INPUT SELECTS

Select your TV or VCR manufacturer from the list below. It will show you the common locations of

that manufacturer’s input select options.

If you are still not able to see your footage, you may need to verify that all your hookup connections

are correct. Please select which system you are connecting to from the main customer service page.

Admiral

Bell and Howell

Broksonic

Citizen

Craig

Crosley

Curtis Mathis

Daewood

Electrohome

Emerson

Fisher

Funai

General Electric

Goldstar

Hitachi

JC Penney

JVC

LXI / Sears

Magnavox

Magnasonic

Memorex

MGA

Mitsubishi

Montgomery Ward

NEC

Optimus

Orion

Panasonic

Philco

Philips

Proscan

Quasar

Radio Shack

RCA

Realistic

Samsung

Sansui

Sanyo

Scott

Sears / LXI

Sharp

Shintom

Signature 2000

Sony

Sylvania

Symphonic

Teac

Teknika

Toshiba

Westinghouse

XR1000

Zenith

Other Brands

Admiral

--------------------------------------------------------------------------------

Admiral TV’s

1 .Aux channel located below channel 2 (might have to auto-program channels with Nintendo 64 ON)

2. Press MENU, choose SOURCE, switch the source to AUX

3. SOURCE INDEX button on remote

4. Channel 91

Admiral VCRs

1. Aux channel below channel 2

2. INPUT button on remote

Admiral TV/VCR Combos

• Aux channel below channel 2

Bell and Howell

--------------------------------------------------------------------------------

Bell and Howell TVs

1. Press SOURCE or MENU, choose INPUT, select either VIDEO or VCR/AUX.

Bell and Howell VCRs

1. Aux channel below channel 2

2. INPUT button on remote

3. TUNER button inside front panel on VCR

Broksonic

--------------------------------------------------------------------------------

Broksonic TVs

1. TV/VIDEO button on the front of TV

Broksonic VCRs

1. Input switches to the AV inputs when in VCR mode.

2. Aux channel below channel 2.

3. Play a movie to switch to Inputs.

Broksonic TVVCR Combo‘s

1. Input switches automatically to the AV inputs when in VCR mode.

Citizen

--------------------------------------------------------------------------------

Citizen TVs

1. TV/VIDEO button on the front of the TV or on the remote

2. Channel 91 or 00

3. Press MENU, then choose SOURCE

Citizen VCRs

1. Input switches automatically to the AV inputs when in VCR mode

2. Aux or Line channel below channel 2

Citizen TVVCR Combos

• Automatically switches or Aux channel below channel 2

Craig

--------------------------------------------------------------------------------

Craig TVs

• Either TV/VIDEO or TV/AV button on the front of the TV

Craig VCRs

• Switches automatically when in VCR mode or Aux channel below 2

Crosley

--------------------------------------------------------------------------------

Crosley TVs

• Press MENU or DISPLAY, select INPUT or TV/AUX, switch to appropriate input.

Crosley VCRs

1. Aux channel below 2

2. Press MENU, choose VCR SETUP, select TV/AV, switch to AV

Crosley TV/VCR Combos

•Aux channel below 2

Curtis Mathis

--------------------------------------------------------------------------------

Curtis Mathis TVs

1. Press DISPLAY until you reach Tuner/Aux, choose AUX

2. Aux channel below 2 or channel 91

Curtis Mathis VCRs

1. Press AUX or INPUT on remote

2. Aux or Line channel below 2

3. Press MENU, choose SOURCE, switch to LINE

Daewood

--------------------------------------------------------------------------------

Daewood TVs

• INPUT or TV/AV button on remote.

Daewood VCRs

1. INPUT button on remote.

2. INPUT or TV/LINE button on TV or remote.

3. Press MENU, select SOURCE, choose AUXILIARY.

Daewood TV/VCR Combos

• TV/LINE on remote.

Electrohome

--------------------------------------------------------------------------------

Electrohome TVs

• INPUT or EXT button in front panel of TV.

Electrohome VCRs

1. INPUT or EXT button in front panel or on remote.

2. TUNER/LINE button in front panel or on remote.

Emerson

--------------------------------------------------------------------------------

Emerson TVs

• TV/VIDEO button on the TV (AV cables usually have to be unplugged to get cable restored)

Emerson VCRs

• Emerson VCR Note: Some Emerson VCRs have a switch on the back that needs to be set to STD for

the AV inputs to work.

1. Automatically switches to the AV inputs when it’s in VCR mode

2. INPUT SELECT or TU/AV button on remote

3. Band selector switch on VCR labeled either TUNER/LINE or TUNER/CAMERA

4. Channel 90, 91, or 92

Emerson TV/VCR Combos

Automatically switches to the AV inputs when it’s in VCR mode

INPUT SELECT button on remote

Fisher

--------------------------------------------------------------------------------

Fisher TV

Fisher TVs Note: The majority of Fisher TVs use the Volume + and - keys to select menu options.

1. TV/VIDEO, Video Mode, or TV/VCR button on the television.

2. Press MENU, choose FEATURE SETUP, then choose INPUT and switch to AV or VIDEO

3. Press MENU, choose INPUT, and switch to AV or VIDEO

4. Input switches automatically when AV cables are plugged in

Fisher VCRs

1. INPUT button on remote

2. INPUT, TUNER/EXT or AUDIO/VIDEO (either a button or a switch) in the front panel of the VCR

3. Input switches automatically when AV cables are plugged in and it’s in VCR mode

4. Aux channel below 2

5. VCR must be on channel 3

Funai

--------------------------------------------------------------------------------

Funai TVs

• Aux channel below 2

Funai VCRs

1. Aux channel below 2

2. Input switches automatically when the AV cables are plugged in, and it‘s in VCR mode

3. Either a TUNER/LINE, TUNER/AV, or TUNER/EXT switch behind front panel on VCR

4. INPUT button on remote

5. VCR on channel 3

Funai TV/VCR Combos

1. Aux channel below 2

2. Press the MONITOR or INPUT SELECT button on the front of the TV. Choose AV.

General Electric (GE)

--------------------------------------------------------------------------------

GE TVs

1. Channel 91, 92, or 00

2. INPUT button on remote

3. Press MENU, choose VIDEO, then choose VHS

4. TV/VIDEO button on the front of the TV

GE VCRs

1. INPUT button on remote or front of the VCR

2. Aux or Video channel below 2

3. A Switch behind the front panel labeled TUNER/LINE, TUNER/SIMUL/LINE or TV/INPUT.

Set to either LINE or INPUT

GE TV/VCR Combos

1. INPUT button on remote

2. Aux channel below 2 or channel 00

Goldstar

--------------------------------------------------------------------------------

Goldstar TVs

1. TV/VIDEO, TV/AV, or TV/CATV/AV button on remote. Set to either VIDEO or AV

2. TV/VIDEO button inside front panel of TV

3. Press FUNCTION on TV or remote. Then select VIDEO

Goldstar VCRs

1. TU/AV or TV/AV on remote

2. Press MENU, choose either TUNER or TUNING BAND, then choose SOURCE SELECT, then choose AV.

3. Either a TUNER/LINE or TV/LINE switch in the front panel.

4. Input switches automatically when the AV cables are plugged in and it’s in VCR mode 5.

Line or AV button in front panel or on remote

Goldstar TV/VCR Combos

1. Press TUNER/LINE on the TV or remote

2. TV/CATV/AV or just an AV button on remote

Hitachi

--------------------------------------------------------------------------------

Hitachi TVs

1. AVX or AUX button on TV or remote

2. FUNCTION, MODE, INPUT, or AUX button on the front of the TV (sometimes behind hidden panel)

3. Channel 91 or an Aux channel below 2

Hitachi VCRs

1. Aux or Line channel located below 2

2. AVX or AUX button on remote (occasionally it’s located behind a hidden panel on the VCR)

3. Channel 91

4. Press INPUT in the VCR‘s front panel .

Hitachi TV/VCR Combos

• INPUT button on remote

JC Penney

--------------------------------------------------------------------------------

All JC Penney TVs and VCRs are manufactured by other companies (RCA, JVC, Emerson, etc.) If the following

information doesn’t get you going, look for the manufacturer‘s name on the back of the TV or VCR. If you’re

unable to find it, JC Penney can let you know who the manufacturer is, as long as you have the model number

handy. JC Penney TV’s

• TV/VIDEO button on the front of the TV

JC Penney VCRs

1. Aux channel below 2

2. Input switches automatically when the AV cables are plugged in, and it‘s in VCR mode

3. Press MENU, choose VCR SETUP, then choose INPUT, switch to LINE or VIDEO

4. Input or TU/AV button on remote

JC Penney TV/VCR Combos

• INPUT button on remote

JVC

--------------------------------------------------------------------------------

JVC TVs

1. TV/VIDEO button either on the TV or remote

2. Press FUNCTION until you reach TV/VIDEO and switch to VIDEO

3. Press MENU until you reach INPUT and switch to either VIDEO or VHS

4. INPUT button on remote

JVC VCRs

• With JVC VCRs, there are frequently two sets of inputs, front and rear. They are not labeled “Input 1

and 2”. To determine which set is activated, you need to go through the menu to either FUNCTION or

TUNER SETUP, choose AUX, and then you can see or select FRONT or REAR.

1. Aux channel below 2

2. Press MENU or FUNCTION, choose TV/VIDEO of TV/AUX, then choose either VIDEO or AUX

3. TUNER/AUX or INPUT SELECT button in hidden panel on VCR

4. TU/AV or INPUT SELECT button on remote

JVC TV/VCR Combos

1. Switches automatically

2. Press MENU, choose TV/VIDEO and switch to VIDEO

LXI / Sears

--------------------------------------------------------------------------------

All Sears TVs and VCRs are manufactured by other companies (RCA, JVC, Emerson, etc.) If the follow-

ing information doesn’t get you going, look for the manufacturer‘s name on the back of the TV or VCR. If

you’re unable to find it, Sears can let you know who the manufacturer is, as long as you have the model

number handy.

Sears TVs

1. TV/AV, TV/VIDEO or INPUT in THE front panel onthe TV or on the remote.

2. Channel 91 or 00 (might have to auto-program TV with the Nintendo 64 turned ON,

or use the channel edit feature in the menu)

3. Press MENU or SETUP, choose SOURCE, select AV

Sears VCRs

• Many Sears VCRs have a button labelled “channel lock” that needs to be turned off in order to channel

up or down on the VCR.

1. Aux or Line channel below 2 or channel 00.

2. TU(SC)AV or INPUT button in the front panel Oof the TV or on remote

3. TUNER/LINE or TUNER/AUX button in front panel or on remote

Magnasonic

--------------------------------------------------------------------------------

Magnasonic VCRs

1. Aux channel below 2.

2. TV/AV or TUNER/LINE in front panel or on remote.

Magnavox

--------------------------------------------------------------------------------

Magnavox TVs

• The majority of Magnavox TVs use the Volume up and down keys to select menu options.

1. Press MENU or DISPLAY, choose INPUT or ANTENNA, and switch from ANTENNA/CABLE

or TUNER to AUX

2. Press MENU or DISPLAY, then choose AUX

3. Press MENU or DISPLAY, choose TUNING FEATURES, then choose PICTURE SOURCE or

SOURCE SELECT and switch to AUX

4. Aux channel below 2

5. Press STATUS, choose INPUT or ANTENNA, switch to AUX

6. TV/VCR or INPUT button on remote toggles between channels 3, 4, and AUX

Magnavox VCRs

1. AUX or LINE channel below 2

2. Press MENU, choose INPUT, switch to either AUX, LINE or AV

3. Press MENU, choose VCR SETUP, select INPUT, and switch to LINE or AV

4. INPUT, TUNER/LINE, or TUNER/AUX switch behind hidden panel or on remote

Magnavox TV/VCR Combos

1. AUX channel below 2 or channel 00.

2. INPUT on remote

3. Channel 91 or 92

Memorex

--------------------------------------------------------------------------------

Memorex TVs

1. Aux channel below lowest numbered channel.

2. INPUT SELECT switch inside front panel. Switch to AV.

Memorex VCRs

1. Aux channel below 2

2. INPUT or TU/AV button on remote.

MGA

--------------------------------------------------------------------------------

MGA TVs

• TV/EXT button inside front panel or on remote.

MGA VCRs

• TV/VIDEO or TUNER/EXT button inside front panel or on remote

Mitsubishi

--------------------------------------------------------------------------------

Mitsubishi TVs

• Some models have a HOME THEATER setting which will lock out the inputs. Turn the HOME THEAT-

ER setting OFF to allow the inputs to be used.

1. INPUT SELECT or TV/EXT button on the front of the TV

2. INPUT SELECT, TV/EXT, TV/VIDEO, or AUX button on remote

Mitsubishi VCRs

1. INPUT SELECTor TV/VIDEO on remote or front panel

2. Aux or Ext channel below 2

3. TV/EXT, TUNER/EXT, or TUNER/CAMERA button in front panel

Mitsubishi TV/VCR Combos

• Aux channel below 2

Montgomery Ward

--------------------------------------------------------------------------------

• All Montgomery Ward TVs and VCRs are manufactured by other companies (RCA, JVC, Emerson, etc.)

If the following information doesn’t get you going, look for the manufacturer‘s name on the back of the

TV or VCR. If you’re unable to find it, Montgomery Ward can let you know who the manufacturer is, as

long as you have the model number handy.

Montgomery Ward TVs

1. TV/VIDEO or VIDEO ON/VIDEO OFF on the TV or remote.

2. Aux channel below 2 or channel 00.

3. Press MENU or DISPLAY, then choose AUX from the menu options.

Montgomery Ward VCRs

1. Input switches automatically when it‘s in VCR mode.

2. Aux channel below 2.

3. Input button in front panel or on remote.

Montgomery Ward TV/VCR Combos

• TUNER/AV button inside front panel.

NEC

--------------------------------------------------------------------------------

NEC TVs

1. TV/VIDEO on TV or remote.

2. INPUT SELECT button on remote.

NEC VCRs

1. Press INPUT or AUX on the front of the VCR or remote.

2. TV/SIMUL/LINE switch in front panel. Switch to LINE.

Optimus

--------------------------------------------------------------------------------

Optimus VCRs

1. AUX or INPUT button on remote.

2. Press MENU, select SETUP VCR, then INPUT SELECT, then choose LINE.

3. Aux channel below 2

Optimus TV/VCR Combos

1. Menu button on remote, choose TV, INPUT SELECT, then switch from TUNER to LINE

Orion

--------------------------------------------------------------------------------

Orion TVs

1. Press TV/AV button on remote

Orion VCRs

1. Input switches automatically when it‘s in VCR mode.

2. INPUT button on remote

Orion TV/VCR Combos

1. Input switches automatically.

2. TV/MONITOR button in front panel or on remote.

Panasonic

--------------------------------------------------------------------------------

Panasonic TVs

• Panasonic has a feature to their newer TVs called GAME GUARD. Game Guard is a function that

blocks all incoming signals from channels 3, 4 and the AV inputs. The purpose is to allow parents to

prevent their children from playing video games. If you have this feature enabled, you must turn it OFFin

order to play your video games.

1. TV/VIDEO button behind front panel or remote

2. INPUT or ACTION button on front panel or remote, then choose appropriate input.

Altri manuali per DIY Security Cam SW211-DSC

Indice

Altri manuali Swann Telecamera di sicurezza

Swann

Swann CoreCam Manuale utente

Swann

Swann Eye HD SWADS-460CAM Manuale utente

Swann

Swann MicroCam II Manuale utente

Swann

Swann Big Dome Deterrent Manuale utente

Swann

Swann PTZ INTERNAL Speed Dome Manuale utente

Swann

Swann IP-3G ConnectCam 1000 Manuale utente

Swann

Swann PRO-770 Manuale utente

Swann

Swann MaxiBrite SW212-MXD Manuale utente

Swann

Swann OutdoorCam SW244-AUO Manuale utente

Swann

Swann PRO-780 Manuale utente

Swann

Swann BulletCam Manuale utente

Swann

Swann PRO-771 Manuale utente

Swann

Swann NHD-816 Manuale utente

Swann

Swann PRO-series Manuale utente

Swann

Swann MicroCam III Manuale utente

Swann

Swann S243-4NU Manuale utente

Swann

Swann Maxi-Brite Cam Manuale utente

Swann

Swann Night Hawk Extra Wireless Outdoor Camera Manuale utente

Swann

Swann SWIFI-2KOCAM-EU Manuale utente

Swann

Swann SWIFI-ALERTCAM Manuale utente

Swann

Swann NHD-819 Manuale utente

Swann

Swann Dummy PIR Camera Manuale utente

Swann

Swann NHD-POE Series Manuale utente

Swann

Swann Black & White Dome Cam Manuale utente

Manuali Telecamera di sicurezza popolari di altre marche

Okina USA

Okina USA SIR36-870VF650LP Manuale utente

Divio

Divio NDR155PA Manuale utente

Canon

Canon VB-C500D Manuale utente

Easy Access

Easy Access EasyGuard Manuale utente

Vivotek

Vivotek FD9389-EHV-v2 Manuale utente

TUYA

TUYA COSMO W2 Manuale utente

Eusso

Eusso UNC7500-IR Guida all'installazione

urmet domus

urmet domus 1096/204 Manuale utente

VC VC20 series Manuale utente

Axis

Axis Q1614 Manuale utente

ieGeek

ieGeek DD201 Manuale utente

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuale utente

Vicon

Vicon V662-D-1 Istruzioni operative

Grundig

Grundig GCH-K0274P Manuale utente

Lorex

Lorex VANTAGE LBC7032 Manuale utente

4xem

4xem WPT Manuale utente

Samsung

Samsung SCV-3082 Manuale utente

Vitek

Vitek VTC-C544 Manuale utente
