MX9200 Café Series Planetary MixMaster Issue: A Page 1 of 15

SERVICE MANUAL

Model MX9200

Café series

Planetary Mixmaster

ISSUE: A

DATE: 19 October 2011

MX9200 Café Series Planetary MixMaster Issue: A Page 2 of 15

SPARE PARTS LIST

PART INFORMATION

Item

Description

Qty

Material

Specification

(&/or Finish)

Supplier's Code

Sunbeam Part No.

MOTOR ASM

A.1

MOTOR

ASSEMBLY

(FAN

FAN SHROUD)

Class F

(k:115°)

MX92006

A.2

STEEL

(電解片

T=1.0mm)

8.75mm x

DIA. 68mm

A.3

PA66

MIXING HEAD ASM

Spare

B.1

MIXING HEAD

Assembly

POLISHED &

CHROMED

MX92005

B.2

SINTER STEEL

B.3

SS S45C

∮12x89mmL

CARBON STEEL

MX9200 Café Series Planetary MixMaster Issue: A Page 3 of 15

B.4

(PLANET GEAR

MIXING SHAFT

MIXING LOCK PIN

BUSH-A

E-RING

PLAIN WASHER

MIXING SHAFT SPRING

MIXING HEAD SCREW

LUBRICANT)

SS S45C

∮6x17mmL

CARBON STEEL

B.5

SINTER BRASS

B.6

CARBON

SPRING STEEL

T=0.8mm

OD=12.00mm

ID=6.00

B.7

STAINLESS

STEEL

B.8

STAINLESS

STEEL

B.9

STAINLESS

STEEL

B.10

Guardian

Crystal Blue

Grease N1G1 2

GEAR ASM

C.1

CHASSIS

C.2

MOTOR PAD

MX9200 Café Series Planetary MixMaster Issue: A Page 4 of 15

C.3

UPPER GEAR

HOUSING

C.4

GEAR BOX

COVER

C.5

FIXED GEAR

SINTER STEEL

C.6

WORM GEAR

SINTER STEEL

C.7

LARGE GEAR

SINTER STEEL

C.8

SMALL GEAR

SINTER STEEL

C.9

BUSH-B

SINTER BRASS

C.10

BUSH-C

SINTER BRASS

ID: Ø8 +0.015 -

0.00

H6 size

C.11

BUSH-D

SINTER BRASS

MX9200 Café Series Planetary MixMaster Issue: A Page 5 of 15

C.12

MAIN SHAFT

STAINLESS

STEEL

∮12x118.5mmL

C.13

GEAR SHAFT

S45C

∮8x52mmL

CARBON STEEL

OD: Ø8 -0.005

-0.011

g5 size

C.14

INSERT SHAFT

S45C

∮4x18mmL

CARBON STEEL

Bottom of PIN

target 159mm ±

0.5mm above

top of BOWL

LOCK

C.15

O-RING

SILICON

C.16

ROOF RING A

0.5mmT FIBER

PAPER

C.17

ROOF RING B

0.5mmT FIBER

PAPER

C.18

GEAR HOUSING

SCREWS

CARBON STEEL

M4.0X18.0mmL

C.19

SPEED SENSOR

CARBON STEEL

M4.0X18.0mmL

Wires Xmm

long

BOWL_ASM

Spare

D.1

BOWL

BOWL BASE

MIRROR

POLISHED

MX92008

MX9200 Café Series Planetary MixMaster Issue: A Page 6 of 15

D.2

(SUS304

T＝0.6mm,)

Standard Polish

Bottom of base

to centre inside

of bowl:

Target 13.5mm

(13.0 - 14.0)

D.4

BOWL CHUTE

CLEAR SAN

GLOSS

MX92007

POK MIXING TOOLS

E.1

Die-Cast Alloy

BEATER

SILVER

Epoxy Powder

Coat

MX92004

E.2

DOUGH HOOK

SILVER

Epoxy Powdre

Coat

MX92001

WISK ASM

Spare

F.1

Wisk

Assembly

(UPPER WISK

LOWER WISK

WISK WIRES A-E)

SILVER

Epoxy Powdre

Coat

MX92003

F.2

SILVER

Epoxy Powdre

Coat

F.3-7

SS WIRE

PLASTIC BEATER ASM

Spare

MX9200 Café Series Planetary MixMaster Issue: A Page 7 of 15

G.1

PLATIC BEATER

ASSEMBLY

CLEAR

GLOSS FINISH

MX92002

G.2

BEATER WIPING

BLADE

TPE

(TPE包膠)

60 DURO

RED pantone

Q160-1-1

THIN TEXTURE

YS20001 A

(Matte)

LOWER ASM

H.1

LOWER BODY

Silver spray

finish

H.2

BOWL LOCK

(SUS304

T＝0.8mm,)

MIRROR

POLISH

H.3

SCREW

STAINLESS

STEEL

Φ4.5X12mmL PM

HINGE MECHANSIM ASM

I.1

NECK

FINISH TO BE

SPECIFIED

I.2

PIVOT IN NECK

MEDIUM

CARBON STEEL,

NICKEL PLATED

KNURLED

25mm FROM

ONE END

I.3

NECK TORSION

SPRING

dia. 2.8mm

3 coil

MX9200 Café Series Planetary MixMaster Issue: A Page 8 of 15

I.4

NECK BEARING

SHELL

GF PA 15%

(PA66+15%GF(A

3EG3))

FINISH TO BE

SPECIFIED

I.5

NECK BEARING

CLAMP

2mm COLD

ROLLED STEEL

(電解片

T=2.0mm)

FORMED ->

HOLES

PUNCHED

I.6

PIVOT PIN CAM

Med carbon

steel, nickel

plated.

KNURLED ON

ONE END

I.7

CAM

FINISH TO BE

SPECIFIED

I.8

CAM SPRING

4.5 coils

per 2EB2

TONGUE ASM

J.1

NECK TONGUE

COVER

FINISH TO BE

SPECIFIED

J.2

TONGUE PAD

J.3

TONGUE

SUPPORT

FINISH TO BE

SPECIFIED

MX9200 Café Series Planetary MixMaster Issue: A Page 9 of 15

SAFE SWITCH ASM

K.1

HEAD SWITCH

ACTUATOR

ABS

K.2

HEAD SWITH

MOUNT

ABS

K.3

SAFE SWITCH

LOWER HEAD ASM

L.1

LOWER HEAD

Silver spray

finish

L.2

LOWER HEAD

END

GFPA 15%

(PA66+15%GF(A

3EG3))

TEXTURE TO

BE SPECIFIED

UPPER HEAD ASM

M.1

UPPER HEAD

Silver spray

finish

M.2

SUNBEAM CAFÉ

SERIES BADGE

ABS

MX9200 Café Series Planetary MixMaster Issue: A Page 10 of 15

M.3

BADGE SPEED

NUTS

SPRING STEEL

M.4

VENTS

GFPA 15%

(PA66+15%GF(A

3EG3))

TEXTURED

RELEASE BUTTON ASM

N.1

HEAD RELEASE

BUTTON

POLISH

CHROMED

N.2

BUTTON SHAFT

FINISH TO BE

SPECIFIED

N.3

ACTUATION PIN

GFPA 15%

(PA66+15%GF(A

3EG3))

FINISH TO BE

SPECIFIED

N.4

BUTTON

SPRINGS

N.5

BUTTON SHAFT

E-RING

CARBON

SPRING STEEL

TIMER ASM

O.1

TIMER Assembly

(SCREEN &

PCB BRACKET)

CLEAR PC

(PC 透明)

HIGH GLOSS

BACK LIGHT

MASKING

MX92010
