Tanaka Power Sweeper Attachment TSW-210 Guida all'installazione
IllustrIllustr
IllustrIllustr
Illustraa
aa
ated Pted P
ted Pted P
ted Parar
arar
arts Mants Man
ts Mants Man
ts Manualual
ualual
ual
Model Number:
TWS-210
Power Sweeper Attachment
P/N 32403
Rev 000
Date 5-4-07
Nikko Tanaka Engineering U.S.A.,Ltd.• 1028 4th Street SW, Bldg B • Auburn, WA 98001 • Phone: (253) 333-1200 • Fax: (253) 333-1212
www.tanakapowerequipment.com [email protected]
www.tanakapowerequipment.com
PARTSINFORMATION
Page 1
TSW-210
POWER SWEEPER ATTACHMENT
9
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
1 32375 CASE,GEAR,SWEEPER 1
2 32369 PIN,CLEVIS,SWEEPER 2
3 32368 PIN,HITCH,SWEEPER 2
4 32367 PIN,COTTER,SWEEPER 2
5 32366 AXLE,DRUM,SWEEPER 2
6 32364 DRUM,SWEEPER 4
7 32365 CLIP,BELT,SWEEPER 12
8 32363 BELT,SWEEPER 4
9 32373 SPACER,24 TO 26mm 1
10 32372 PROTECTOR,TUBE,SWEEPER 1
