06
SPECIFICATIONS
MODEL C20 C30 C40 C50 C60 C80 C60T C80T
Discharge SIDE SIDE
Fan 11112222
Performance at Air 27°C, Water 26°C
Heat Capacity
(Min - Max) kW 2.3 - 9.2 2.9 - 12.5 3.8 - 16.0 4.7 - 19.0 5.9 - 24.0 6.8 - 28.5 5.9 - 24.0 6.8 - 28.5
Power Consumption
(Min - Max) kW 0.18 - 1.59 0.22 - 2.02 0.3 - 2.66 0.37 - 3.4 0.47 - 4.28 0.54 - 5.09 0.47 - 4.28 0.54 - 5.09
COP 5.8 - 13.0 6.2 - 13.0 6.0 - 12.6 5.6 - 12.5 5.6 - 12.5 5.6 - 12.4 5.6 - 12.5 5.6 - 12.4
Performance at Air 15°C, Water 26°C
Heat Capacity
(Min - Max) kW 1.9 - 6.8 2.2 - 9.2 3.0 - 11.5 3.9 - 14.7 4.7 - 18.9 5.6 - 23.2 4.7 - 18.9 5.6 - 23.2
Power Consumption kW 0.27 - 1.51 0.31 - 2.0 0.39 - 2.55 0.51 - 3.27 0.61 - 4.2 0.73 - 5.16 0.61 - 4.2 0.73 - 5.16
COP 4.5 - 7.1 4.6 - 7.1 4.5 - 7.0 4.5 - 7.0 4.5 - 7.0 4.5 - 7.0 4.5 - 7.0 4.5 - 7.0
General
Rated Current Amps 6.9 8.5 11.7 16.3 18.9 22.5 6.9 8.2
Minimum Fuse Current Amps 10.0 15.0 20.0 20.0 32.0 32.0 9.0 13.0
Voltage/Power Supply
220-240v /
50Hz / 1PH
220-240v /
50Hz / 1PH
220-240v /
50Hz / 1PH
220-240v /
50Hz / 1PH
220-240v /
50Hz / 1PH
220-240v /
50Hz / 1PH
380-415v /
50Hz / 3PH
380-415v /
50Hz / 3PH
Pool Volume
Cold Climate Litres 20,000 30,000 40,000 50,000 60,000 80,000 60,000 80,000
Pool Volume
Warm Climate Litres 30,000 40,000 50,000 60,000 70,000 90,000 70,000 90,000
Advised Flow Rate L/m 50 70 80 100 140 180 140 180
Inlet / Outlet mm 50 50 50 50 50 50 50 50
Compressor Brand GMCC /
Toshiba
GMCC /
Toshiba Mitsubishi Mitsubishi Mitsubishi Mitsubishi Mitsubishi Mitsubishi
Noise Level (1m) db 40 - 52 40 - 52 41 - 54 41 - 54 42 - 60 42 - 60 42 - 60 42 - 60
Weight / Dimensions (L x W x H)
Net Weight kg 49 59 67 87 123 127 123 127
Gross Weight kg 57 69 76 97 135 140 135 140
Net Dimensions mm 1025 * 395 * 565 1068 * 465 * 715 1068 * 465 * 715 1145 * 480 * 886 1076 * 470 * 1290 1076 * 470 * 1290 1076 * 470 * 1290 1076 * 470 * 1290
Packing Dimensions mm 1080 * 405 * 705 1120 * 495 * 855 1120 * 495 * 855 1200 * 515 * 1015 1156 * 517 * 1430 1156 * 517 * 1430 1156 * 517 * 1430 1156 * 517 * 1430
Technical Specications
Heatseeker Nova+Inverter Heat Pump
