PROXI
INSTALLATION AND MAINTENANCE GUIDE
INSTALLATION AND MAINTENANCE GUIDE
ELECTRONIC DETECTION
KIT FOR FAUCETS
2
Ref. RES-110P / RES-110P-T /
RES-110P-ENC / RES-110P-T-ENC
3 TECHNICAL CHARACTERISTICS
4 PRE-INSTALLATION
5-8 INSTALLATION
9-11 SETTING ADJUSTMENTS
12 MAINTENANCE
13 TROUBLESHOOTING
14 LIMITED WARRANTY
INSTALLATION GUIDE
PROXI detection kit for faucets
Index
The information in this document reects products at the date of printing. SUPRATECH reserves the right, subject to all
applicable laws, at any time, at its sole discretion, and without notice, to discontinue or change the features, designs, materials,
and other specications of its products, and to either permanently or temporarily withdraw any of the forgoing from the market.
All information in this document is provided “as is” without warranty of any kind, either expressed or implied, including but not
limited to any implied warranties of merchantability, tness for a particular purpose, or non-infringement. SUPRATECH assumes
no responsibility for errors or omissions in the information presented in this document. In no event shall SUPRATECH be liable
for any special, incidental, indirect, or consequential damages of any kind, or any damages whatsoever arising out of or in
connection with the use or performance of this information. The tradenames, trademarks, logos, and service marks presented
in this document, including their design, are the property of SUPRATECH or other third parties and you are not permitted to use
them without the prior written consent of SUPRATECH or such third party as may own them.
3
9V Battery
Power supply options
Technical Characteristics
9V
Transformer Battery box
for 6x1,5V AA
batteries
IP68
Transformer
Detection type Touch free sensor
Power supply 9V battery or 230/9V transformer
Recommended water
pressure
0.5-8.0 bars. If the water pressure exceeds 8 bars,
use a pressure reducing valve.
Hot water
temperature Max 70°C
Min. detection
range 30 mm
Max. detection
range 300 mm
or
1 X PROXI SENSOR
FRONT FIXATION
FOR RECESSED INSTALLATION
1 X PROXI SENSOR
FOR PANEL MOUNTED
INSTALLATION
1 X SOLENOID
HOUSING WITH FILTER
AND INLET NIPLE
1 X ACETAL
SOLENOID
4
Pre-Installation
Check contents
Separate every part from the packaging and go over each item according
to the TECHNICAL CHARACTERISTICS section.
Please check that all components are present and in good condition
before discarding the packaging. If any parts are missing, do not attempt
to install the detection kit until you have obtained all parts.
Warnings
Do not install the system in front of a mirror or any other electronical
systems using infrared sensors.
To prevent reection problems, it is recommended to keep a minimum
distance of 1500 mm between the sensor unit and any other object.
Prepping for installation
Flush water supply lines thoroughly before installing.
Shut o water supply.
Operation
Once the system is set up and connected to the water supply source:
Water will automatically be ushed when the user leaves the sensor area
after using the urinal. The water ow will cease after a predetermined
number of seconds.
All the plumbing should be installed in accordance with applicable codes
and regulations.
5
STEP 1 –PREPPING FOR INSTALLATION
1Shut o water supply
2Remove nut, disk, and gasket.
GASKET
NUT
STEP 2 –SYSTEM INSTALLATION
1Place the sensor in its designated
location.
18-25
18-25
2
Slide the nut, disk, and gasket
back onto the sensor and secure
them into place.
GASKET
NUT
3Connect the water outlet to the
solenoid valve. WATER
OUTLET
WATER
OUTLET
4
If your system is equipped with
an inlet nipple, connect it to the
water supply inlet on the Solenoid
body or connect it directly to the
shut-o valve FILTER
WATER INLET
NOTE: Make sure
the lter is set
up between the
solenoid body and
the shut-o valve
(angle valve)
(not supplied).
Installation PROXI SENSOR
6
Installation
5
Open the central water supply and
the shut-o valves (angle valves)
and check for leaks.
6
Connect the waterproof connector
from the sensor to the solenoid
valve connector. FROM THE SENSOR TO THE VALVE
STEP 3 –CONNECTING TO THE POWER SOURCE
1
Connect the waterproof
connector from the sensor to
the power source. FROM THE SENSOR TO THE POWER
SOURCE
2
Battery powered
Mount the batteries to the wall
using screws or double-sided
tape.
Transformer powered
a. Connect the waterproof
connector from the sensor
to the transformer.
b. Plug the transformer into the
electrical socket.
3
Important
Wait 10 seconds before operating
the system.
PROXI SENSOR
7
Installation
STEP 1 –INSTALLATION PREPPING
1Shut o power supply.
2Cut an opening in the wall to the
size of the PVC pipe.
STEP 2 –SYSTEM INSTALLATION
1Insert the PVC pipe into
the opening.
2
When the construction work is
complete, cut the PVC pipe to the
required length.
3
Place the sensor in the PVC pipe
and tighten the two Allen
screws provided.
Important: Place the solenoid
valve, body and power source
in an accessible place such as
under the sink or in the fake
ceiling.
4
Connect the water outlet to the
solenoid valve body.
The inlet and outlet should follow
the indicating arrow on the
solenoid valve body.
WATER OUTLET
WATER OUTLET
PROXI SENSOR
FRONT FIXATION
8
Installation
5
If your system is equipped
with an inlet nipple, connect
it to the water supply inlet on
the solenoid valve housing or
connect directly to the
shut-o valve. FILTER
WATER INLET
NOTE: Make sure
the lter is set
up between the
solenoid body and
the shut-o valve
(angle valve)
(not supplied).
6
Open the central water supply
and the shut-o valves (angle
valves) and check for leaks.
7
Connect the waterproof
connector from the sensor to
the solenoid valve connector. FROM THE SENSOR TO THE VALVE
STEP 3 –CONNECTING TO THE POWER SOURCE
1
Connect the waterproof
connector from the sensor to
the power source. FROM THE SENSOR TO THE POWER
SOURCE
2
Battery powered
Mount the batteries to
the wall using screws or
double-sided tape.
3
Transformer powered
a. Connect the waterproof
connector from the sensor to
the transformer.
b. Plug the transformer into the
electrical socket.
Important
Wait 10 seconds before
operating the system.
PROXI SENSOR
FRONT FIXATION
9
Setting adjustments
SELF
ADJUSTMENT
MODE
FLOW TIME
TRIGGERING TIME
DETECTION
RANGE
24 HOUR HYGIENE
FLUSH
RESET
TEMPORARY OFF
FUNCTION
DELAY TIME
Adjusting the settings with the (optional) RES-31 remote control
If necessary, the sensor settings can be adjusted:
Turn the water supply o .
To adjust the sensor using the remote control, position the remote
control approximately 15-20 cm directly in front of the sensor.
Select the function you wish to adjust by pressing the corresponding
button once.
After pressing the function button once, the LED on the front
of the remote will ash quickly.
At this point, you can adjust the setting by pressing the (+) and (-) buttons,
each press increasing and decreasing by one level.
When you have nished adjusting, switch the water supply back on.
10
Setting adjustments
DETECTION RANGE:
the detection range refers to the greatest
distance from which an object can be sensed in order to activate the
system. Press the RANGE button and wait for a quick ashing of the
LED in the sensor eye. Then, press + to increase the detection range
and -to decrease it.
NOTE: once the detection range has been set using the remote control,
this range is memorized even in the event of a power cut.
SELF ADJUSTMENT MODE:
to activate, rst ensure that no objects
are in front of the sensor. Press the ADJ button and wait for a quick
ashing of the LED in the sensor eye. Move the hand that is holding the
remote control, away from the sensor area. The ideal sensor range for
each specic location will be set automatically. Once self-adjustment
has taken place, the solenoid valve will open and close for one second
as an indication that the ideal sensor range has been set, and
the product is ready for use.
TRIGGERING TIME:
it is recommended to change the triggering time
only for WC and urinal ushes. This prevents unintentional activations
which may occur when someone passes by the WC or urinal without
intending to use it. By adjusting the triggering time, the system will
only be activated after a minimum presence time has elapsed.
If necessary, the triggering time can be adjusted as follows:
press the IN button. Wait for the blue light to ash on the sensor.
Then press + to increase the safety time or –to decrease it
.
FLOW TIME
: this button applies to ush valves for toilets and urinals
with an infrared dual ush system. For these ush valves, the full ow
time can be adjusted using the double wave button. If required, adjust
the full ow time as follows: press the double wave button and wait for
a quick ashing of the LED in the sensor eye. Then, press +to increase
the ow time and - to decrease it.
