Supermicro SC818 Manuale utente

Rev. 1.0

SUPER

The SC818 Chassis Series

User Guide

SC818 Chassis User's Guide

1-2

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates.

Please Note: For the most up-to-date version of this manual, please see our web

site at www.supermicro.com.

SUPERMICRO COMPUTER reserves the right to make changes to the product described in this

manual at any time and without notice. This product, including software, if any, and documenta-

tion may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any

medium or machine without prior written consent.

IN NO EVENT WILL SUPERMICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, THE VENDOR SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all

claims will not exceed the price paid for the hardware product.

Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

Manual Revision: Rev. 1.0

Release Date: March 20, 2006

1-3

Chapter 1: Introduction

Table of Contents

Chapter I: Introduction .................................................................1-4

A. Safety Guidelines ......................................................................................... 1-4

B. Packing Lists ................................................................................................ 1-6

C. SC818 Chassis Front Panel ........................................................................ 1-8

D. The SC818 Chassis Speciﬁcations............................................................ 1-10

E. The SC818 Chassis Power Supply Speciﬁcations .....................................1-11

Chapter 2: Installation Procedures..............................................2-1

Section 1: Installing components into the SC818 Chassis ........... 2-1

A. Removing the Top Cover of the SC818 Chassis......................................... 2-1

B. Removing the Riser Card Bracket from the Chassis ................................. 2-2

C. Installing the Motherboard into the Chassis ................................................ 2-3

D. Installing the Chipset Air Shroud into the Chassis ...................................... 2-5

E. Installing the CPU Air Shroud into the Chassis........................................... 2-6

F. Accessing the Hard Disk Drive Tray and Installing a Hard Drive ............... 2-7

G. Rail Installation ............................................................................................ 2-8

H. Installing the Chassis into the Rack .......................................................... 2-10

Section 2: SCSI (Super) GEM Driver Installation Instructions for the

Windows Operating System .............................................................2-6

Appendix: SCA 818S User's Guide ............................................ A-1

SC818 Chassis User's Guide

1-4

Chapter 1- Introduction

A. Safety Guidelines

A-1 Electricity Safety

General Electrical Safety Guidelines

Use the exact type of power cords as required.

Be sure to use power cord(s) that came with safety certiﬁca-

tions.

The power cord(s) must be compliant with the AC voltage require-

ments in your region.

Plug the Power cord(s) into a socket that is properly grounded

before turning on the power.

Take extra precautionary measures when working with high voltage

components. It is not recommended to work alone.

Before removing or installing chassis components, be sure to

disconnect the power ﬁrst. Turn off the system before you dis-

connect the power supply.

•

A-2. ESD Safety Guidelines

Use a grounded wrist strap designed to prevent static discharge.

Keep all components and printed circuit boards (PCBs) in their antistatic bags

until ready for use.

Touch a grounded metal object before removing chassis components or the

motherboard from the antistatic bag.

Do not let components or PCBs come into contact with your clothing, which

may retain a charge even if you are wearing a wrist strap.

Handle a motherboard by its edges only; do not touch its components, peripheral

chips, memory modules or contacts.

When handling processors, chips or modules, avoid touching their pins.

Put the motherboard or components back into their antistatic bags when not

in use.

For the grounding purpose, make sure that your chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

•

Electric Static Discharge (ESD) can damage electronic components. To

prevent damage to your system board, it is important to handle it very

carefully. The following measures are generally sufﬁcient to protect your

equipment from ESD.

1-5

Chapter 1: Introduction

A-3. General Safety Guidelines

Warning!! Follow the guidelines below to avoid possible

damage to the system or injury to yourself:

To avoid injuries to your back, be sure to use your leg muscles, keep your

back straight, and bend your knees, when lifting the system.

After removing the components or chassis covers from the system, place

them on a table for safeguard.

Avoid wearing loose clothing to preventing it from coming into contact with

electrical circuits or being pulled into a cooling fan.

The handles are for sliding the chassis in and out of the racks only. Do

not carry the chassis by the handles.

A-4. Operation Safety Guidelines

1. Make sure that all components and devices are securely fastened on the chassis

and there are no loose parts/screws inside the chassis.

2. Make sure that all cables are properly connected to the connectors and ports.

3. Use the original screws or fasteners to install the covers to the chassis.

4. Be sure to lock to the chassis or the system to prevent unauthorized access.

5. Please follow the procedures listed in Chapter 2 to install or remove components

to or from the SC818.

A-5. An Important Note to the User:

All images and graphics shown in this manual were based upon the latest chas-

sis Revision available at the time of publishing. The chassis you’ve received may

or may not look exactly the same as the graphics shown in this manual.

•

Warning: For proper cooling, make sure to install all chassis covers

before turning on the system. If this rule is not strictly followed, warranty

may become void. Do not open the casing of a power supply. Power

supplies can only be accessed and serviced by a qualiﬁed technician of

the manufacturer. Be sure to follow the steps below to install the chassis

covers:

SC818 Chassis User's Guide

1-6

B. Packing Lists

B-1. The SC818+-1000 Chassis Packaging List:

B-2. The SC-818+-1000 Chassis Accessory Kit:

The SC818+-1000 Chassis Packing List

Item Name Part Number Q'ty Notes

Chassis body CSE-818TS+-1000 1

*Power supply PWS-1K01-1R 1 1000W

*Cooling fan (Chassis fan) FAN-0086 6 40x56 (Nidec) Dual blade 3 pin

*CPU Air Shroud CSE-PT-0128 1

Power Distributor CSE-PT818-PD284 1

Power Distributor Cover CSE-PT126 1

Chipset Air Shroud CSE-PT0115 1 With two Fan-0089

Slim DVD-ROM DVM-PNSC-824(B) 1

Slim DVD -ROM adapter SCD812 1

Slim Floppy device FPD-Teac-S (B) 0 Optional Item

Slim floppy adapter SFBP812 0 Optional Item

CD & floppy PWR converter

cable 07-01-813904-XX1 2

*Dummy CD-ROM Cover 0

*Dummy FDD Cover 1

*Hard drive carriers CSE-PT39(B) 4

*Front panel LED board 1

*Front panel control round

cable CBL-0049 1 Flat cable 54cm (cable)

DVD-ROM cable CBL-0139 1

Floppy cable CBL-0078 1 Optional Item

Backplane

Hard Drive Backplane CSE-SAS-818S 1 SuperMicro install item

Notes:

1. Items marked with “ * ” are included in the chassis packaging.

2. DVD-ROM & FDD are optional items.

3. Slide Rails have no Teflon Tapes.

The SC818+-1000 Chassis

Item Name Part Number Q'ty Note

*Power cord 1

*Rail accessories CSE-PT51 1 1U Rail w/Teflon Tape

*Screw and tie wrap kits (A) B0-01-814O01-XXA 1

*Riser card bracket 1

*Accessory Box 1

Note: Items marked with “ * ” are included in the chassis packaging.

1-7

Chapter 1: Introduction

B-3. The SC818-1000 Chassis Packaging List:

B-4. The SC818-1000 Chassis Accessory Kit:

The SC818 1000 Chassis Packing List

Item Name Part Number Q'ty Notes

Chassis body CSE-818 1000 1

*Power supply PWS-1K01-1R 1 1000W

*Cooling fan (Chassis fan) FAN-0086 6 40x56 (Nidec) Dual blade 3 pin

*CPU Air Shroud CSE-PT-0128 1

Power Distributor CSE-PT818-PD284 1

Power Distributor Cover CSE-PT126 1

Slim DVD-ROM DVM-PNSC-824(B) 1

Slim DVD -ROM adapter SCD812 1

Slim Floppy device FPD-Teac-S (B) 0 Optional Item

Slim floppy adapter SFBP812 0 Optional Item

CD & floppy PWR converter

cable 07-01-813904-XX1 2

*Dummy CD-ROM Cover 0

*Dummy FDD Cover 1

*Hard drive carriers CSE-PT39(B) 4

*Front panel LED board 1

*Front panel control round

cable CBL-0049 1 Flat cable 54cm (cable)

DVD-ROM cable CBL-0139 1

Floppy cable CBL-0078 1 Optional Item

Backplane

Hard Drive Backplane 1 SuperMicro install item

Notes:

1. Items marked with “ * ” are included in the chassis packaging.

2. DVD-ROM & FDD are optional items.

3. Slide Rails have no Teflon Tapes.

The SC818-1000

Item Name Part Number Q'ty Note

*Power cord 1

*Rail accessories CSE-PT51 1 1U Rail W/Teflon Tape

*Screw and tie wrap kits (A) B0-01-814O01-XXA 1

*Riser card bracket 1

*Accessory Box 1

Hard Drive Backplane

SATA cable CBL-0058 4 SuperMicro install item

SATA LED cable CBL-0056 1 SuperMicro install item

Note: Items marked with “ * ” are included in the chassis packaging.

SC818 Chassis User's Guide

1-8

C. The SC818 Chassis Front Panel

Top View

C-1. Major Chassis Components

1. Front Control Panel (*See C-2 below)

2. Power Module 6. Chipset

3. Power Back Plane 7. DDR Memory Modules (8)

4. Fan Modules (6)

5. CPUs (4)

Front View

C-2. Front Panel LED Indicators and IO Ports

1. Front Panel LED Indicators (*See C-3 below)

2. CD-ROM/DVD-ROM

3. Power Supply Module

4. Hard Disk Drives (3)

5. Floppy Drive (optional)

1-9

Chapter 1: Introduction

C-3. Front Panel LED Indicators

1. Power Button

2. Reset Button

3. Power-on LED

4. Hard Drive Activity LED

5. LAN Port1 LED

6. LAN Port2 LED

7. Overheat/Fan Fail LED

C-4. Front Panel LED Descriptions

LED Button Color Condition Description

Green On System OnPower

Off System Off

Amber Blinking HDD ActivityHDD

Off No Activity

Green On Linked

Blinking LAN Activity

LAN1 & LAN2

Off Disconnected

Red On System Overheat

Off System Normal

Overheat

Blinking Fan Failure

SC818 Chassis User's Guide

1-10

D. The SC818 Chassis Speciﬁcations

D-1. The SC818+-1000 Chassis Speciﬁcations

D-2. The SC818-1000 Chassis Speciﬁcations

Model SC818S+-1000 SC818TQ+-1000

Form Factor 1U Rackmount 1U Rackmount

CPU Support AMD Quad Opteron

Processors

AMD Quad Opteron

Processors

Max.

Motherboard Size

ATX 13” x 16” ATX 13” x 16”

Expansion Slots 11

SCA or HD Bays Three 1”hot-swap Ultra

320/160 SCSI drive bays

(SAF-TE Compliant)

Three 1”hot-swap SATA bays

Front Side USB

Port &COM port

Optional Optional

Floppy/CD-ROM Optional/Yes Optional /Yes

Power Supply 1000W cold-swap PS 1000W cold-swap PS

Cooling System Six 40mmx40mmx56mm Six 40mmx40mmx56mm

Dimension

(W x H x D)

17.2” x 1.7” x 27.75”

(437mm x 43mm x 705 mm)

17.2” x 1.7” x 27.75”

(437mm x. 43mm x 705mm)

Weight 35 lb. (15.9 kg) 35 lb. (15.9 kg)

Optional Kits Riser Cards Riser Cards

Model SC818S-1000 SC818TQ-1000

Form Factor 1U Rackmount 1U Rackmount

CPU Support Intel Quad Processors Intel Quad Processors

Max.

Motherboard Size

ATX 16” x 14.5” ATX 16” x 14.5”

Expansion Slots 11

SCA or HD Bays Three 1”hot-swap Ultra

320/160 SCSI drive bays

(SAF-TE Compliant)

Three 1”hot-swap SATA bays

Front Side USB

Port &COM port

Yes Yes

Floppy/CD-ROM Optional/Yes Optional/Yes

Power Supply 1000W cold-swap PS 1000W cold-swap PS

Cooling System Six 40mmx40mmx56mm Six 40mmx40mmx56mm

Dimension

(W x H x D)

17.2” x 1.7” x 27.75”

(437mm x 43mm x 705 mm)

17.2” x 1.7” x 27.75”

(437mm x. 43mm x 705mm)

Weight 35 lb. (15.9 kg) 35 lb. (15.9 kg)

Optional Kits Riser Cards Riser Cards

Indice

Altri manuali Supermicro Telaio

Supermicro

Supermicro SC213XAC-R1K05LP Manuale utente

Supermicro

Supermicro SC813MF2 Series Manuale utente

Supermicro

Supermicro CSE-LB13-AW Series Manuale utente

Supermicro

Supermicro SC116B Manuale utente

Supermicro

Supermicro SCLA26 Manuale utente

Supermicro

Supermicro SC846BE2C-R1K28B Manuale utente

Supermicro

Supermicro SC847BE1C Series Manuale utente

Supermicro

Supermicro SC216 Series Manuale utente

Supermicro

Supermicro SC745BTQ-R1K28B-SQ Manuale utente

Supermicro

Supermicro SC825M Series Manuale utente

Supermicro

Supermicro SC743TQ-865B-SQ Manuale utente

Supermicro

Supermicro SC119XTQ-BR700WB Manuale utente

Supermicro

Supermicro SC745BTQ-R1K28B Manuale utente

Supermicro

Supermicro SCLA25 Manuale utente

Supermicro

Supermicro SC113MTQ-330CB Manuale utente

Supermicro

Supermicro SC811i-280 Manuale utente

Supermicro

Supermicro SC823MTQ-R700LPB Manuale utente

Supermicro

Supermicro SC846BE1C-R1K23B Manuale utente

Supermicro

Supermicro Supero SC513 Series Manuale utente

Supermicro

Supermicro Supero SC832 Manuale utente

Supermicro

Supermicro SC815B Manuale utente

Supermicro

Supermicro SC747 Series Manuale utente

Supermicro

Supermicro SC946LE1C-R1K66JBOD Manuale utente

Supermicro

Supermicro CSE-947S JBOD Manuale utente

Manuali Telaio popolari di altre marche

Advantech

Advantech IPC-623 Series Manuale utente

IMC Networks

IMC Networks iMcV/18 Manuale utente

Chenbro

Chenbro RB13804N4WFT Manuale utente

Lenovo

Lenovo ThinkSystem SR665 V3 Manuale utente

Wuntronic

Wuntronic PCI4DRQ Manuale utente

EtherWAN

EtherWAN EMC400 Manuale utente

Overland Storage

Overland Storage SnapSAN S1000 Guida

Philips

Philips LC4.1E A Manuale utente

Chenbro

Chenbro RM437 Series Manuale utente

Pickering

Pickering 40-914 Manuale utente

HP A7503-S Istruzioni per il montaggio

SilverStone

SilverStone RMS08 Series Manuale utente

NI cRIO-FRC II Manuale utente

Pickering

Pickering 65-200 Manuale utente

Allied Telesis

Allied Telesis AT-MMCR18 Manuale utente

Hisense

Hisense MSD6586 Manuale utente

Cisco

Cisco Nexus 7010 Manuale di istruzioni

JYTEK

JYTEK PXIe-62780 Manuale utente
