Sylvania SMP1050 Manuale utente
Your Pocket Guide
Digital Audio Player
SMP1050
m
ic
PLAY
REC
Get Connected
Transfer Music
Plug Your Ears & Enjoy
SMP1050
1
2
3
4 - 6
7
8 - 9
10
11
12
13
14 - 15
16
17
What’s in the box?
System Requirement
Synchronize songs to the player
Transfer
Know Your Player Well
Music Playback
Edit Lyrics
Repeat Mode & EQ Mode
Record & Voice Playback
Settings
Technical Data
Trouble Shooting
2
What’s in the box?
Digital Audio Player
Earphone
Your Pocket Guide
USB Cable
What’s in the box?
CD-ROM containing:
Media player driver for
Windows® 98
1 x AAA 1.5V Battery
ALKALINE BATTERY
m
i
c
PLAY
REC
Your Pocket Guide
Digital Audio Player
SMP1050
mic
PLAY
REC
Get Connected
Transfer Music
Plug Your Ears & Enjoy
/ / /
Windows® 98 2000 XP Vista
Pentium Class or faster Processor
CD-ROM Drive
64MB RAM
30MB free hard disk space
USB Port
3
You’ll need a computer with:
System Requirement
For Windows® 98 users, please install the driver in the CD-ROM before downloading any files to your player.
Synchronize songs to the player
You can use Windows Media Player 10 on Windows® XP SP2
to synchronize music which are downloaded from Internet legally and validly with license to the player.
If the song is downloaded illegally without license, it cannot be synchronized.
4
Step 2:
A dialog box will appear, choose
,
and click to proceed.
Plug the player to the USB port of your PC.
Synchronize media
files to this device using Windows Media Player
OK
Step 1: Set the Online Device of the player as Media Device
before plugging it to your PC.
Push the MODE button leftwards / rightwards to select
on the main menu, then press the MODE button to enter
its sub-menu.
Push the MODE button rightwards to select ,
and press the MODE button to enter its options list.
Then push the MODE button leftwards / rightwards to select
, and press the MODE button to confirm.
SYS
Online Device
Media Device
MSC RPLREC SYS
Synchronize songs to the player
Step 3: Windows Media Player will find device automatically.
And after a while, a dialog box of will appear,
choose and click .
Device Setup
Manual Finish
Step 4: Windows Media Player will be operating.
Drag and drop your downloaded songs into its Sync List,
and press . Then the songs will be
synchronized to the player.
Start Sync
5
Synchronize songs to the player
Synchronize songs to the player
Step 5: The synchronized music can be found in the player.
Click into on the desktop, and you can see
an Audio Device named as ,
click into it to view your synchronized songs.
Step 6: If you want to remove the MTP device, you can
just unplug the player from your PC. Then you will
see disappear.
When you successfully synchronize music to the player,
the current time shown on your PC will be synchronized to
the player, too.
You can select to go into
(on the sub-menu of ) to check it.
My Computer
Actions Mtp Device 000001
Actions Mtp Device 000001
DRM Time
SYS
6
Get Your Player Connected & Transfer
Transfer
Step 1:
Then plug this player to the USB port of your PC.
Once the connection is successfully made,
the window would pop up.
Try re-connecting the player if it doesn't
appear.
Set the Online Device of the player as USB Disk
(Refer to Page 4).
Removable Disk
Step 2:
Drag and drop your audio files into the
removable disk.
You can create any folder or directory in
the removable disk.
Close the removable disk window and
disconnect the player from your PC after
the data transfer.
7
8
Right View
Left View
Vol+ button
Vol- button
HOLD
MODE button
HOLD switch
Back ViewFront View
m
ic
PLAY
REC
Play/Pause
button
Earphone jack
Microphone
USB port
Battery
compartment
REC button
