Takstar DA10 Manuale utente

使⽤⼿册User Manual

■Product

■Features

●

Combining microphone, power amplifier and speaker

together, suitable for speech, publicity, karaoke

Rear earth material speaker, light weight, excellent sound,

high volume, peak power 8W

One button to switch between MC mode and KTV mode,

easy operation

Wireless playing function without the trouble of cable

connection, more convenient to play music

Volume adjusting function to adjust the volume based on

the venue

Built-in DSP chip with the feedback rejecting function to

reject feedback effectively

Ultra-long standby, turning off automatically after no signal

input for 15 minutes to save the power consumption

High capacity Lithium battery for energy saving and

environmental protection, approximately 8h operation time

Compact design, comfortable to hold, suitable for

reinforcement and karaoke for a long time

Dear Customer,

Thank you for purchasing TAKSTAR DA10 speech microphone.

Please read the user manual carefully before operation and

keep it for reference in future. If you have any questions or

suggestions, please contact our local dealer.

DA 10 Speech Microphone

■Product content

DA 10 speech microphone………………………………………1 pc

Windscreen………………………………………………………1pc

Type-C charging cable…………………………………………1 pc

User manual………………………………………………………1 pc

■Specification

Specification

DA 10 Speech Microphone

Frequency Response: 100Hz-15kHz

Peak Power: 8W

Speaker Impedance: 4Ω

THD: THD≤5% 1KHz@4R,4W

S/N Ratio: 66dB (A-Weighted)@1W 4Ω (speech mode)

Bluetooth Version: 5.0

Reverb: Reverb

Operating Voltage: 3.4V-4.2V

Battery Type: Li-ion battery (18650)

Battery Capacity: 3.7V/2000mAh

Charging: DC5V 1.5A

Charging Time: apprpx.3h

Operation Time: approx.8h (speech)

Net Weight: approx. 220g

Dimension: Φ64mm*235mm (Dia*H)

■Application

Speech, publicity, karaoke, etc.

Cartridge: back electret

Polar Pattern: unidirectional

Frequency Response: 150Hz-16KHz

Sensitivity: -47.5±1.5dB(0dB=1V/Pa，at 1KHz)

Cartridge Specification

Note: The data is tested by Takstar Laboratory and Takstar has the

final interpretation right!

■Function

DA 10 Speech Microphone

④

⑤

⑥

⑦

⑧

①

②

③

①Power button: Keep pressing it for 2 seconds to turn on or

off the amplifier. If it is not used for 15 minutes, it will

automatically power off.

DA 10 Speech Microphone

② "M" button: Click it repeatedly to switch between the KTV

mode and the SPEECH mode. When it is switched to the

KTV mode, the wireless connection is turned on at the

same time, and when it is switched to the SPEECH mode,

the wireless connection is turned off.

③ Indicator light: If it keeps lighting up green during

operation, this means sufficient power supply. If the power

can last for less than 1h, it keeps lighting up red. It flashes

red when charged. If it keeps lighting up green, this means

it is fully charged.

④ "+" button: Click it to increase the volume of the amplifier.

A total of 3 levels of volume can be chosen.

⑤ "-" button: Click it to decrease the volume of the amplifier.

It can only be minimized to about 60% of the total volume.

There is no mute function.

⑥ Cartridge: When speaking, the mouth should be as close

as possible to the pickup, generally 3-5 cm. Do not cover

the cartridge with your hands; otherwise it will easily

produce feedback.

⑦ Charging interface: Connect to the Type-C charging cable.

Please use a charging head with a specification of 5V 1.5A

and 3C certification to charge the amplifier.

⑧ Speaker: Do not put the speaker too close to people's ears

to avoid hearing damaging. Please try to keep the speaker

clean.

Note: When the product is used for the first time, it is

recommended to fully charge it first; when it is fully charged,

please stop charging the battery to avoid overcharge; if it is

When the product is used for the first time, it needs to be

paired with a mobile phone or a wireless playing device. The

steps are as follows:

1. In the power-on state, click the mode button, and the

amplifier enters the searching and pairing state of wireless

playing;

2. Enter the "Settings" menu of the mobile phone, find the

option of wireless function, and turn on the wireless

playing function of the mobile phone. After searching for

"TAKSTAR DA10", click "TAKSTAR DA10" to connect. When

the amplifier can be played wirelessly, it means the

connection is successful.

3. The next time you switch to the KTV mode, if you have

already made a wireless connection, it will automatically

reconnect. In the case of a successful wireless connection, it

will be disconnected when switching to the SPEECH mode.

■ Wireless pairing method

DA 10 Speech Microphone

Holding diagram

not used for a long time, it needs to be charged once every six

months to avoid over discharge of the battery, which will

affect the battery performance.

■ Caution

In order to avoid possible personal injury or property

damage caused by electric shock, high temperature, fire,

radiation, explosion, mechanical hazards and improper use,

please read and observe the following items carefully before

using the product.

1. Please do not put the speaker close to people's ears to

avoid hearing damage.

2. If there is any abnormality (such as smoke, odor, etc.)

during use, please turn off the power switch and unplug the

power plug immediately, and then send the product to the

dealer for maintenance.

3. The product and accessories should be placed indoors in a

dry and ventilated place. Do not store them in a humid and

dusty environment for a long time. Avoid getting close to

fire, rain, water, excessive collision, throwing, vibrating the

machine and covering the ventilation holes during use, so

as not to damage its function.

4. When using the product, you must abide by the relevant

safety regulations. Please do not use the product in the

occasions that are clearly prohibited by laws and

regulations to avoid accidents.

5. Please do not disassemble, refit or repair the product by

yourself to prevent personal injury. If you have any

questions or service needs, please contact our local dealer

for follow-up.

DA 10 Speech Microphone
