SurgeX
Installation Instructions
SX1115RL
Mounting
The SurgeX SX1115RL is designed to be installed in a 19 inch equipment rack and
requires one unit (1-U) of rack space. Remove the product from its packaging and
slide it into place in the rack being careful to feed the power cord into the rack first
and guide it so that it does not get caught or jammed as the product is installed.
Use the four screws provided with the product to secure the rack ears to the rack
rails. These screws can be tightened by hand and do not require tools.
120 Volt Connections
Connect power to the unit by plugging the cord into a 120V ac receptacle.
The SX1115RL has 8 receptacles on the rear panel: six switched, and two always
on. Each receptacle is rated for a maximum load of 15 amps, but the total load also
must not exceed 15 amps. Plug the equipment cords into the always-on and
switched receptacles as needed to power the equipment.
The always-on receptacles provide power as long as power is supplied to the
SurgeX and the AC voltage is within normal limits. The six switched outlets
provide power only when the front panel switch is on.
Indicator Lights
The SX1115RL has three indicator lights on the front panel. The red Power light
indicates that the power switch is turned on, power is applied to the unit and the
AC voltage is within normal limits. The orange Over/Under Voltage Protection
light indicates that the AC voltage is below 90 volts or above 145 volts. The green
Self-Test light indicates that power is applied to the unit and the internal surge
protection circuitry is fully functional.
Littlite Connectors
The SX1115RL has provision for one or two Littlites. Plug the Littlites into the
two three-pin XLR connectors on the front panel and use the dimmer to set a
suitable brightness. Standard or HI brightness Littlites can be used. Each connector
can supply up to 5 Watts maximum. LED type Littlites can be used with the
SX1115RL but the dimmer must be set fully clockwise.
