARRANTY

During the production and assembly of the Stromtank, each unit undergoes several pro-

fessional checks and tests. These are carried out with strict adherence to the established

procedures. Each Stromtank owns a serial number allowing complete follow-up on the

checks, according to the particular data for each device. For this reason it is very important

never to remove the type plate which shows the serial number. The manufacture, assem-

bly and tests for each Stromtank are carried out in their entirety by its factory in Germany.

The warranty for this equipment depends upon the strict application of the instructions

appearing in this manual.

Exclusion of warranty

No warranty claims will be accepted for damage resulting from handling, usage or pro-

cessing that does not explicitly appear in this manual. Cases of damage arising from the

following causes are notably excluded from the warranty:

• Surge voltage on the battery input

• Incorrect polarity of the battery

• The accidental ingress of liquids into the device or oxidation resulting from condensation

• Damage resulting from physical or mechanical shocks

• Modications carried out without the explicit authorisation of manufacturer

• Nuts or screws that have not been tightened suciently during the installation or maintenance

• Damage due to atmospheric surge voltage (lightning)

• Damage due to inappropriate transportation or packaging

• Disappearance of original marking elements

Exclusion of liability

The placement, commissioning, use, maintenance and servicing of the Stromtank

cannot be the subject of monitoring by manufacturer. Therefore, we assume no

responsibility and liability for damage, costs or losses resulting from an installation

that does not conform to the instructions, defective functioning or decient main-

tenance. The use of a Stromtank is the responsibility of the customer in all cases.

Manufacturer shall in no event be liable for consequential, incidental, contingent or

special damages, even if having been advised of the probability of such damages.

This equipment is neither designed nor guaranteed to supply installations used for

vital medical care nor any other critical installation carrying signicant potential da-

mage risks to people or the environment.

Manufacturer assumes no responsibility for the infringement of patent rights or

other rights of third parties that result from using the Stromtank.

Manufacturer reserves the right to make any modications to the product without

prior notication.

Altri manuali per S 5000

Indice

Altri manuali Stromtank Alimentazione elettrica

Stromtank

Stromtank S1000 Manuale utente

Stromtank

Stromtank S 2500 Manuale utente

Manuali Alimentazione elettrica popolari di altre marche

Monacor

Monacor PS-12CCD Manuale utente

VOLTIMA

VOLTIMA MagicBox 15 Manuale utente

Agilent Technologies

Agilent Technologies 6032A Manuale utente

Miller

Miller Auto Deltaweld 452 Manuale utente

BCP

BCP PUOUBK Foglio di istruzioni

HC 2210 Manuale utente

Puls

Puls CT5.241 Manuale utente

OCZ

OCZ ZX1250W Manuale utente

iseg

iseg ECH 238 Manuale utente

Power

Power XXL A Series Manuale utente

Agilent Technologies

Agilent Technologies 6631B Manuale utente

Renogy

Renogy PHOENIX 300 Manuale utente

HP 6200B Manuale di servizio

Epson

Epson Stylus Scan 2500 Manuale operativo

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manuale utente

Puls

Puls MiniLine ML50.100 Manuale utente

Puls

Puls AS-Interface SLA4.100 Manuale utente

Kenwood

Kenwood PS-60 Manuale utente
