Swann DVR4-9*50 Guida rapida

www.swannsecurity.comSwann Communications • Toll Free Technical Support: USA - 1-800-627-2799, Australia - 1300 13 8324 • Email: tech@swannsecurity.com

.com

DVR4-950 - Easy Setup Guide

BCamera Connections

Connect the camera

cables to the extension

cables

1Connect all power ends

of extension cables to

the power splitters

Connect power

splitter to camera

power adapters

Plug in camera power

adapters and DVR

adapter to outlets

Connect the RCA

adapters into the

camera inputs

on the back of

the DVR

Connect the RCA

to BNC adapters

to the other end

of the extension

cables

SR344-DPS-50010-290509

Easy Set Up Components

RCA Cable

Power Adapter

Cable

Remote

Control

DVR Power

Adapter

DVR4-950 Unit

Connecting the DVR to LCD

Connect the other end of the

RCA cable to the DVR’s video

port marked video output

Connect the monitor input cables to

AV1 or AV2 on the side of the monitor

Connect the monitor input

cables to the RCA cable

Cameras and Accessories

Monitor Input

Cables x 2

LCD

LCD Power

Supply
