SurfLink MINI MOBILE Manuale utente
MINI MOBILE
OPERATIONS MANUAL
System includes: SurfLink Remote Microphone 2
and SurfLink Mini Mobile Adapter
IMPORTANT: SurfLink Mini Mobile Adapter is ONLY
compatible with SurfLink Remote Microphone 2.
Table of Contents
Introduction 4
Basic Use
SurfLink Remote Microphone 6
SurfLink Mini Mobile 8
SurfLink Remote Microphone
Controls Overview 12
Operation
Low Battery and Charging 14
Power On/Off Slider 16
Syncing to Hearing Instruments 17
Built-In Microphones 19
LED 20
How to Wear 21
Streaming Audio 22
Interoperability with Other Accessories 23
SurfLink Mini Mobile
Controls Overview 24
Operation
Low Battery and Charging 26
Multi-function Push-Button 27
Power On/Off 27
Bluetooth Pairing 27
Interacting with Phone Calls 29
Listening to Music 30
Resetting 30
LED 31
Typical Use Cases 32
Troubleshooting
SurfLink Remote Microphone 34
SurfLink Mini Mobile 36
Regulatory Notices 38
IMPORTANT: SurfLink Mini Mobile Adapter is ONLY
compatible with SurfLink Remote Microphone 2.
Introduction
The SurfLink Mini Mobile system includes both the
SurfLink Remote Microphone and SurfLink Mini Mobile
Adapter. Prior to use, both products will need to be
separately set up. The SurfLink Remote Microphone
will be synced to your hearing instruments. The
SurfLink Mini Mobile Adapter will be paired to your
Bluetooth device.
The SurfLink Remote Microphone is designed
to stream remote microphone audio directly to your
900MHz wireless hearing instruments. When worn
by a distant speaker in noisy environments, SurfLink
Remote Microphone functions as an assistive listening
device.
When SurfLink Mini Mobile Adapter is attached to
SurfLink Remote Microphone, the resulting SurfLink
Mini Mobile system is designed to stream audio
from your Bluetooth device to your 900MHz wireless
hearing instruments.
Streaming – Audio or sound transmitted from
SurfLink Remote Microphone to your 900MHz wireless
hearing instruments.
4
Package Contents
• SurfLink Remote Microphone
• SurfLink Mini Mobile Adapter
• USB-to-MicroUSB Charging Cable
• Wall Power Adapter
• Operations Manual
Optional Accessories
• Car Charger Adapter
• Lanyard
Typical Setup for SurfLink Remote Microphone
5
Hearing Instrument Speaker
SurfLink Remote Microphone
Basic Use
To quickly start using SurfLink Remote Microphone:
1. Power on SurfLink Remote
Microphone. Green LED
appears for 2 seconds.
2. Press “Sync” icon on
slider button for 5 seconds
until LED starts rapidly
blinking blue.
3. Open one hearing
instrument battery door,
insert battery and close
battery door. Green LED
pulses to confirm successful
sync.
If you only have one hearing
instrument, wait 20 seconds
until red LED pulses.
6
Basic Use
If you have two hearing
instruments, open second
hearing instrument battery
door, insert battery and
close battery door. Green
LED pulses to confirm
successful sync.
4. Each hearing instrument
should automatically start
streaming audio. Blue
LED slowly pulses when
audio streaming is active.
5. Have a speaker attach
SurfLink Remote
Microphone to their
clothing, within 8 inches
(20cm) of their mouth is
recommended for best
performance.
6. To stop streaming, turn
off SurfLink Remote
Microphone.
7
Basic Use
SurfLink Mini Mobile
Basic Use
To quickly start using SurfLink Mini Mobile:
1. Ensure SurfLink
Remote Microphone
has been properly
setup with your hearing
instruments and is in
powered on state.
2. Insert the male
microUSB jack of
SurfLink Mini Mobile
Adapter into SurfLink
Remote Microphone’s
female microUSB jack.
3. To turn on SurfLink
Mini Mobile Adapter,
press its push-button
for 2 seconds and
release when the
green LED appears.
8
Basic Use
4. Put your Bluetooth device into
pairing mode.
NOTE:Some devices may ask for the SurfLink
Mini Mobile Adapter PIN, which is 0000.
5. While the green LED
is slowly pulsing,
double-click the push-
button. The LED starts
rapidly blinking blue,
which puts SurfLink
Mini Mobile Adapter
into Bluetooth Pairing Mode.
6. On your Bluetooth device, select SurfLink Mini
to complete the pairing process.
x2
9
Basic Use
7. A green LED confirms
a successful Bluetooth
pairing.
8. To verify your setup, ensure LED is slowly
pulsing blue and either:
• Play music on your Bluetooth device
• Have someone call your Bluetooth device
o When you hear the incoming call ringtone
in your hearing instruments, briefly press
and release the push-button on SurfLink
Mini Mobile Adapter.
o Speak into SurfLink Mini Mobile Adapter
microphone.
o To end the call, briefly press and
release the push-button.
10
Basic Use
