SystemBase sLAN/all Manuale utente
User Manual
www.sysbas.com
sLAN/all
Version 1.1.1 2018/06/11
1
Revision History
Revision Date
Document
Version
Pages
Description
March. 6. 2017
1.0
All
New
June. 11. 2018
1.1
24-25
RS-422 Multi-Drop Mode Added
sWiFi/all User Manual
2
Contents
1. Preface 4
About This Manual 4
To Our Readers 4
Documents Related to sLAN/all 4
Technical Support 5
2. Getting Started 6
Overview 6
Features 6
Applied Field 8
3. Hardware Specifications 10
Case and Connectors 10
LEDs 10
Serial Port Pin Specifications 11
Reset Tact Switch 11
4. Connecting Network 12
First-time Use 12
Before connecting 12
Making Connection 12
5. Configuration Web Page 14
Minimum Requirements 14
Login 14
Network Setting 15
Operation Setting 17
Serial Setting 20
Change ID and PW 22
Reboot 22
sWiFi/all User Manual
4
1. Preface
General sLAN/all, one of a serial converter device manufactured by SystemBase, related information is provided.
About This Manual
This manual explains the connection, communication, configuration, and other management operations with sLAN/all.
To Our Readers
This manual is written for users and network managers using sLAN/all. We recommend reading this manual before
using and configuring sLAN/all. The manual includes the details on utilizing the hardware and setting provided
software. This document should provide enough information regarding controlling and managing sLAN/all with its
connected devices.
Documents Related to sLAN/all
Technical documents related to sLAN/all are as follows.
All documents in our website is up-to-date. Contents of the documents may change without notice.
Document
Description
User Manual
sLAN/all hardware information, configuration, and management
COM Port Redirector
User Manual
Information regarding using COM Redirector by SystemBase
TestView User Manual
Information regarding using TestView
(a serial data testing utility for COM port, TCP, and UDP)
SGConfig Manual
Details on using utilities for configuring through the network
sLAN/all Spec Sheet
sLAN/all product specification
sLAN/all White Paper
Details on backgrounds, technology, and related market
sWiFi/all User Manual
5
Technical Support
SystemBase provides technical support through two methods below:
1. Send an e-mail to our technical support team at [email protected] to receive fast responses. Any questions,
requests, suggestions or comments are welcomed.
2. For instant response, call us. Our technical team will always provide detailed consultation and guides through a
simple phone call.
The phone number is: +82-2-855-0501 (ext. 233)
Available from Monday to Friday, 9:00 ~ 18:00 KST. We are closed on weekends and holidays.
sWiFi/all User Manual
6
2. Getting Started
This chapter provides an overview, function of sLAN/all, contents of package and applied field.
Overview
sLAN/all is a small converter allowing data transmission from serial (RS-232, RS-422, RS-485) to Ethernet.
The connection standard supports IEEE 802.3 10/100Base-TX. It has a standard DE9 connector to providing
maximum serial communication speed of 921.6kbps and RJ45 connector for Ethernet side with maximum 100Mbps
speed connection. A sLAN can be connected remotely to control, monitor any type of serial devices through the same
network.
Features
sLAN/all features are as follows:
- Maximum Serial Communication Speed: 921.6 kbps
- Support RS-232, RS422, and RS485
- 10/100 Mbps (Auto MDIX) Ethernet Port
- Virtual Serial Port Utility: COM Port Redirector
- Configure sLAN/all from a Web Browser
- Windows Utility for Configuration: SGConfig
sWiFi/all User Manual
7
Contents of Package
Please check if your package includes following:
1 Unit of sLAN/all Device
1 Unit of 5V DC Adaptor (or a Micro USB B Cable)
1 LAN Cable
1 sLAN/all Quick Manual (Paper Manual)
Class A equipment
Sellers or users should be aware of the fact that this device is intended for industrial use(Class A), not for
residential use.
sWiFi/all User Manual
8
Applied Field
sLAN/all can be applied in many areas. Some examples are shown below.
Serial Communication using Network
Serial devices can be used from a computer, if a computer and a sLAN/all device are connected through the network.
sLAN
Serial Tunneling
This allows the serial cable between a computer and a serial device to be extended through the network. This
makes the cable length limitless where there is a network nearby. To use this feature, please refer to Chapter 5
Configuration Web Page, and use either “TCP Server – TCP Client mode”, or “UDP Server – UDP Client mode”.
Only these two modes allow transmit and receive data for serial tunneling.
sLAN sLAN
sWiFi/all User Manual
9
COM Port Redirector
By using COM port redirector, a virtual COM port utility, sLAN/all serial port (on the network) can be used as a physical
serial port connected to a computer.
sLAN
Factory / Industry Automation
PLC, Robot Arms, Human-Machine Interface, Logistic Storage Conveyor Belt
Medical Equipment, Controllers on Inspection Equipment
Alarm Device, Biometric Sensors
Home Appliances / Electronics
Power Management Device, Game Console
Measuring Instrument, Gas Detector, Water/Pollution Detector
Devices for Data Collection and Distribution
Finances / Building Automation
Card Reader, Barcode Scanner, Kiosk, POS Devices
Serial Printer, ATM Machines, Credit Card Terminals
Security Devices
