T-Fal SENSOR 2 Manuale utente
Pressure Cooker
Olla de presión
Operating instructions
Instructivo de uso y seguridad
Realization : Axana Conception
oct 2001
Ref. : 4131493 For models/Para Modelos
3297/3298/3299/4230/4231/4232/4233/4207/4208/
3273/3274/4209
IMPORTANT SAFEGUARDS
When using pressure cookers, basic safety precautions should always be followed:
1 Read all instructions.
2 Do not touch hot surfaces. Use handles or knobs.
3 Close supervision is necessary when the pressure cooker is used
near children.
4 Do not place the pressure cooker in a heated oven.
5 Extreme caution must be used when moving a pressure cooker
containing hot liquids.
6 Do not use pressure cooker for other than intended use.
7 This appliance cooks under pressure. Improper use may result in a
scalding injury. Make certain unit is properly closed before opera-
ting. See “Operating instructions”.
8 Do not fill the unit over 2/3 full. When cooking foods that expand
during cooking such as rice or dried vegetables, do not fill the unit
over 1/2 full. See “Operating instructions”.
9 Do not cook foods such as applesauce, cranberries, pearl barley, oat-
meal or other cereals, split peas, noodles, macaroni, rhubarb, or spa-
ghetti. These foods tend to foam, froth, and sputter, and may block
the pressure release device.
10 Always check the pressure release devices for clogging before use.
11 Do not open the pressure cooker until the unit has cooled and inter-
nal pressure has been reduced. See “Operating instructions”.
12 Do not use this pressure cooker for pressure frying with oil.
13 Be sure that handles are assembled and fastened properly.
14 SAVE THESE INSTRUCTIONS
- Never use your appliance without liquid, as it could damage it severely.
- Always use at least 1 cup (250 ml) liquid in the pressure cooker.
- Be careful to use heat sources which are suitable to your pressure cooker.
• when using a gas burner: make sure that the flame is not higher than the
base of the appliance.
• when using an electric or radiant range: choose a cooking plate with a
diameter equal to or less than that of the appliance.
- Before placing the appliance onto a hotplate, ensure that the base of the cooker
is dry and thoroughly clean.
- After having cooked a type of meat that has an adhering skin (i.e. chicken) which
tends to swell when cooked in pressure cookers, do not puncture swollen skin
as you risk scalding yourself.
- In the case of starchy foods, slightly shake the pressure cooker before opening
the lid to avoid food splattering.
- When pressure has built up, avoid pointing the release device towards you as
the steam burst can be dangerous.
- Leave the safety systems alone, except for cleaning and maintenance in accor-
dance with instructions. In particular, never open the control panel.
- Use only T-Fal spare parts for your model.
GENERAL RECOMMENDATIONS
Sensor II USA 4131340 12/03/02 10:15 Page c2
1
2
3
4
5
6
7
8
9
10
11
Product diagram
Pressure Cooker models
Opening • Closing
Capacity
Using the pressure
regulator valve
Before using for the first time
Before cooking
During cooking
After cooking
Cleaning • Maintenance
T-Fal safety features
T-Fal answers your questions
Sensor II USA 4131340 12/03/02 10:15 Page 1
Product diagram
1
2
Safety valve
Steam outlet
Pressure regulator
valve
Locking indicator pin
Alignment hole
Cover handle
Pin housing
Gasket
Steaming basket*
Trivet*
Short pot
handle
Long pot handle
Pot
Stainless
steel cover
Steam plate*
*Option depending on model
Sensor II USA 4131340 12/03/02 10:15 Page 2
Bottom diameters
Compatible heat sources
■DIFFUSAL Stainless steel models can be used on:
■Enamel/Non-stick models can be used on:
■All other models can be used on:
■When using an electric stovetop, use a burner with the same diameter as the bottom of
the Pressure Cooker, or slightly smaller.
■When using a ceramic range top , make sure the bottom of the Pressure Cooker
is perfectly clean.
■When using gas, the flame should not exceed the diameter of the pot.
■Do not heat the pot when empty.
T-Fal accessories
■Please contact your T-Fal After-Sales Service Center if you need to change parts
or require pressure cooker repair.
■Only use genuine T-Fal parts to match your model.
Item identification
■Please record the following in the event that parts and/or servicing of your Pressure
Cooker is required :
■■Model/Item Number: .......................................................................................................
■■Capacity: ..........................................................................................................................
■■Date Purchased: ...............................................................................................................
■■Retailer Where Purchased: ..............................................................................................
■Retain retailer receipt.
GAS
ELECTRIC
GAS SEALED (solid) CERAMIC HALOGEN
GAS SEALED (solid) ELECTRIC
CERAMIC HALOGEN INDUCTION
Features
2
3
Diffusal
stainless steel Star Base
stainless steel Aluminum Aluminum
Enamel/non-stick Aluminum
Non-stick/non-stick
Base Ø Models Base Ø Models Base Ø Models Base Ø Models Base Ø Models
7 inches
7 inches
7 inches
3297
3298
3299
5.5 inches
5.5 inches
5.5 inches
4230
4231
4232 6.5 inches
6.5 inches 4207
4208 7 inches
7 inches 3273
3274
6.5 inches 4209
4.5 L
5 L
6 L
7,5 L
Sensor II USA 4131340 12/03/02 10:15 Page 3
Opening
3
4
■Hold the lower body handle with your left hand
and turn the upper cover handle to the right with
your right hand until it opens.
■Lift the cover.
■Place the cover on the pot, aligning the rims.
Align the triangle on the cover with the one on the
lower body handle.
■Turn the cover to the left until you hear it click.
This appliance cooks under pressure.
Improper use may result in a scalding injury.
Make certain unit is properly closed before
operating.
!
Closing
If you can’t close the cover:
■Check the position of the lock. If it is not in the
forward position, hold the cover horizontally and
push the lock toward you.
1
3
OPERATING INSTRUCTIONS
Sensor II USA 4131340 12/03/02 10:15 Page 4
Capacity
4
5
■Never use your Pressure Cooker without at least
1 cup (250 ml ) of liquid.
Steaming
■The minimum amount of water is 3 cups (750
ml).
■Place the steam accessory (steaming basket and
trivet or steam plate) on the bottom of the pot.
■Do not fill the unit over 2/3 full.
For certain foods
■When cooking foods that expand during cooking
such as rice or dried vegetables, do not fill the unit
over 1/2 full.
Maximum
filling
If the Pressure Cooker has been heated
without any liquid inside:
■Have your Pressure Cooker checked by an
Authorized T-Fal After-Sales Service Center.
1 cup
2/3
1/2
3 cups
Sensor II USA 4131340 12/03/02 10:15 Page 5
5
6
Using the pressure
regulator valve Cooking delicate foods
such as fish or desserts:
■Set the pressure regulator valve to 1.
Cooking meat and defrosting
■Set the pressure regulator valve to 2.
Releasing steam
■Set the pressure regulator valve to .
■Quick release: place the pressure cooker under
cold running water.
The steam is very hot when released from
the pressure regulator valve.
Removing the pressure regulator valve
■Press down on the center and turn the valve
to position 0.
■Lift off the pressure regulator valve.
Attaching the pressure regulator valve
■Position the pressure regulator valve by placing
the 0opposite the dot on the cover.
■Press it down then turn to the required position.
!
Sensor II USA 4131340 12/03/02 10:15 Page 6
6
7
Before using
for the first time
■Fill with water to 2/3 of the pot height.
■Close the Pressure Cooker.
■Set the pressure regulator valve to 2.
■Place the Pressure Cooker on the stovetop and set to maximum heat.
■When the pressure indicator pin rises, and steam begins to escape
from the valve, reduce the heat and wait for 15 minutes.
■After 15 minutes turn off the heat.
■Release steam by turning the pressure regulator valve to
or leaving the valve on 2 and putting your Pressure Cooker under
cold running water.
■When steam no longer comes from the steam outlet, and the
pressure indicator has dropped, open the Pressure Cooker.
■Rinse the Pressure Cooker with cold water and dry.
■For models with a non-stick coating, wipe the inside of the pot with
a little vegetable oil.
■Note: The appearance of stains on the inside bottom of the pot does
not affect the quality of the metal. These are marks left by hard water.
Use diluted vinegar and a scouring pad to remove them.
2/3
Sensor II USA 4131340 12/03/02 10:15 Page 7
7
8
Before cooking
■Before each use, check that the steam outlet is not clogged.
■Fit the pressure regulator valve.
■Set the pressure regulator valve as indicated in your recipe
(position 1or 2).
■Place the Pressure Cooker on the stovetop turned to a high setting.
As soon as the pressure indicator pin rises, you will be unable
to open the Pressure Cooker (never try to force it open).
■Cooking begins when the pressure regulator valve allows steady
release of steam, making a regular hissing noise.
!
If the pressure has not risen and no steam
is released from the valve :
■This is normal for the first few minutes.
■If this persists check that:
The heat setting is high enough, if not, turn it up.
There is enough liquid in the pot (see page 5).
The pressure regulator valve is set to position 1 or 2.
The Pressure Cooker is properly closed.
The gasket and the rim of the pot are not damaged.
If the pressure indicator pin has risen and no steam
is released from the valve :
■Put your Pressure Cooker under cold running water to
decompress.
■Clean the pressure regulator valve and the steam outlet.
Sensor II USA 4131340 12/03/02 10:15 Page 8
