Svan SVJI1045 Manuale utente
EN
SVJI1045
EN - 2
This user manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this user manual before using your appliance and keep this
book for future reference.
WARNING Serious injury or death risk
Dangerous voltage risk
Injury or property damage risk
Operating the system correctly
EN - 3
4
1.1 General Safety Warnings ..............................................................................................4
.....................................................................................................5
1.3 During Usage..................................................................................................................6
9
2.1 Machine Positioning ......................................................................................................9
2.2 Water Connection..........................................................................................................9
2.3 Water Inlet Hose.............................................................................................................9
2.4 Drain Hose (Model Depending)....................................................................................10
2.5 Electrical Connection....................................................................................................10
11
3.1 General Sppearance ....................................................................................................11
...............................................................................................11
13
....................................................................13
4.2 Salt Usage (IF AVAILABLE)..........................................................................................13
4.3 Fill The Salt (IF AVAILABLE) ........................................................................................13
.......................................................................................................................14
4.5 Water Hardness Table .................................................................................................14
.................................................................................................14
4.7 Setting .........................................................................................................................14
4.8 Detergent usage..........................................................................................................15
4.9 Filling the detergent......................................................................................................15
4.10 Using combined detergents.......................................................................................15
4.11 Rinse-aid usage........................................................................................................15
4.12 Filling the rinse-aid and setting..................................................................................15
17
5.1 Recommendations .......................................................................................................17
5.2 Alternative Basket Loads..............................................................................................19
20
21
7.1 Changing a Programme ...............................................................................................21
7.2 Cancelling a Programme............................................................................................22
...........................................................................................22
24
8.1 Filters............................................................................................................................24
8.2 Spray Arms...................................................................................................................25
8.3 Drain Pump...................................................................................................................25
26
EN - 4
• Read these instructions carefully before using your
appliance and keep this manual for future reference.
Please check the packaging of your machine
before installation and the outer surface of the
machine once the packaging has been removed. Do
not operate the machine if it appears damaged or if
the packaging has been opened.
• Packaging materials protect your machine from any
damage that might occur during transportation. The
packaging materials are environmentally friendly
as they are recyclable. Use of recycled material
reduces raw material consumption and decreases
waste production.
This appliance can be used by children aged from
8 years and above, and by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning the use of the
appliance in a safe way and understand hazards
involved. Children should not be allowed to play with
the appliance.
Remove packaging and keep it out of reach of
children.
Keep children away from detergents and rinse
aids.
EN - 5
There may be some residue left in the machine
after washing. Keep children away from the machine
when it is open.
• Choose a suitable and safe place to install your
machine.
• Only original spare parts should be used with the
machine.
Unplug the machine before installation.
Your machine must only be installed by an
authorised service agent. Installation by anyone other
than an authorised agent may cause your warranty to
be void.
Check that the indoor electrical fuse system is
connected in line with safety regulations.
All electrical connections must match the values on
the plate.
Ensure the machine does not stand on the
electrical supply cable.
Never use an extension cord or a multiple socket
connection.
The plug should be accessible after the machine is
installed.
• After installation, run your machine unloaded for the
The machine must not be plugged in during
positioning.
EN - 6
Always use the coated plug supplied with your
machine.
If the electrical cable is damaged, it should only
• Connect the hose directly to the water inlet tap. The
pressure supplied by the tap should be a minimum
of 0.03 MPa and a maximum of 1 MPa. If the
pressure exceeds 1 MPa, a pressure relief valve
• This machine is for domestic use only; do not use
it for other purposes. Commercial use will void the
guarantee.
Do not stand, sit or place loads on the open door
the dishwasher.
Only use detergents and rinse aids produced
responsible for any damage that may occur due to
misuse.
Do not drink water from the machine.
Due to the danger of explosion, do not place any
chemical dissolving agents into the machine’s washing
section.
• Check the heat-resistance of plastic items before
washing them in the machine.
Only put items in the machine which are suitable for
EN - 7
Do not open the door while the machine is in
operation, hot water may spill out. Safety devices
ensure the machine stops if the door is opened.
The machine door should not be left open. It may
cause accidents.
Place knives and other sharp objects in the cutlery
basket in a blade-down position.
For models with the automatic door-opening
system, when the EnergySave option is active, the
door will open at the end of a program. To prevent
damage to your dishwasher, do not attempt to close
the door for one minute after it has opened. For
after a programme has ended. Do not stand in front of
the door after the auto-open signal sounds.
In the case of a malfunction, repair should only
be performed by an authorised service company,
otherwise the warranty will be void.
Before repair work, the machine should be
disconnected from the mains. Do not pull the cable to
Operation at a low voltage will cause a decline in
performance levels.
For safety, disconnect the plug once a program has
To avoid an electric shock, do not unplug the
machine with wet hands.
EN - 8
Pull the plug to disconnect the machine from the
mains, never pull on the cord.
EN - 9
When positioning the machine, place it in
an area where dishes can be easily loaded
and unloaded. Do not put the machine in
an area where the ambient temperature
falls below 0°C.
Read all warnings located on the packaging
before removing the packaging and
positioning the machine.
Place the machine close to a water tap
and drain. Take into consideration that the
connections will not be altered once the
machine is in position.
Do not hold the machine by its door or
panel.
Leave an adequate distance around the
machine to allow ease of movement when
cleaning.
Ensure the water inlet and outlet
hoses are not squeezed or trapped
and that the machine does not stand on the
electrical cable while positioning.
Adjust the feet so the machine is level and
balanced. The machine should be placed
and the door of the machine will not close
properly.
Please install the decorative panel
as indicated on the assembly sheet.
Otherwise, the door may not open properly
and steam leakage problem may occur.
inlet supply in order to prevent damage to
your machine due to contamination (sand,
rust, etc.) from indoor plumbing. This will
also help prevent yellowing and deposit
formation after washing.
Note printing on the water inlet hose!
If models are marked with 25°, the water
temperature may be max. 25 °C (cold
water).
For all other models:
Cold water preferred; hot water max.
temperature 60 °C.
WARNING: Use the new water inlet
hose supplied with your machine, do not
use an old machine’s hose.
WARNING: Run water through the
new hose before connecting.
WARNING: Connect the hose
directly to the water inlet tap. The pressure
supplied by the tap should be a minimum
of 0.03 MPa and a maximum of 1 MPa. If
the pressure exceeds 1 MPa, a pressure
connection.
WARNING: After the connections are
made, turn the tap on fully and check
An Aquastop water spout is available
with some models. Do not damage it
or allow it to become kinked or
twisted.
EN - 10
Connect the water drain hose directly to
water drain hole or to the sink outlet spigot.
This connection should be minimum 50
dishwasher is placed.
Items will not wash
properly if a drain hose longer than 4 m
is used.
WARNING: Your machine is set to
operate at 220-240 V. If the mains
voltage supply to your machine is 110
3000 W between the electrical connection.
