Switel M550 Manuale utente

Mobile Phone

Operating Instructions

M550

Operating Instructions 3. . . . . . . . . . . .

Declaration of Conformity 95. . . . . . . . .

HAC Hearing Aid Compatible

to M3 / T3 Rating

The M550 Phone has a built in Induction Coil and is

hearing aid compatible.

To ensure optimum benefit, users with hearing aids

may wish to select the T setting on their hearing aids.

Contents

1 Quick Start Guide 4. . . . . . . . . . . . . .

2 At a Glance 16. . . . . . . . . . . . . . . . . .

3 How does it work 20. . . . . . . . . . . . . . .

4 Getting Started 24. . . . . . . . . . . . . . . .

5 Phone Book Set Up 29. . . . . . . . . . . . .

6 Making and Receiving Calls 35. . . . . . .

7 Calls List 39. . . . . . . . . . . . . . . . . . . .

8 SMS − Text Messages 40. . . . . . . . . . .

9 Voice Mail 45. . . . . . . . . . . . . . . . . . .

10 Other Useful Features 47. . . . . . . . . . .

11 SIM Tool Kit 67. . . . . . . . . . . . . . . . . .

12 Menu Structure 68. . . . . . . . . . . . . . . .

13 Trouble Shooting 77. . . . . . . . . . . . . . .

14 Technical Properties 80. . . . . . . . . . . .

15 Safety Information 84. . . . . . . . . . . . . .

16 Maintenance / Guarantee 89. . . . . . . . .

17 Index 91. . . . . . . . . . . . . . . . . . . . . . .

Quick Start Guide

1 Quick Start Guide

Important: Before you start, please read the

safety information on page 84.

Quick Glance

1 LED

2 Earpiece

3 Display

4 Navigation keys (scroll up/down)

5 Softkey, left

6 Call key

7 One−touch dialling keys

8 Star key / Ringer On/Off − Silent Mode

9 Softkey, right

10 On/Off key / End call key

11 Keypad

12 Hash key

13 Microphone

14 Charge contacts

15 Mini USB socket

16 Headset socket (Headset not supplied)

Quick Start Guide

What is in the box

The package contains:

1 mobile phone 1 desktop charging unit

1 li−ion battery 1 operating manual

1 AC adaptor

Installing the SIM card

Risk of swallowing small objects!

The SIM card can be removed.

Small children can swallow them.

Switch the phone off.

Pay attention that the SIM card is not bent or

scratched. Prevent any contact with water, dirt

or electrical charges.

Slide the mobile phone’s

battery compartment cover

towards the bottom using a

little force. Lift the battery

compartment cover off the

phone completely.

If there is already a battery

inside, remove it.

Quick Start Guide

Your telephone number is carried by the SIM

card, not the phone. Therefore if you use a

SIM card you had in a previous phone, you will

keep the same phone number.

Slide the SIM card with the

golden contacts facing

down in the SIM card

holder provided for it at the

top right. The SIM card

must be located under the

metal retaining bar to be in

the correct position.

Insert the battery. The

golden contacts on the bat-

tery must face towards the

top left. Press lightly on the

bottom end of the battery

until it snaps into place.

Quick Start Guide

Replace the battery com-

partment cover back on

the phone. Slide the bat-

tery compartment cover

upwards until it snaps in to

place.

Charging the battery

Before starting to charge the battery, check

that it has been installed properly.

Do not remove the battery while it is being

charged. This could damage the phone.

When charging the battery for the first time, it

should be charged for at least 4 hours. Some

batteries only reach their full capacity after se-

veral complete charge/discharge cycles.

Charging via the mini USB socket

Plug the power adapter in the

mini USB port.

Quick Start Guide

Connect the power adapter

plug as illustrated in the dia-

gram. For safety reasons,

only use the power adapter

plug supplied.

Charging via the desktop charging unit

Plug the power adapter in the

mini USB socket on the charg-

ing unit. Insert the phone in

the charging unit to charge it.

The display will go blank but even so the bat-

tery is still being charged. This is correct ope-

ration.

It may take a few seconds before the phone in-

dicates the charging process.

You can use the phone during the charging

process.

Battery status warning

The current battery charge status is indicated in the

display as follows:

Full Half empty Low Empty

Mains power

outlet

Quick Start Guide

When the battery charge is low, a corresponding

warning message appears in the display.

Charge the battery.

In cases where the battery charge is extremely low, it

is possible that the back−lighting no longer works and

certain functions are no longer available.

When the battery charge drops below the minimum

status, the phone switches off automatically.

Switching the mobile phone on and off

3 sec. Switch the mobile phone on

3 sec. Switch the mobile phone off

Some SIM cards will require you to enter a PIN

code. Follow the prompts on the screen or
