Tailulu DS9H Manuale utente
7.5L Water Tank
Model: DS9H
HOME HUMIDIFIER
USER MANUAL
MAX
MIN
Auto Shut O
Night Light
3 Mist Settings
Time Setting
CUSTOMER SERVICE
Our cusromer sercice team is standing by to assist you
if you have any questions or concerns.
www.tailulu.com
suppor[email protected]
1-833-368-8825
CONTENT:
SAFETY NOTICE
PRODUCT OVERVIEW
BEFORE USING
CONTROL PANEL AND FUNCTIONS
HOW TO USE
USE THE HUMIDIFIER
MAINTENANCE
PRECAUTIONS
SPECIFICATIONS
TROUBLESHOOTING
1-833-368-8825
www.tailulu.com
01
03
04
05
06
07
08
10
13
13
Please read this manual carefully before using the appliance,
retain it for future use.
1 SAFETY NOTICE
1.To avoid electric shock, do not plug or unplug the power plug with wet hands.
2.Without prior authorization, do not dismantle, repair, or modify this product.
3. Do not cover the mist nozzle.
4.The power cable must not be knotted, damaged, crushed by heavy objects,
or changed in any way before use, as this might cause an electric shock,
short circuit, or re.
5.Do not detach the top of the water tank from the barrel during work, and do not
touch the water or any of the water tank's components.
6.Not suitable for outdoor use.
7.Unplug the power cord during thunderstorms or when not in use for long
periods of time.
8.To avoid damaging the internal electronic components, do not ip the machine
over while it is turned on or with water inside.
1-833-368-8825
www.tailulu.com
9.This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision orinstruction concerning use of the
appliance in a safe way and understand the hazards involved.
10.If there is any abnormal phenomenon in the use of the product, please unplug
the power plug immediately and contact the after-sales service.
11. Do not add essential oils to the humidier to prevent the humidier from being
corroded by essential oils.
Note: The schematic diagrams of goods, accessories, user interfaces,
and other items in this manual are for reference only.
Due to product updates and upgrades, the actual product may be
slightly dierent from the schematic diagram, please refer to the
actual product.
1-833-368-8825
www.tailulu.com
2 PRODUCT OVERVIEW
1-833-368-8825
www.tailulu.com
Water tank
Adapters
Switch base
Humiddvation
Unit Cover
Mist outlet
Inner cover
Top cover
Air outlet
Buoys
3 BEFORE USING
Open the package lift the top cover module, take out the power adapter from
the bucket, put back the top cover module,water tank is stuck.
Remove the top cover Take out the adapter Reset successfully
Tip: Please remove the cover rst and take out the adapter in
the water tank before you use the item.
1-833-368-8825
www.tailulu.com
Open
ADD WATER:
1. Place humidier on a solid and smooth surface, remove the water tank cover.
2. Fill the tank with water.
3. Do not exceed the max capacity mark.
4. Do not ll water from the air outlet on top of the humidier.
5. Put the tank cap on, make sure all parts are fastened rmly, connect the
power and turn on the device.
4 CONTROL PANEL AND FUNCTIONS
1-833-368-8825
www.tailulu.com
Mist outlet
(Can’t add water here)
Water intake
Power on/o
Mist Function Timing Function
Light on/o
1-833-368-8825
www.tailulu.com
5 HOW TO USE
POWER ON:
Notice: Before connecting the humidier, check that the voltage
indicatd on the appliance matches the the local power supply voltage.
1. Plug the DC24V power on the back of the humidier and tum it on. At this time, the
power indicator lights up (about 0.1 seconds), indicating that the humidier is already
in power-on standby state.Press the "ON/OFF" button againcan turn o the humidier.
2.Press the "ON/OFF" button to switch on the humidier, the atomization starts, it is in
a continuous working state with high humidication speed.“H” indicator light lights up.
3. Press the " MIST" button to adjust the mist level (H,L,S ) and choose the most
comfortable one for you. If select "S" the humidier works for 10 seconds and stops for
10 seconds, which is ideal for sleeping.
4. Press the "TIME" button to pick the required operating time (2, 4, 8hours). Air
humidier shuts o automatically at the end of the selected period.
5. Press the "LIGHT" button to turn on/o the dreamy blue night light.
1-833-368-8825
www.tailulu.com
Tip:
The fan of the humidier will continue to run for 30 seconds, which
is normal after it is turned o. The purpose is to remove the residual
water mist in the water tank and ensure normal use next time
WATER SHORTAGE PROTECTION:
When the water reservoir is empty, the water shortage protection device will
automatically disconnect the atomizing circuit.The humidier turns o after night
light ashes 5 times.The machine can be used normally after adding water.
6. MAINTENANCE
1. Power o and unplug the humidier before cleaning.
2. Use a soft damp towel to clean the upper cover. The water tank can be cleaned
under the faucet and use the brush included.
3. Pull out with two index ngers to open the snap, then use your thumb to lift the
humidier cover up to separate the atomizer and the middle barrel. and use a towel
or brush to clean the interior.
