• Monitor & Record 4 areas

Monitor & record up to 4 cameras located around your office, home or industrial premises.

Replaces time lapse VCR and quad processor.

• Motion Detection

Set up to only record events, rather than continuous recording of still image (eg: empty room).

• Audio

Supports one camera with Audio or separate Microphone.

eg. Monitor customer service transactions in retail stores

• Other Features

Multiple search - By time, date, alarm, or event list.

Event search - eg. What happened yesterday at 2pm in reception?

Zoom & Picture in Picture.

www.swannsecurity.com

Enquiries: [email protected]

Product Code: SW-R-DVR4

Home/Office Security System

4 Channel Digital Video Recorder

With Motion Detection and Audio

Monitoring & Recording

• Record evidence of theft, shoplifting, and accidents to take to the police.

• Set and forget, records continuously the past months activities from 4 cameras, no tapes required!

Common Scenarios

• Who drove the car that day?

• Who started that fight?

• Who's been going into my office?

• Who's using the photocopier/printer for personal use?

• Who's been stealing from the stationary cabinet?

• What time did the cleaner arrive & leave?

• Who's the neighborhood thief/vandal?

Home/Office Security System

4 Channel Digital Video Recorder

With Motion Detection and Audio

Technical Specifications

Video Format: NTSC/EIA or PAL/CCIR

HDD Supported: IDE type, UDMA 66, upto 250 GB

HDD supported

Recording Mode: Manual / Alarm / Timer / Motion

Camera Input Signal: Composite video signal 1Vp-p

(BNC) 4 channels

Main Monitor Output: Composite video signal 1Vp-p (BNC)

Call Monitor Output: Composite video signal 1Vp-p (BNC)

Audio Input: 4 audio inputs, (RCA)

Audio Output: 2 audio outputs from one

at a time, (RCA)

Motion Detect Area: 16 x 12 targets per camera

Motion Detect: 99 Levels

Video Loss Detection: Yes

Monitoring Speed: Up to 100 images/sec. for PAL

Recording Speed: Up to 25 images/sec. for PAL

Dwell Time: Programmable (1~15 Sec)

Picture in Picture: Yes (Movable)

Key Lock: Yes

Camera Title: 8 letters

Video Adjustable: Hue/ Colour/ Contrast/

Brightness Adjustable

Alarm Input: TTL input, Hi (5V),

Low (GND)

Alarm Output: COM./N.O/N.C

Remote Control: RS-232 or RS-485

Power Source: (19VDC) PSU Supplied -

Can Operate off 12VDC

Operating Power: <32W

Operation Temperature: 10 ~ 40ºC

Dimensions (mm): 343(W) x 223(L) x 59(H)

Net Weight: 2.05 Kg

Package Contents

DVR

Hard Drive Tray & Key

Power Adaptor

Power Cable

6 x BNC to RCA Adaptors

Instructional Manual (Manual only available in English)

Molex Power Clip

www.swannsecurity.com

Please note that the information

contained within this document is

subject to change without notification.
