Subaru 2011 Tribeca Manuale utente

Tribeca 2011

Quick Reference Guide.

782335_11_Tribeca_QRG_102010b.indd 2 10/20/10 3:07 PM

Complete U.S. specications and illustrations may

not have been available at time of publication.

Specications are based on the latest product

information available at time of publication. Some

images shown are for illustration purposes only.

Some equipment shown may be optional at

extra cost. Specic options may be available

only in combination with other options. Specic

combinations of equipment or features may vary

from time to time and by geographic area. Certain

accessories and equipment may not be available at

the time of publication.

This Quick Reference Guide applies to all Tribeca

models. Therefore, some explanations may be for

equipment not installed on your vehicle. Subaru

of America, Inc., reserves the right to change or

discontinue at any time, without notice, prices,

colors, materials, equipment, accessories,

specications, models and packages without

incurring any obligation to make the same or

similar changes on vehicles previously sold. Colors

shown may vary due to reproduction process.

For detailed operating and safety information,

please consult the Owner’s Manual.

Subaru, Outback, Legacy, Forester, Impreza,

WRX, WRX/STI, BOXER, SPORTSHIFT, SI-DRIVE,

Lineartronic, Alcantara, Circle Surround, Audyssey,

MultiEQ, XM and Sirius are registered trademarks.

electronically reproduced in whole or in part without

prior written approval of Subaru of America, Inc.

782335_11_Tribeca_QRG_102010b.indd 3 10/20/10 3:07 PM

Table of Contents

Getting Started

Instrument Panel

Gauges

Personalize

Controls

While Operating

Safety/In Case of Emergency

Additional Information

2 - 3

4 - 5

6 - 7

8 - 9

10 - 17

18 - 19

20 - 21

22 - 23

782335_11_Tribeca_QRG_102010b.indd 5 10/20/10 3:07 PM

Remote Keyless Entry

Lock/Arm

• Press to lock all doors

and rear gate.

• If any of the doors or the

rear gate are not fully closed,

an electronic chirp will

sound ve times and the

hazard lights will ash ve

times to alert you that the

doors or the rear gate are

not properly closed.

• To activate the vehicle nder

function, press three times

(within ve seconds). If you

are within 30 feet of the

vehicle, the horn will sound

one time and the hazard

lights will ash three times.

Unlock/Disarm

• Press once to unlock

the driver’s door.

• Press twice (within ve

seconds) to unlock all doors.

• When the “Unlock/Disarm”

button is pressed, the dome

and map lights will illuminate

if the dome light switch is in

the middle position.

Unlocking the

Rear Gate

Press to unlock the rear gate.

An electronic chirp will sound

twice and the hazard lights will

ash twice.

Panic Alarm

• Press once and the horn

will sound and the hazard

lights will ash.

• Press any button on the

remote to deactivate.

Immobilizer

When the security alarm is

activated, the immobilizer

interrupts the starter motor

to prevent an intruder from

starting your vehicle without

a registered key.

782335_11_Tribeca_QRG_102010b.indd 2 10/20/10 3:07 PM

Getting

Started

Instrument

Panel

Gauges Personalize Controls While

Operating

Safety / In Case

of Emergency

Additional

Information

Getting

Started

Seating

Power Driver’s Seat:

Memory (if equipped)

You can memorize two seat positions.

To memorize seat positions:

3. Press the “SET” button.

4. Within ve seconds after pressing the

“SET” button, press the “1” or “2” button.

A buzzer will sound one time to inform

you that the memorizing is nished.

To move the seat to a memorized position

with the vehicle selector lever in “P” (Park)

position, press either the “1” or “2” button.

The seat will move to the stored position.

Power Driver Seat:

8-way Adjust

1. Forward/Backward, Angle

and Height

Move the switch toward the front or rear

to move the seat forward or backward.

Pull the switch up or push down on the

front of the switch to adjust the angle of

the seat cushion. Pulling the switch up or

pushing down on the rear of the switch

will adjust the height of the seat cushion.

2. Seatback

Move the switch in the corresponding

direction to adjust the angle of

the seatback.

Midway Stopping Feature

for 2nd Row Seats

The 2nd row seats are equipped with

a midway stopping feature on the

sliding mechanism. Release the midway

stopping feature by pushing the lever

located on the outside of the 2nd row

seat forward and slide the seat.

Getting

Started

782335_11_Tribeca_QRG_102010b.indd 3 10/20/10 3:08 PM

Instrument Panel

pg. 10 pg. 17pg. 6-7pg. 11 pg. 8pg. 10 pg. 16

782335_11_Tribeca_QRG_102010b.indd 4 10/20/10 3:08 PM

Getting

Started

Instrument

Panel

Gauges Personalize Controls While

Operating

Safety / In Case

of Emergency

Additional

Information

pg. 12-13 pg. 14-15pg. 16 pg. 11

Instrument

Panel

782335_11_Tribeca_QRG_102010b.indd 5 10/20/10 3:08 PM

Gauges Immediate Attention

Trip meter A/B selection and trip

meter reset knob

Tachometer

Temperature Gauge

Caution Informational

Seatbelt warning

Front passenger

seatbelt warning

SRS airbag system

Security indicator light

Door open

Charge warning

Oil pressure warning

Brake system

Rear Differential oil

temperature warning

High beam indicator light

AT OIL TEMP warning

ABS warning

Low fuel

All-Wheel Drive warning

782335_11_Tribeca_QRG_102010b.indd 6 10/20/10 3:08 PM

Getting

Started

Instrument

Panel

Gauges Personalize Controls While

Operating

Safety / In Case

of Emergency

Additional

Information

Gauges

Trip meter and odometer

Speedometer

Fuel Gauge

Informational

Vehicle Dynamics

Control/Vehicle Dynamics

Control operation

Vehicle Dynamics Control OFF

CHECK ENGINE /

Malfunction indicator

Tire pressure warning light

Front passenger frontal

airbag ON

Front passenger frontal

airbag OFF

Low windshield

washer uid

Turn signals

Front fog light indicator

light (if equipped)

Headlight indicator light

Cruise Control

indicator light

Cruise control set

indicator light

SPORT mode

782335_11_Tribeca_QRG_102010b.indd 7 10/20/10 3:09 PM

Personalize

Steering Column

Push the lever down rmly to adjust the

vertical and lengthwise position of the column.

Firmly push the lever back up to lock the

column in place. Do not adjust while driving.

Power Exterior Mirrors

Turn knob to the “L” side to adjust the

left-hand mirror or to the “R” side to adjust

the right-hand mirror. Move the knob in the

direction you want to move the mirror,

then return the knob to the neutral position.

The mirrors can also be adjusted manually.

HomeLink® (if equipped)

Three buttons on the driver’s side sun visor

control indoor or outdoor devices (such as a

garage door) from inside your vehicle.

782335_11_Tribeca_QRG_102010b.indd 8 10/20/10 3:09 PM
