SWEEX GC800 Manuale utente
English version
2
Quick Install Guide for Sweex PCIegraphic cards
Hardware Installation
1. Make sure the computer is turned off and that there is no power connected.
2. Also remove the printer and monitor cable, because these have their own power supply.
3. Now unscrew the computer casing.
4. Make sure that you undo yourself of possible static electricity. This can be done by grabbing a (naked) central heating pipe or
an unpainted water pipe. Pay attention not to use a magnetic screwdriver. Briefly touch the iron frame of the PC casing. Avoid
direct contact with the contact points of the PCIeslot and contact points on the graphics card.
5. Locate a free PCIeslot and remove the metal protection plate that is in the computer casing for the intended slot. Consult the
manual of your computer to find the PCIeslot.
Place the card in the PCIeslot. (Your PCIe slot may look different)
Make sure the card is securely fastened
English version
3
6. When possible fasten the card with screws so it can not move.
7. When the card is mounted successfully, check if the other cards are still fitted properly in their expansion slot. It can happen
that when a new card is added the other cards rise a little with as result that the card, or even the entire computer, may not
work.
8. Close the computer casing and reconnect all cables properly.
9. Turn on the computer.
Software installation
On the CD-ROM we place the most recent drivers that are available whilst making this CD-ROM.It is possible that when you buy
this product new drivers are available for your card. The most recent drivers can be found on www.nvidia.com/drivers.
After starting the computer the graphics card will automatically be detected. Windows will ask for drivers of the card. Choose
cancel installation.
Place the Sweex CD-ROM in the computer. The CD-ROM will start automatically and display a menu. Choose install drivers.
Warranty
For all Sweex products a warranty period of 2 years applies. We do not give support or warranty on supplied software,
rechargeable batteries and batteries. Transaction of warranty only takes place at the sales point where the product is bought.
All brand names and associated rights mentioned in this manual are and stay property of the rightful owner.
