Tanita DC-360 Manuale utente

BODY COMPOSITION ANALYZER

DC-360

Instruction Manual

Please read this Instruction Manual carefully and keep it forfuture reference.

REMOTE DISPLAY VERSION COLUMN MOUNTED VERSION

Contents

Before Use

For Your Safety .........................................................4

Part names & Connection Procedure.......................8

Setting the Printer Paper / Setting an SD Card .....10

Power Supply..........................................................12

Settings...................................................................13

How to Use

Taking a Measurement...........................................15

Body Composition Mode............................................... 15

Measurement Results .................................................. 17

Scale Mode.................................................................. 19

Various Criteria.......................................................20

What is body fat percentage?....................................... 20

What is total body water percentage? .......................... 21

What is visceral fat rating?........................................... 21

What is basal metabolic rate (BMR)?............................ 22

What is metabolic age?................................................ 22

What is muscle mass? ................................................. 23

What is physique rating?.............................................. 23

What is bone mass?..................................................... 24

Output and Storage of Measurement Results .......25

If Necessary

Troubleshooting ......................................................31

Technical Notes ......................................................32

The Regression Formula for

Basal Metabolic Rate (BMR) ..................................36

Speciﬁcations .........................................................38

Before Use

For Your Safety

This section explains precautionary measures to be taken to avoid injury to the users of this device

and others, and to prevent damage to property. Please familiarize yourself with this information to

ensure safe operation of this equipment.

Warning Failure to follow instructions highlighted with this mark could result in

death or severe injury.

Caution Failure to follow instructions highlighted with this mark could result in

injury or damage to property.

This mark indicates actions that are prohibited.

This mark indicates instructions that must always be followed.

Warning

This equipment must not be used on subjects with pacemakers or other

mechanical implants.

This equipment passes a weak electrical current through the body which

could interfere with and cause the malfunction of electrical medical implants,

resulting in serious harm.

Do not handle the plug with wet hands.

This may result in electric shock, ﬁre, or leakage.

Do not modify this equipment in any way.

This can cause electric shock or injury, or affect the accuracy of analysis.

Do not use a multi-plug adapter.

This may cause ﬁre.

Keep this equipment away from ﬂammable gas and oxygen-rich

environments.

Prohibited

Before Use

Caution

Prohibited

Always…

Keep away from water.

Avoid using on subjects with metal allergies.

Allergic reactions may be caused by the stainless steel used in the electrodes of this device.

Do not jump on the equipment.

Do not lean on the equipment.

Do not use this equipment near other products that emit electromagnetic waves.

Do not insert ﬁngers into gaps or holes.

Do not apply force to the display.

The screen panel may break and cause injury.

Assist persons with disabilities or children under 15 years old.

A person who is familiar with the device should assist persons with disabilities or children under

15 years old who may not be able to take measurements alone.

Clean the scale platform with appropriate disinfectant after each use.

Stand clear of the subject during measurement to ensure accuracy.

Continually monitor both the subject and the equipment for anomalies.

If an anomaly in the subject or equipment is discovered,take appropriate action, such as stopping

the equipment, while ensuring the safety of the subject.

Use the included AC adapter.

Do not lean against the equipment.

Unplug the AC cord from the equipment when moving it.

Tighten the adjustable feet when moving the equipment.

Interpretation of analysis results (e.g. evaluation of measurements and formulation of

exercise programs based on results) must be performed by a professional.

Weight loss measures and exercise based on self-analysis could be harmful to your health.

Always follow the advice of a qualiﬁed professional.

Before Use

For Accurate Measurements

Avoid measuring after strenuous exercise.

This may cause inaccurate measurements. Please take measurements after sufﬁcient rest.

Avoid measuring after excessive food or ﬂuid intake or when dehydrated.

This may cause inaccurate measurements. For greater accuracy, avoid using directly after

waking up. Use at the same time on each occasion, at least three hours after a meal.

Ensure inner thighs are not touching each other during measurement.

If necessary, place a dry towel between thighs.

Do not take measurements while using transmitting devices, such as mobile phones, which may affect

readings.

Use the equipment under the same conditions and in the same position as much

as possible for accurate tracking of changes.

Readings are affected by the level of hydration and position of the body. Please use at the

same time of day each time, under the same conditions and in the same body position.

Avoid measuring in multiple locations with greatly differing temperatures.

This may cause inaccurate measurements. Allow the equipment to stand for at least

2 hours before using if it is moved to a new location with a temperature difference of

20℃or more.

Make sure the soles of feet are free of excess dirt, as this may block the mild electric current.

Bare feet should be placed correctly on the electrode platform.

Place arms straight down during measurement.

Use in a stable location.

Errors in measurements may occur if the device is used in an unstable location.

Do not wipe the equipment with corrosive chemicals (gasoline, cleaner, etc.). Please use a neutral

detergent to clean the equipment.

Before Use

Scheduled Maintenance

TANITA recommends that each facility conduct periodic checks of each unit.

1. Check the following at least daily:

• The unit is on a stable and level surface ie on a ﬁrm ﬂooring, not on a thick carpet

• Date and time settings

2. Visually inspect the following at least weekly:

• The display for any damage or contamination

• All cables, cords, and connector ends for damage or contamination

• All safety-related labeling for legibility

• All accessories (electrodes, etc.) for wear or damage

3. Visually inspect the following at least monthly:

• Mounting screws on stand

Update settings, replace items, or call for service as necessary according to the results of the visual

inspections. Do not use the unit if you see any signs of damage. Equipment that has been damaged

must be checked for proper operation by qualiﬁed personnel before using again.

Before Use

Part names & Connection Procedure

Symbols and their Meanings

Positive polarity Serial number

Alternating current Direct current

Input, Output

WEEE - Waste Electrical

and Electronic

Equipment Directives

Caution

Refer to the attached

notes.

For indoor use only

SD card See the instructions

Serial interface Manufacturer

*The SD logo is a registered trademark of the SD Association.

Remote display version Column mounted version

Control Box

Platform

Control box

Column

Accessories

This manual

AC adapter

AC cord

Printer paper

✓

Printer cover

Display

Operating key

DC jack for AC adapter

*RS-232C and USB-B are mutually exclusive.

RS-232C

USB-B

SD card slot

Adjustable feet x 4

Before Use

DC-360

Display and Keys

Meanings of the LED Indicators and Keys

Turn ON / OFF the power

Feeds the printer paper

Set various functions

Reset zero point

Set preset value

(Clothes weight)

Select measurement mode

Display Body Fat (percentage and mass)

*Not measured value but calculated value

Display Body Muscle (percentage and mass)

*Not measured value but calculated value

Display Body Water (percentage and mass)

*Not measured value but calculated value

Display Visceral

Fat Rating

Display Basal

Metabolic Rate

Indicates whether “Standard mode or Athletic

mode” is selected as the body type.

Indicates whether “Male or Female” is selected as

the gender

Enter the age between “5 to 99 years”

Enter the height between “90.0cm to 249.9cm”

Conﬁrms the entered numerical value.

Before Use

1010

Setting the Printer Paper /

Setting an SD Card

Setting the Printer Paper

(1) Turn the power OFF and push the

handle on the left hand side of the

controller.

(2) Open the printer cover.

(3) Set the printer paper in place.

Peel off the adhesive and pull out approximately

10cm of paper from the printer paper.

(4) Replace the printer cover to its

original place.

Press to turn on the device.

After all the indicators are displayed, is

displayed.

If the device is turned on with the printer cover open,

is displayed.

Press . The printer paper is cut

automatically, and the settings are

completed.

Paper is not automatically cut when ‘Auto Cut’ is set

to ‘Off’.

②

①

③

④

Cutting automatically setting →See P.13 setting4

Note

Before Use

1111

Setting an SD Card

When the power is turned OFF, insert

an SD card into the slot with the logo

side facing upwards.

Make sure the card is facing in the correct direction

when inserting it.

Press to turn on the device.

When the device detects the SD card,

the mark on the right appears in the

upper left corner of the screen.

Be sure to insert and remove the SD card when the

device power is off to avoid damaging the SD card.

Compatible with SD and SDHC memory cards

Not compatible with SDXC memory cards

Note
