Swann RedAlert SW242-WBW Manuale utente

Product Code: SW242-WBW

www.swannsecurity.com Monitoring Kits & Recording

• Portable & discreet for covert surveillance

• Motion triggers still photos or 10 second video clips at 3 second intervals

• Built-in PIP (Picture In Picture) feature allows you to see 1 wired & 1

wireless camera simultaneously on your monitor

• Built-in 4-channel wireless receiver matches the channels used by

Swann wireless cameras and receivers; choose the right channel for best

reception

• Easy to connect wireless or wired cameras, records 1 camera at a time

MONITORING

Warranty

month

RedAlert™ Security Kit

Movement Video Recorder

Records movement while you are away or distracted

DRAFT Sees in the Dark

Up to 30ft (9m)

SD Memory Card

Store over

(10 seconds each)

2000 images or 250 AVI Clips

128MB

www.swannsecurity.com

Please note that the information

contained within this document is

subject to change without notification.

MONITORING

DVR Technical Specifications Package Contents

Safeguard

Loved Ones

Deter

Shoplifters

Monitor

the Kids

Screen

Visitors

• BlueAlert™

• Antenna

• Wireless Camera

• AV Cables x 2

• RCA to BNC Adapter

• SD Card (128MB)

• Manual

• Easy Setup Guide

• Power Supply

• Bonus Security Stickers x 4

• Size: 3” x 2” (80mm x 55mm)

• 2-Channel Input (1 wired / 1 wireless)

• Wireless option offers 4 frequencies for

added flexibility

• Built-in PIP (Picture In Picture) feature

• Video format: AVI (10 seconds each)

• Image format: JPEG

• Built-in memory 16MB

• Video output to TV

• Preset NTSC or PAL TV system input

RoHS Compliant

2002/95/EC

RoHS

† Depends on local conditions.

Use with any Swann security camera except IP cameras

Channel Indicator Video In On/Off

AV Out DC Power

SD Card Slot Channel Set

Front View Rear View

BlueAlert™

Movement Video Recorder

Records movement while you are away or distracted

• Channels: 2414, 2432, 2450, 2468MHz

• Power Supply: 8V DC 200mA

• Power Consumption: 65-110mA

• Size: 2” x 1¾” (54 x 43mm)

• Antenna: Omni-directional

• Transmitting Range: Up to 150ft (50m)*

• Weight: 7¾oz (220 grams)

• Operating Temperature: 32° - 122°F ~ (0° - 50°C)

• Sensor: 1/3” (8.5mm) Color CMOS

• Horizontal Resolution: 380TV Lines

• Minimum Illumination: 1 Lux @ f1.2

• Lens: 7/32” (5.6mm) 60°

CameraTechnical Specifications
