Stryker SR-A10 Manuale utente
2 Year Warranty
CB & Amateur Radio Antenna
USER’S MANUAL
READ THIS MANUAL BEFORE OPERATION
SR-A10
10,000 Watt Capability
INTRODUCTION
Congratulations on the purchase of your Stryker Antenna. Your
Stryker is designed to provide years of enjoyment and trouble-free
service. To ensure that your investment is enjoyed to its fullest ex-
tent, please take a few moments and thoroughly read this manual.
LIMITED WARRANTY
Stryker Radio warrants this product to be free of defects for a
period of two (2) years from the original date of purchase.
This warranty is non-transferable. Warranty does not cover
damages caused by abuse, misuse, negligence (i.e. hitting
overhead objects), improper installation, etc. These are considered
to be avoidable circumstances and are not covered by warranty.
The coaxial cable is warranted for a period of 1 year, and does not
include pinching or cutting of the cable by the door, window or
trunk lid. If your Stryker Antenna needs repair any time during the
(2) year warranty period please visit our website:
www.StrykerRadios.com to obtain an RA number or call
910-221-1086 between the hours of 10 a.m. – 5 p.m. Eastern
standard time.
IMPORTANT: RETAIN YOUR SALES RECEIPT
You will need to include a copy of your original sales receipt along
with your antenna when sending it in for warranty repair.
INSTALLATION
1. Contents
Unpack and inspect your Stryker SR-A10 for missing or
damaged Components.
Quantity Description
1 Stryker SR-A10 Antenna
1 Weather Cap
1 Allen Wrench
1 PL-259 Connector
Caution
Small particles on car service or bottom of magnet can damage the
car’s paint surface. Clean surface of car and bottom of magnet with
soft towel or rag before installing on a vehicle.
When removing the antenna, grasp the coil portion of the mouth
firmly and tilt the antenna towards you. This will break the
magnetic force and allow you to lift the antenna off of vehicle
without scratching the paint. Do not slide twist magnetic mount
while on vehicle.
SWR INFORMATION
1. Choose a clear location to adjust the SWR
Antennas are very sensitive to objects close to them. Go to an open
area to tune your antenna, such as a parking lot. This can be done
at home, providing you are not close to the house. Do not try to
tune inside a building, under trees, near or under power lines, nor
with someone standing next to the antenna. This distorts the signal
and causes a reflection back into the antenna giving false readings.
Also, close all doors, the hood and trunk lid.
2. Setting the SWR
1. Test with the radio only. If you have an amplifier, either
turn it off, or preferably remove from installation.
2. Insert the antenna whip 1 into chrome antenna adjustment
mast at the top of the coil.
3. Using either the meter built into the radio or a good
external SWR meter, calibrate on channel 20. Switch back
to SWR and record the readings on three channels 1, 20, &
40.
4. If the lowest SWR reading occurs on channel 1, the
antenna whip is to long and must be shortened. Loosen the
mast set screws and lower the whip 1/4 into the mast.
SWR INFORMATION (continued)
Tighten mast set screw and again read SWR. Repeat until lowest
SWR is obtained.
If the whip is fully lowered into mast and the SWR is still high,
remove the whip from mast. Using a hacksaw, grinder, or bolt
cutters, cut 1/4 from the bottom part of the whip. Re-insert the whip
into the mast and test again for SWR. Repeat the above procedure
until the SWR is below 1.5 of all channels.
If the lowest SWR reading occurs on channel 40, the antenna whip
is to short and must be raised. Loosen the mast set screws and
raise the whip 1/4, re-tighten set screws and test SWR again.
Repeat the above procedure until the SWR is below 1.5 of all
channels.
