Swann NHD-817 Manuale utente

Pan-Tilt-Zoom

Super HD Dome Camera

For use with Swann 7300 Series HD NVRs

EN INSTRUCTION MANUAL

Important instructions

1. Make sure your camera is fixed correctly and

stable if fastened in place.

2. Only use the supplied power adapter (48V).

3. Do not manually pan and tilt your camera when

it is turned on as it may damage the internal com-

ponents.

4. Never place strain of any kind on the network

cable connection. It’s designed to clip into place to

prevent slippage, but it won’t support any weight

and can be easily broken by a sharp tug.

5. The audio input requires a powered or amplified

microphone or audio source to work correctly.

6. The earth connection is optional. For added

safety from lightning strikes and or power surges,

screw this to a metal surface or object.

7. To perform a factory reset, disconnect the pow-

er input, hold down the reset button, reconnect

the power input and continue holding the button

for at least 20 seconds then release.

8. This camera can only be used with Swann’s

NVR-7300 Series HD Network Video Recorders.

9. Have a look at page 6 for instructions on how to

control your camera.

Please note: Have a look at the camera location

tips included with your NVR, to select the best lo-

cation for your camera.

Important note: All jurisdictions have specific

laws and regulations relating to the use of cam-

eras. Before using any camera for any purpose,

it is the buyer’s responsibility to be aware of all

applicable laws and regulations that prohibit or

limit the use of cameras.

Introduction

Connecting your Dome Camera

AUDIO

OUT

eS ATA

LAN

VGA

HDMI

DC 48V USB

1 3 5 7

2 4 6 8

Power Input

Audio Input LAN

Reset

The earth connection is optional. For added safety

from lightning strikes and or power surges, screw

this to a metal surface or object.

NVR-7300

Ethernet cable connects

to the camera inputs on

the NVR and the power

input connects to the

power adapter.

Connect both of these

to the camera cable.

Connect the power cable

to a spare wall socket.

Earth

Ethernet & Power Cable

Connect this to the

power input on the

Ethernet cable.

Wall Mount

The camera cable is

attached to the dome

camera via one data

and one power cable

(as indicated by the

arrows). Gently dis-

connect both cables

when removing the

wall mount.

Dome Camera

Camera Cable

Power Adapter

Installing the Wall Mount

1. The wall mount can be mounted onto a flat ver-

tical surface and must be of sufficient strength

to hold your camera.

2. For wooden surfaces, screw the wall mount

directly to the surface. For masonry surfaces

(brick or concrete) you’ll need to use the wall

plugs.

3. Position the wall mount in the location you

want to mount it. Make sure the location is rigid

to prevent vibration.

4. Using the appropriate screws for the surface

you’re mounting to, screw the wall mount into

place (use the top mounting holes first). Make

sure the wall mount is aligned straight, other-

wise the image will appear on an angle.

5. To gain access to the bottom two mounting

holes without obstruction, use a Phillips head

screwdriver to temporarily remove your dome

camera from the wall mount. Be careful as the

camera cable is connected to your dome camera

via one data and one power cable. Gently discon-

nect both cables (see illustration on page 2).

6. Screw the two remaining screws to the bottom

mounting holes to fasten into place.

7. Reattach the data and power cable to the rel-

evant connections on your dome camera then

screw the camera back onto the wall mount.

Make sure the rubber seal is sitting flush within

the groove of the camera casing and make sure

all the screws are securely fastened.

8. You’re now ready to use your dome camera.

For instructions on how to use your camera, go

to page 6 - Controlling your Dome Camera.

Installing the Ceiling Mounting Kit

1. The ceiling mounting kit consists of a ceil-

ing mount, cylinder pipe and a camera mount.

To use this, you need to remove the wall mount

first. Use a Phillips head screwdriver to remove

your dome camera from the wall mount.

2. The camera cable is attached to your dome

camera via one data and one power cable. Gently

disconnect both cables and remove the camera

cable from the wall mount (see illustration on

page 2).

3. Screw the cylinder pipe to the ceiling mount

(make sure the connection is tight) and feed the

cable from the ceiling mount through the cylin-

der pipe.

4. Drill a hole in the ceiling at the desired loca-

tion and feed the camera connections inside the

ceiling (make sure the hole is big enough to fit all

the connections). Using the appropriate screws

for the surface you are mounting to, screw the

ceiling mount in place (make sure the location is

rigid to prevent vibration).

5. You’re now ready to attach the camera mount

to the cylinder pipe. Feed the data and power

cable through the top of the camera mount and

reattach them to the relevant connections on

your dome camera (don’t force the connections

as they only attach the one way). Make sure the

rubber seal is sitting flush within the groove of

the camera casing.

6. Screw the camera mount to your dome cam-

era then secure the camera mount to the cylin-

der pipe. Make sure all the screws are securely

fastened.

Controlling your Dome Camera

To control your camera, use the mouse and click

the channel the camera is connected to. Click the

“PTZ” button on the camera toolbar. The PTZ con-

trols will appear on-screen (as shown above).

1. Click the directional buttons to move your cam-

era in the direction selected.

2. This determines how fast the camera will move.

The lower the number the slower your camera

will move (this does not affect the speed when the

camera is in Patrol mode).

3. Click to zoom into an object and to control the

level of focus (the “Iris” controls are not available).

To access the PTZ menu, right-click the mouse (as

seen above).

Controlling your Dome Camera (cont.)

7. Click this to select a different channel.

8. Click this to select a different Preset position.

9. Click this to select a different Patrol mode.

10 (4). Click this to access the Preset menu, go to

page 8 - Creating a Preset.

11 (5). Patrol mode instructs the DVR to automati-

cally move the camera according to the Preset po-

sitions that have been created. Click this to access

the Patrol menu, go to page 9 - Creating a Patrol.

12. Click this to hide the PTZ controls. Click again

to return.

13 (6). Click this to exit. You will be taken back to

the default Live View mode.

Creating a Preset

1. Use the PTZ controls to move your camera to

the desired focal position. Zoom and Focus can

also be used.

2. Click “Preset” to access the Preset menu then

click the first Preset slot available.

4. Click “Set” to save (will change from No to Yes).

5. Click “OK” to exit.

Repeat the above steps to create multiple Preset

positions by changing the Preset slot for each Pre-

set that you want to create.

Call: Select a saved Preset slot then click to move

the camera to the Preset position.

Clear All: Click to clear all Preset slots.

Clear: Click to clear a selected Preset slot.

4 5

Creating a Patrol

1. Click “Patrol” to access the Patrol menu.

2. Click the first Preset slot available.

3. Click “Set” then select from one of the available

Preset positions that you created. Adjust the “Du-

ration” and “Speed” (some experimentation may

be required) then click “OK”.

Repeat the above steps to add multiple Preset

positions. Select a different Preset slot for each

Preset that you want to add.

4. When finished, click “Add” to add each Preset

to the Patrol.

5. Click “OK” to confirm then right-click to exit.

Click “Start” to enter Patrol mode.

43 5

Limited Warranty - Terms & Conditions

Swann Communications warrants this product

against defects in workmanship and material for

a period of one (1) year from its original purchase

date. You must present your receipt as proof of

purchase for warranty validation. Any unit which

proves defective during the stated period will be

repaired without charge for parts or labour or re-

placed at the sole discretion of Swann. The end

user is responsible for all freight charges incurred

to send the product to Swann’s repair centres. The

end user is responsible for all shipping costs in-

curred when shipping from and to any country

other than the country of origin.

The warranty does not cover any incidental, acci-

dental or consequential damages arising from the

use of or the inability to use this product. Any costs

associated with the fitting or removal of this prod-

uct by a tradesman or other person or any other

costs associated with its use are the responsibility

of the end user. This warranty applies to the origi-

nal purchaser of the product only and is not trans-

ferable to any third party. Unauthorized end user

or third party modifications to any component will

render all warranties void. By law some countries

do not allow limitations on certain exclusions in

this warranty. Where applicable by local laws,

regulations and legal rights will take precedence.

For Australia: Our goods come with guarantees

which cannot be excluded under Australian Con-

sumer Law. You are entitled to a replacement

or refund for a major failure and for compensa-

tion for any other reasonably foreseeable loss or

damage. You are also entitled to have the goods

repaired or replaced if the goods fail to be of ac-

ceptable quality.
