Sunfire SunFire 32 Manuale utente

DANGERUltraviolet radiation. Follow instructions. Avoid overexposure. As with

natural sunlight, overexposure can cause eye and skin injury and al-

lergic reactions. Repeated exposure may cause premature aging of the skin and skin cancer.

WEAR PROTECTIVE EYEWEAR; FAILURE TO MAY RESULT IN SEVERE BURNS OR LONGTERM

INJURY TO THE EYES. Medications or cosmetics may increase your sensitivity to the ultravio-

let radiation. Consult physician before using sunlamp if you are using medications or have a

history of skin problems or believe yourself especially sensitive to sunlight. If you do not tan

in the sun, you are unlikely to tan from the use of this product. Children, the elderly, or fair

skinned people who always burn easily and either never tan or tan minimally should not use

this equipment.

Contraindication: This product is contraindicated for use on persons under the age of 18

years. Contraindication: This product must not be used if skin lesions or open wounds are

present.

To use, lie down under canopy and pull down as far as adjustment will allow. Do not use with-

out clear plastic panel and wire grill in place. Untanned persons should not tan on consecutive

days during their ﬁrst week of tanning. Never tan more than once a day. Tanning normally

appears after the ﬁrst few sessions and maximizes after approximately four weeks. Tan once

or twice per week thereafter to maintain appearance. Persons already having a base tan may

begin at advanced levels corresponding to the extent of their base tan.

Skin Type:

I Sensitive Skin (Burns easily and severely and does not tan.)

II Light Skin (Burns easily and severely and tans minimally.)

III Normal Skin (Burns moderately and tans average.)

IV Dark Skin (Burns minimally, tans easily and above average.)

New lamps emit approximately 10% more ultraviolet radiation during the ﬁrst 50 hours of

operation. Recommended tanning times should therefore be reduced by approximately 10%

during that period.

WARNING: • Read these instructions before using this sunlamp product. • This product

should not be used on individuals who have had skin cancer or have a family history of

skin cancer. • Persons repeatedly exposed to UV radiation should be regularly evaluated for

skin cancer. • All persons in the room should wear protective eyewear when lamps are on.

Recommended eyewear: provided eyeshields or equivalent eyewear as deﬁned under 21

CFR 1040.20. Other types of eyewear may not provide adequate protection. Failure to use

protective eyewear may result in severe burns or other eye injury. If discomfort develops,

discontinue use and consult a physician.

THE FOLLOWING LAMPS HAVE BEEN CERTIFIED FOR USE IN THIS EQUIPMENT:

SunFire® Plus Model F71/100W Bi-Pin

SunFire® Max Model FR71/100W Bi-Pin

THIS EQUIPMENT MUST BE EARTH GROUNDED.

This product is in conformity with performance standards for sun lamp products under 21

CFR PART 1040.20 and ANSI/UL Standard 482.

Disconnect power cord before attempting to clean, relamp,

or engage in the maintenance of this product

RECOMMENDED EXPOSURE TIMES IN MINUTES

Level 1/Week 1 Level 2 Level 3 Level 4 Level 5

Skin Type: 1st-3rd Sessions

I Sensitive NOT RECOMMENDED FOR TANNING

II Light 2 4 7 10 12

III Normal 3 6 9 12 12

IV Dark 4 7 10 12 12

MAXIMUM EXPOSURE TIME IS 12 MINUTES

Electrical Requirements

Your sunbed operates from a 120V AC source. You should have a

NEMA 5-20R electrical outlet (below), on a dedicated circuit capable

of providing 20 Amp service, installed in the room in which you will

use the unit. We recommend installation by a professional electrician.

The outlet must be earth grounded. 20 AMP NEMA #5-20R

RECEPTACLE

DANGER

Shock hazard.

Disconnect power before servicing or removing any pro-

tective covers.

Do not operate this device near water or while you are

wet.

DANGER

Some medications may increase your sensitivity to ultraviolet light. It

is recommended that you consult a physician before using this sun-

bed if taking any medication or if you suspect that your skin might be

especially sensitive to sunlight.

WARNING

Wear protective eyewear.

Failure to may result in severe burns or longterm injury to the eyes.

CAUTION

Air from the room is used to cool the sunbed. Maximum ambient room

temperature should be 80°F. Place your sunbed no closer than 6” from

any wall. Make sure nothing obstructs the airow into the sunbed’s

endcaps or out of the fan openings. A poorly ventilated room may

cause the unit to become hot and cause discomfort to the user.

Unpacking and Inspection

Your sunbed comes in two cardboard cartons. Pull back the plastic

sheet and, with a helper, grasp the bench and pull it from the carton

bottom, leaving the plastic wrap and the carton packaging. Do not try

to lift the unit with the plastic still on as it may slip. Do the same with

the canopy.

The canopy box contains the canopy, a pair of gas springs, and the as-

sembly hardware. The bench box contains the bench and stand legs.

Inspect the items and make sure they are free from any visible damage.

Report the extent of any damage to the transportation company.

Hardware Inventory (Plus a small pillow and eyewear)

Shoulder Bolt

Quantity 2

Flanged Sleeve Bushing

Quantity 2

Nylon Flat Washer

Quantity 2

3/8” Washer, Black

Quantity 2

Hex (Allen) Wrench

Quantity 1

3/8-16 Locknut, Black

Quantity 2

10199B

You Will Need:

#2 Phillips

Screwdriver

9/16” Wrench

Assembly Procedures

Lay the bench upside down on the

oor. Locate the two stand legs.

Use the same bolts and washers to

attach the stand legs. Make sure the

bolts are secure.

With a helper holding the canopy open,

align ends of gas spring ball joints with

pivot studs and push into place. Be sure

rod end is down as shown. DO NOT lower

canopy until both gas springs are secure!

Lift and lower canopy a few

times to lubricate gas springs

for optimum performance.

Connect the canopy to bench

power cords. Make sure the

connection is secure.

Plug the three-prong 120V AC

power cord into a dedicated outlet

(see Electrical Requirements).

NOTE:

Pry back the metal

locking clip with a

at screwdriver to

make installation

easier.

CAUTION

Failure to engage locking clips may

result in the ball joints working loose,

allowing the canopy to fall, which may

result in damage to the unit and injury.

Remove the six bolts and washers

installed in the bench.

Turn the bench over and attach

the canopy as shown. Be sure the

white Nylon Washer is between

the hinges.

Thorough Periodic Cleaning

The cooling fans draw air through the bed and will cause a dust build-

up on the lamps and reectors. When a dust buildup is observed, it

is necessary to thoroughly clean the inside of the bench and canopy.

1 Remove the acrylic shield, metal grill and lamps.

2 With a soft cloth, wipe the entire length of each lamp.

3 Clean both sides of the acrylic shield and grill with a non-ammonia

disinfectant cleaner.

4 Wipe the reectors with a clean damp cloth.

5 Re-install the lamps, acrylic shield and grill.

Mechanical Inspection

Inspect the unit’s mechanical integrity every 400-500 hours of use.

• Inspect the unit’s fasteners verifying that all are rmly in place. Pay

particular attention to the hinge bolts.

• Inspect gas springs for signs of wear. Replace gas springs that will not

hold the canopy in the full open position when raised.

• Inspect the AC power cord and its connections.

• Inspect the acrylic. Replace if broken, cracked or badly scratched.

Removing/Replacing Acrylic Shield (bench)

The acrylic shield in the bench and metal grill in the canopy are se-

cured in place by hinged proles which run the length of the bed, both

front and back. Start at the end and simply 1push the inside edge of

the prole toward the aluminum bed frame until it releases its latch-

ing action and then 2 lift. Continue to lift the prole across its entire

length until it swings back freely. Repeat for the other prole. The long

edges of the acrylic shield are now exposed. Standing in front of the

sunbed, grasp the edge of the acrylic and carefully lift it out of the

bench.

Replace the bench acrylic by laying it on the bench and pressing into

place. Close the hinged prole by pushing it back into place until it

snaps tight.

Removing/Replacing Canopy Grill

Follow the above directions for

opening the hinged proles. As you

pry the hinged prole open the

canopy grill should start to drop

out on its own.

Using Your Sunbed

Before using your sunbed, please note the following:

• Your skin should be free of cosmetics, tanning oils, or other body

lotions prior to tanning except for those specically made for use

with tanning devices. However, do not remove natural body oils by

bathing or showering immediately before tanning.

• Keep treated hair from contacting sunbed surfaces. Many hair prod-

ucts can damage the sunbed acrylic. Wear a shower cap or towel if

you use gels, mousses, sprays, or other hair products.

• Your sunbed is designed for individual use. Always wear the safety

goggles supplied with your sunbed or another approved pair of gog-

gles, as dened under 21 CFR 1040.20. Regular sunglasses do not

provide adequate protection from ultraviolet light.

Follow the guidelines for skin type and exposure times as shown in the

table below. Untanned persons should not tan on consecutive days

during their rst week of tanning. Never tan more than once a day. Tan-

ning normally appears after the rst few sessions and maximizes after

approximately four weeks. Tan once or twice per week thereafter to

maintain appearance. Persons already having a base tan may begin at

advanced levels corresponding to the extent of their base tan.

Skin Type:

I Sensitive Skin (Burns easily and severely and does not tan.)

II Light Skin (Burns easily and severely and tans minimally.)

III Normal Skin (Burns moderately and tans average.)

IV Dark Skin (Burns minimally, tans easily and above average.)

Operation

1 Lift the canopy, lie down on the bench

(face up), lower the canopy as close to

your body as possible.

2 Turn the timer knob clockwise to the

desired tanning session time to begin

the tanning session. The lamps will

turn on immediately.

3 When the timer reaches “0” the lamps

turn off. If you want to stop your ses-

sion before time expires, turn the timer knob back to “0”.

4 Raise the canopy by pushing the outer edge of the canopy.

Care and Maintenance

Cleaning After Use

Clean and disinfect your tanning bed’s bench and canopy after each

use. Use a non-abrasive disinfectant cleaner (such as a mixture of 2oz

of Lucasol™ disinfectant with 1 gallon of water) that does not contain

ammonia or ammonia derivatives which may damage the acrylic sur-

face. Spray the acrylic with disinfectant until thoroughly wet. Allow to

remain wet for 10 minutes and then let air dry. Wipe the canopy grill

with a soft cloth slightly dampened with disinfectant, then let air dry.

For heavily soiled areas remove the soil (lotions, etc.) using Lucas®

Spray and Wipe Tanning Bed Acrylic Cleaner. Apply solution with spray

bottle to wet the area thoroughly. Allow to remain wet for 30 seconds

and then wipe the surface dry. Then disinfect as described above.

CAUTION

Be careful. The edges of the

acrylic shield may be sharp.

PROFILE

ACRYLIC

To be assured of maximum tanning effectiveness, change lamps after

approximately 500 hours of use. Tanning will continue after this time

but at a slower rate. We recommend using the lamps specied below.

Use of uncertied lamps is a violation of Federal regulations and may

void your warranty.

1 Grasp a lamp at one end and at the middle, then turn the lamp a

quarter turn. The lamp may then be gently removed from its holder.

2 To reinstall lamp, insert pins on the ends of the lamp into the slots on

top of the lamp holder and turn the lamp a quarter turn.

The following lamps have been certied for use in this equipment:

SunFire® Plus Model F71/100W Bi-Pin

SunFire® Max Model FR71/100W Bi-Pin

RECOMMENDED EXPOSURE TIMES IN MINUTES

Level 1/Week 1 Level 2 Level 3 Level 4 Level 5

Skin Type: 1st-3rd Sessions

I Sensitive NOT RECOMMENDED FOR TANNING

II Light 2 4 7 10 12

III Normal 3 6 9 12 12

IV Dark 4 7 10 12 12

MAXIMUM EXPOSURE TIME IS 12 MINUTES

To obtain warranty service visit www.SunFireTanningBeds.com.

SUNFIRE INDUSTRIES, INC. 4905 HWY 70 E, NEW BERN, NC 28562 • SUNFIRETANNINGBEDS.COM • 800-817-5083

Proudly manufactured in the U.S.A.

Date of purchase:

Bench serial number:

Canopy serial number:

1. Warranty Period: SUNFIRE INDUSTRIES warrants new tanning equipment manufactured

by it, provided it is still owned and operated by the original purchaser, to be free from defects in

material and workmanship under normal use and service, for a prorated period of twelve (12)

months from the date of delivery to the original Purchaser.

2. What is covered: During the warranty period as specied above SUNFIRE INDUSTRIES

will replace any defective system or component, at SUNFIRE INDUSTRIES’s sole discretion.

The Purchaser shall be responsible for the difference between the cost of a new system or com-

ponent and the prorated value of the defective system or component. Prior to making any repairs

SUNFIRE INDUSTRIES will advise the Purchaser of the nature of the problem and the cost to

the Purchaser based on the proration of the defective system or component.

3. What is not covered:

A. Acrylic sheets, starters (igniters), lamps, blue and clear lter glass.

B. Any plastic parts affected by discoloration.

C. Cracked or broken cover plates, end caps and sidebars

D. Any failure to the external timing system (example: T-Max, FST timers and timer system

components)

E. Any failure to the external voltage transformer (example: “buck and boost” transformers)

F. Any damage caused by the failure of any supporting hardware not supplied by SUNFIRE

INDUSTRIES.

G. Any labor charges, travel time charges, or mileage charges associated with a warranty item.

H. Shipping costs back to SUNFIRE INDUSTRIES’S factory. SUNFIRE INDUSTRIES will

pay for ground transportation of repaired or replaced part back to purchaser.

I. Tanning units, parts or components damaged in transit where SUNFIRE INDUSTRIES’S

damaged goods policy is not followed by purchaser or purchaser’s designee.

This warranty does not apply to any failure of product due to alterations, modications,

misuse, abuse, neglect, accident, improper maintenance or installation, use of parts not sup-

plied by SUNFIRE INDUSTRIES, failure to operate and use the product in accordance

with the instructions provided in the Owner’s Manual supplied with the product or failure

to otherwise meet manufacturer’s specications, or if the serial number has been removed,

altered or defaced.

6. Procedure for Requesting Warranty Work: In the event of a problem covered under this

limited warranty, the customer must rst contact SUNFIRE INDUSTRIES and obtain a Returned

Goods Authorization for products to be repaired or replaced at SUNFIRE INDUSTRIES’s discre-

tion, provided product(s) are returned freight prepaid to SUNFIRE INDUSTRIES. SUNFIRE

INDUSTRIES will perform its obligation within thirty (30) days from the date of SUNFIRE

INDUSTRIES’s receipt of the Purchaser’s authorization to effect repairs and acceptance of the

cost of repairs based on the prorated values of the defective systems or components. Any payment

due from the Purchaser shall be payable in full prior to SUNFIRE INDUSTRIES’s return of the

repaired system or component. Any product being returned to SUNFIRE INDUSTRIES for repair

or replacement must be adequately packaged to prevent freight damage and shipped via traceable

method

7. Right to Modify: SUNFIRE INDUSTRIES reserves the right to make changes or improve-

ments in its products without incurring any obligations to similarly alter products which have been

previously purchased.

8. Exclusivity of Warranty: This warranty is the only warranty made by SUNFIRE INDUS-

TRIES and may only be modied or amended by a written instrument signed by a duly authorized

ofcer of SUNFIRE INDUSTRIES. SUNFIRE INDUSTRIES’s sole and exclusive liability and

Purchaser’s sole and exclusive remedy under this warranty shall be, at SUNFIRE INDUSTRIES’s

option, to repair or replace, to the extent available on a prorated basis, any such defective Prod-

ucts. These remedies are available only if SUNFIRE INDUSTRIES’s examination of such Prod-

ucts discloses to SUNFIRE INDUSTRIES’s satisfaction that such defects actually exist and were

not caused by Purchaser’s misuse, abuse, neglect, improper installation, maintenance or testing,

alterations or modications, failure to meet manufacturer’s specications or any other cause be-

yond the range of normal usage, or by accident, re or other hazard. Repair or replacement of a

part does not extend the warranty period or extend the prorated value of a part or product beyond

the initial two year limited warranty period from the date of delivery.

THE WARRANTY SET FORTH ABOVE IS IN LIEU OF ALL OTHER WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WAR-

RANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN

NO EVENT SHALL SUNFIRE INDUSTRIES BE LIABLE FOR ANY INCIDENTAL OR

CONSEQUENTIAL DAMAGES WITH RESPECT TO THE PRODUCTS DELIVERED

HEREUNDER OR SUBSEQUENT USE THEREOF.

9. Limitation of Liability: SUNFIRE INDUSTRIES shall not be liable for any loss, damages,

or penalty resulting from failure to perform any of its obligations under this Agreement due to

force majeure or any cause beyond its reasonable control.

SUNFIRE INDUSTRIES’S LIABILITY UNDER OR FOR BREACH OF THIS AGREE-

MENT SHALL NOT EXCEED THE REFUND OF THE PURCHASE PRICE LESS REA-

SONABLE RENTAL FOR PAST USE. IN NO EVENT SHALL SUNFIRE INDUSTRIES

BE LIABLE FOR COSTS OF PROCUREMENT OF SUBSTITUTE GOODS BY THE

PURCHASER OR FOR UNAUTHORIZED REPAIRS UNDERTAKEN BY THE PUR-

CHASER WITHOUT SUNFIRE INDUSTRIES’S PREVIOUS WRITTEN APPROVAL. IN

NO EVENT SHALL SUNFIRE INDUSTRIES BE LIABLE FOR ANY SPECIAL, CON-

SEQUENTIAL, OR INCIDENTAL DAMAGES, HOWEVER CAUSED, WHETHER FOR

BREACH OF WARRANTY, NEGLIGENCE, OR OTHERWISE. SUNFIRE INDUSTRIES

DISCLAIMS ANY OBLIGATION OR LIABILITY FOR LOSS OF USE OF THE PROD-

UCT WARRANTED, LOSS OF TIME, INCONVENIENCE, RENTAL OR SUBSTITUTE

PRODUCTS, LOSS OF BUSINESS, LOSS OF INCOME, COMMERCIAL LOSS OR ANY

OTHER DIRECT, CONSEQUENTIAL, SPECIAL OR INCIDENTAL DAMAGES.

10. Governing Law: Notwithstanding principles of conicts of law of any jurisdiction to the

contrary, all terms and provisions of this Agreement are to be construed and governed by the laws

of the state of North Carolina without regard to the laws of any other jurisdiction. The Purchaser

waives any and all privileges and rights which they may have under North Carolina Statutes,

relating to venue as it now exists or may hereafter be amended, and under any other statute, or

administrative provision thereof in any legal action on this Agreement; and further, the Purchaser

agrees that any legal action brought on this Agreement or in connection therewith, shall be brought

in the appropriate court in Craven County, North Carolina.

11. Attorney’s Fees: Should a dispute arise with regard to this warranty or any other aspect of this

sale the prevailing party shall be entitled to reasonable attorneys fees and costs through appeal.

Sunbed not tanning

1. Clean sunbed, see Thorough Periodic Cleaning.

2. Replace lamps if lamp hours are greater than 800hrs.

3. Replace acrylic.

Lamps fail to light

1. Check source of AC power. Reset circuit breaker or replace

fuse if necessary.

2. Make sure the unit is plugged into outlet.

3. Make sure canopy to bench cord is properly connected.

One or more lamps fail to light

1. Check that lamp is installed correctly.

2. Switch unlit lamp with a lamp that lights. If the new lamp

lights and the old lamp still does not, replace old lamp.

Problem Troubleshooting

Solution Problem Troubleshooting

Solution

The canopy will not stay up

NOTE: Gas springs are manufactured to hold the canopy in its

fully open position as well as allow it to rest fully closed. If left

open for an extended period of time some creep down may

occur. This is considered normal. Keep the unit closed when

not in use. If the canopy will not stay fully open when raised...

1. Raise and lower the canopy a few times to lubricate gas

spring internal seals.

2. Replace gas springs.

3. Tighten the hinge bolts to create friction.

Sunbed does not stay lit

Check source of AC power. Reset circuit breaker or replace

fuse if necessary.

Altri manuali Sunfire Lettino abbronzante

Sunfire

Sunfire 12R Manuale utente

Manuali Lettino abbronzante popolari di altre marche

ergoline

ergoline JK 116/48-0 Manuale utente

ProSun

ProSun RenuvaSkin L3200 Manuale utente

KBL

KBL megaSun 4500 Super Guida all'installazione

KBL

KBL megaSun space 2000 Manuale utente

ergoline

ergoline VITALITY Manuale utente

KBL

KBL mon amie Manuale utente

JK ERGOLINE ESSENCE Series Manuale utente

KBL

KBL 4800 alpha Manuale utente

Heartland

Heartland SUNDAZZLER 2M Manuale utente

VDL

VDL Hapro TOPAZ 24C Manuale utente

JK-Products

JK-Products DAYON LightSpa Soft Manuale utente

ergoline

ergoline Sunrise series Manuale tecnico

HAPRO

HAPRO Luxura V10 Manuale utente

KBL

KBL space 3000 PURECOLLAGEN Manuale utente

HAPRO

HAPRO Onyx Pro-Line Manuale utente

SOLTRON

SOLTRON Energy TX 500 Manuale utente

ProSun

ProSun Luxura X3 Manuale utente

KBL

KBL Tower pureEnergy Manuale utente
