Subaru 2014 Forester Manuale utente

Subaru of America, Inc., Subaru Plaza,

P.O. Box 6000, Cherry Hill, NJ 08034-6000

MSA5B1404A

Issued December 2012

Printed in USA 02/13

1353095_14a_Subaru_Forester_QRG_021913.indd 1 2/19/13 9:33 AM

2014

Forester

Quick Reference Guide

1353095_14a_Subaru_Forester_QRG_021913.indd 2 2/19/13 9:33 AM

Complete U.S. specications and illustrations may

not have been available at time of publication.

Specications are based on the latest product

information available at time of publication. Some

images shown are for illustration purposes only.

Some equipment shown may be optional at

extra cost. Specic options may be available

only in combination with other options. Specic

combinations of equipment or features may vary

from time to time and by geographic area. Certain

accessories and equipment may not be available at

the time of publication.

This Quick Reference Guide applies to all Forester

models. Therefore, some explanations may be for

equipment not installed on your vehicle. Subaru

of America, Inc., reserves the right to change or

discontinue at any time, without notice, prices,

colors, materials, equipment, accessories,

specications, models and packages without

incurring any obligation to make the same or

similar changes on vehicles previously sold. Colors

shown may vary due to reproduction process.

For detailed operating and safety information,

please consult the Owner’s Manual.

Subaru, Outback, Legacy, Forester, Impreza,

WRX, WRX/STI, BOXER, SI-DRIVE, Lineartronic,

Alcantara, EyeSight, HD Radio, Aha Radio,

XM and Sirius are registered trademarks.

electronically reproduced in whole or in part without

prior written approval of Subaru of America, Inc.

1353095_14a_Subaru_Forester_QRG_021913.indd 3 2/19/13 9:33 AM

1353095_14a_Subaru_Forester_QRG_021913.indd 4 2/19/13 9:33 AM

Table of Contents

Getting Started

Instrument Panel

Gauges

Personalize

Controls

While Operating

Safety/In Case of Emergency

Additional Information

2 - 3

4 - 5

6 - 9

10 - 15

16 - 29

30 - 31

32 - 33

33 - 34

1353095_14a_Subaru_Forester_QRG_021913.indd 5 2/19/13 9:33 AM

Remote Keyless Entry

1. Lock/Arm

 •Presstolockalldoorsandthe

rear gate.

 •Ifanyofthedoorsortherear

gate are not fully closed, an

electronic chirp will sound ve

times and the hazard lights will

ash ve times to alert you that

the doors or the rear gate are

not properly closed.

 •Toactivatethevehiclender

function, press three times

(within ve seconds). If you are

within 30 feet of the vehicle,

the horn will sound one time

and the hazard lights will ash

three times.

Keyless Access

with Push Button

Start System

(if equipped)

By simply carrying the access

key in your pocket, you can

lock and unlock doors, open

the rear gate and start your car

without ever having to take the

keyfob out of your pocket.

2. Unlock/Disarm

 •Pressoncetounlockthe

driver’s door.

 •Presstwice(withinve

seconds) to unlock all doors.

 •Whenthe“Unlock/Disarm”

button is pressed, the dome

and map lights will illuminate

if the dome light switch is in

the middle position.

3. Unlocking the

Rear Gate

Press the button to unlock

the rear gate.

4. Panic Alarm

 •Pressonceandthehornwill

sound and the hazard lights

will ash.

 •Pressanybuttononthe

remote to deactivate.

1353095_14a_Subaru_Forester_QRG_021913.indd 2 2/19/13 9:33 AM

Getting

Started

Instrument

Panel

Gauges Personalize Controls While

Operating

Safety/In Case

of Emergency

Additional

Information

Getting

Started

Seating

10-Way Power Driver’s Seat

(if equipped)

1. Forward/Backward, Angle and Height

Move the switch toward the front or rear to move

the seat forward or backward. Pull the switch up

or push down on the front of the switch to adjust

the angle of the seat cushion. Pulling the switch

straight up or pushing the switch straight down

will adjust the height of the entire seat cushion.

2. Seatback

Move the switch in the corresponding direction

to adjust the angle of the seatback.

3. Lumbar Support

Press the front part of the switch to increase

lumbar support; press the rear part of the switch

to decrease lumbar support.

Heated Seats

(if equipped)

Press the switch in the

corresponding direction for

the desired seat temperature.

To turn off the seat heater,

slightly press in the opposite

direction of the current position.

Folding the

Rear Seat

Lower the headrests. Pull up on

the release knob on the seat side

that you want to fold down. To

return the seatback to its original

position, raise the seatback until

it locks into place, making sure

that it is securely locked.

Getting

Started

1353095_14a_Subaru_Forester_QRG_021913.indd 3 2/19/13 9:33 AM

Instrument Panel

pg. 16 pg. 6-9 pg. 29pg. 30 pg. 28pg. 16

1353095_14a_Subaru_Forester_QRG_021913.indd 4 2/19/13 9:33 AM

Getting

Started

Instrument

Panel

Gauges Personalize Controls While

Operating

Safety/In Case

of Emergency

Additional

Information

pg. 18-21 pg. 22-27pg. 17

Clock

Pressthe“+”buttontoadvancetimeorthe

“–”buttontoreversethetime.Vehicleswitha

navigation system please refer to the separate

“OperatingInstructionsforNavigationSystem.”

Instrument

Panel

1353095_14a_Subaru_Forester_QRG_021913.indd 5 2/19/13 9:33 AM

Trip meter A/B selection and trip meter reset knob

Trip meter and odometer

Forester 2.5i

Forester 2.5i Premium

Tachometer

Gauges

Seatbelt warning

Front passenger

seatbelt warning

SRS airbag system

Security indicator light

Door open

Charge warning

Oil pressure warning

Power steering warning

Brake system

Hot coolant temperature /

Cold coolant temperature

High beam indicator light

AT OIL TEMP

(Automatic Transmission)

ABS warning

Low fuel

All-Wheel Drive

(Automatic Transmission)

Windshield washer

uid warning

Immediate Attention

Caution

Informational

1353095_14a_Subaru_Forester_QRG_021913.indd 6 2/19/13 9:33 AM
