Synology DS620slim Manuale
Synology NAS DS620slim
Hardware Installation Guide
Table of Contents
Chapter 1: Before You Start
Package Contents 3
Synology NAS at a Glance 4
Specications 5
Safety Instructions 6
Optional Accessories 7
Chapter 2: Hardware Setup
Tools and Parts for Drive Installation 8
Install Drives 8
Add a RAM Module on Synology NAS 10
Start Up Your Synology NAS 12
LED Indicator Table 13
Chapter 3: System Maintenance
Replace the Malfunctioning Fan 14
Chapter 4: Install DSM on Synology NAS
Install DSM with Web Assistant 15
Learn More 15
Synology_HIG_DS620slim_20181226
2
Thank you for purchasing this Synology product! Before setting up your new Synology NAS, please check the
package contents to verify that you have received the items below. Also, make sure to read the safety instructions
carefully to avoid harming yourself or damaging your Synology NAS.
Note: All images below are for illustrative purposes only, and may dier from the actual product.
Package Contents
Main unit x 1 AC power cord x 1
AC power adapter x 1
Screws for 2.5” hard drives x 14 Hard drive tray key x 2 RJ-45 LAN cable x 2
Before You Start 1
3
Chapter
4Chapter 1: Before You Start
Synology NAS at a Glance
No. Article Name Location Description
1Status Indicator
Front Panel
Displays the status of the system. For more information, see "LED Indicator
Table".
2Alert Indicator Displays warnings regarding fan or temperature. For more information, see
"LED Indicator Table".
3Power Button
1. Press to power on the Synology NAS.
2. To power o the Synology NAS, press and hold until you hear a beep sound
and the Power LED starts blinking.
4LAN Indicator Displays the status of the network connection. For more information, see
"LED Indicator Table".
5Drive Status Indicator Displays the status of the installed drive. For more information, see "LED
Indicator Table".
6Drive Tray Lock Lock or unlock drive trays.
7Drive Tray Install drives (hard disk drives or solid state drives) here.
8Power Port
Back Panel
Connect the AC power cord here.
9LAN Port Connect network cables here.
10 Kensington
Security Slot Attach a Kensington security lock here.
11 RESET Button
1. Press and hold until you hear a beep sound to restore the default IP address,
DNS server, and passwords for the admin account.
2. Press and hold until you hear a beep sound, then press and hold again until
you hear three beep sounds to return the Synology NAS to “Not Installed”
status so that DiskStation Manager (DSM) can be reinstalled.
12 USB 3.0 Ports Connect external drives or other USB devices to the Synology NAS here.
13 Fan Disposes of excess heat and cools the system. If the fan malfunctions, the
Synology NAS will emit a beeping sound.
Item DS620slim
Compatible Drive Type 2.5" SATA x 6
Maximum Internal Raw Capacity 30TB (6 x 5TB hard drives)
External Ports USB 3.0 x 2
LAN Ports 1GbE (RJ-45) x 2
Size (H x W x D) (mm) 121 x 151 x 175
Weight (kg) 1.4
Supported Clients • Windows 7 and 10
• Mac OS X 10.11 onward
File Systems • Internal: Btrfs, ext4
• External: Btrfs, ext4, ext3, FAT, NTFS, HFS+, exFAT1
Supported RAID Types
• Basic • JBOD • RAID 0 • RAID 1
• RAID 5 • RAID 6 • RAID 10
• Synology Hybrid RAID (2-Disk Fault Tolerance)
Agency Certications • FCC Class B • CE Class B • BSMI Class B
HDD Hibernation Yes
Scheduled Power On/O Yes
Wake on LAN Yes
Language Localization
Environment Requirements
• Line voltage: 100V to 240V AC
• Frequency: 50/60Hz
•Operating Temperature: 32 to 104˚F (0 to 40˚C)
•Storage Temperature: -5 to 140˚F (-20 to 60˚C)
• Relative Humidity: 5% to 95% RH
Note: Model specications are subject to change without notice. Please refer to www.synology.com for the latest information.
Specications
5
Appendix
1Support for exFAT can be enabled by purchasing and downloading exFAT Access in Package Center.
6Chapter 1: Before You Start
Safety Instructions
Keep away from direct sunlight and away from chemicals. Make sure the environment does not
experience abrupt changes in temperature or humidity.
Place the product right side up at all times.
Do not place near any liquids.
Before cleaning, unplug the power cord. Wipe with damp paper towels. Do not use chemical or
aerosol cleaners.
To prevent the unit from falling over, do not place on carts or any unstable surfaces.
The power cord must plug in to the correct supply voltage. Make sure that the supplied AC voltage is
correct and stable.
To remove all electrical current from the device, ensure that all power cords are disconnected from
the power source.
Risk of explosion if battery is replaced with an incorrect type. Dispose of used batteries appropriately.
7Chapter 1: Before You Start
Optional Accessories
With Synology accessories, you can customize your Synology NAS to t dierent business environments without
worrying about compatibility and stability. Visit www.synology.com/compatibility for more information.
•Memory Module
Model Name Picture Description
D3NS1866L-4G
D3NS1866L-4G
DDR3L-1866 unbuered SO-DIMM
204pin 1.35V
•Spare Part
Model Name Picture Description
2.5" Disk Tray (D1) 2.5" HDD Tray for DS slim Series
Fan 80*80*20_4
System Fan DS slim Series
Adapter 65W_2 Adapter 65W Level VI
Tools and Parts for Drive Installation
• A screwdriver
• At least one 2.5” SATA drive (please visit www.synology.com for compatible drive models)
Warning: If you install a drive that contains data, the system will format the drive and erase all existing data. Please
back up any important data before installation.
Install Drives
1 Pull and remove one of the drive trays.
2 Place a drive in the drive tray and tighten the screws provided to secure the drive in place, as illustrated below.
Hardware Setup 2
Chapter
8
9Chapter 2: Hardware Setup
3 Insert the loaded drive tray into the empty drive bay.
Important: Make sure the drive tray is completely inserted. Otherwise, the drive might not function properly.
4 Repeat the steps above to install all prepared drives.
5 Drives are numbered as illustrated below.
Note: If you want to create a RAID volume, we recommend that all installed drives are of the same size to make the
best use of drive capacity.
10 Chapter 2: Hardware Setup
Add a RAM Module on Synology NAS
The optional Synology DDR3 RAM module is designed for Synology NAS memory expansion. Follow the steps
below to install, check, or remove a RAM module on your Synology NAS.
To install a RAM module:
1 Shut down your Synology NAS. Disconnect all cables connected to your Synology NAS to prevent any possible
damages.
2 The RAM modules are located at the bottom of DS620slim.
3 Remove the 4 screws that secure the bottom panel. Lift up the panel and place it to the side. You will see a
pre-installed 2G RAM module.
Important: When you remove the panel, the sensitive internal components are exposed. Avoid touching anything
other than the memory assembly when you remove or add a memory module.
4 Insert the new memory module into the slot:
a Align the notch on the gold edge of the module with the notch in the slot.
b Tilt the card and insert the module into the slot. Make sure the module is properly inserted.
c Push down on the memory module with moderate pressure until you hear a click.
Note:
• Hold the memory module by its edges, and do not touch the gold connectors.
• Synology will not provide complete product warranty or technical support if non-Synology RAM modules are used
for memory upgrade.
