Introduction

Congratulations on your purchase of the Targus USB

Mobile Port Replicator. This ultra portable expansion

module directly connects to a desktop or notebook

computer via a Universal Serial Bus (USB) port.

The port replicator provides the following ports:

•PS/2

®(two)

• RS232 serial

• Parallel (printer)

• High-speed USB 2.0 (two)

• RJ-45 Ethernet 10/100 Base T (Model PA095 only)

Contents

In addition to this user’s guide, the package contains:

• Targus USB Mobile Port Replicator

• 2-foot (60 cm) USB cable (A/B type) (Model PA075

only)

• Driver software CD

•ACpoweradapter

NOTE: The supplied AC power adapter is a universal

adapter that you can use in a 100 to 240 AC volt

outlet.

System Requirements

• USB 2.0 compliant port (When connected to a USB v1.1

upstream port, the Mobile Port Station's performance will

be less than optimal. For best results, connect it to a USB

2.0 port.)

•Windows

®2000/XP operating system

• CD-ROM Drive

WARNING: You must install the port replicator

software BEFORE connecting it to your computer.

Otherwise, the port replicator will not work properly.

Installing the Port Replicator

Drivers

1 Turn on your computer.

2 Insert the driver software CD into your computer’s CD-

ROM drive.

3 If setup does not begin automatically, click Start, Run,

then enter D:\Setup.exe (where D: is the path of your CD-

ROM drive) and then click OK.

The Welcome screen appears.

4ClickNext.

5 If you are running the Windows®XP operating system,

the Important Information screen appears. Click Next.

The Setup program begins installing the software

drivers.

NOTE: If you get a warning screen, please click

‘continue anyway’.

The Setup Complete screen appears.

6ClickFinish.

Connecting the Port Replicator

to Your Computer

After installing the port replicator drivers, you are ready to

connect the port replicator to your computer. To do this:

1 Turn off your computer.

2(Model PA095 only) Open the USB cable

compartment, located on the bottom of the port

replicator, and uncoil the cable.

3 Connect the supplied AC power adapter to the AC

power jack on the port replicator.

4 Plug the USB connector end of the USB cable into the

USB port of your computer.

5 Turn on your computer.

The following will configure automatically:

• Ethernet 10/100 (Model PA095 only)

• Serial Interface Controller

• USB Device (twice)

• Parallel Interface Controller

• PS/2 Adapter (twice)

This configuration process takes a few minutes. The

operating system does not prompt when configuration is

complete. Watch that all hardware devices are configured

before opening another application or connecting devices

to the port replicator.

NOTE: some hardware devices may prompt you for the

location of device drivers.

To install the drivers:

1 Select “Install the software automatically

(Recommended)” and click Next.

The Found New Hardware Wizard program begins

installing the hardware drivers.

The Completing the Found New Hardware Wizard

screen appears.

2ClickFinish and repeat as needed for each device.

3 Restart your computer.

When your computer restarts, the port replicator/dock

should be completely configured.

LED Status Indicator Lights

Once all device drivers are installed, the LED status

indicator lights glow and you can connect devices to the

port replicator. The LED lights display as follows:

• Hub Link light blinks green.

• Serial light glows green.

• Each PS/2 light flashes green when a device is first

connected or there is activity on the port.

• USB lights glow green when a USB device is attached.

(Model PA095 only)

• Tx/Rx light flashes green when data is transmitted to or

from the network.

• 100M light glows green when connected to a 100 Mbps

network.

NOTES: The Ethernet port is compatible with 100 Mbps

networks. however, the actual throughput is 10 Mbps

maximum when connected to a USB v1.1 port due to the

bandwidth limitation. The throughput may decrease as

additional devices are attached to the port replicator

regardless of whether the port replicator is attached

to a USB 1.1 or 2.0 port.

The port replicator supports hot swapping of the

network cable.

Connecting Devices to the Port

Replicator

When connecting new devices to the port replicator, you

may need to install additional software drivers. Consider the

following guidelines:

• The device drivers install automatically.

• When connecting a new device to the port replicator, you

must run the Setup or Install program for that device.

• When connecting a device to the port replicator, do not

force the cable connector into the port on the port

replicator, to avoid possible damage. If the cable

connector does not attach smoothly, turn the connector

over and try attaching it again.

Model PA095

Model PA075

AC PS/2

keyboard

PS/2

mouse

RS232 Parallel RJ-45

ethernetSerialpower

RS232 Serial Keyboard MouseParallel

PS/2 PS/2

PS/2 Port

To connect a PS/2 device, such as a mouse or keyboard,

plug it into a PS/2 port on the port replicator and begin

using the device.

Serial Port

Connecting and Configuring a Modem

To connect a serial modem:

1 Attach the cable connector to the serial port on the port

replicator.

2 Install the modem software driver according to the

instructions that come with the device.

3 When prompted to select the port, choose the Serial

USB (COMx), where xis the COM port number

assigned by your operating system.

Connecting a Handheld Computer

To connect a handheld computer:

1 Attach the cable connector to the serial port on the port

replicator.

2 Verify that the COM port setting, in either your

HotSync®or ActiveSync®software, matches the setting

on the port replicator. To verify the COM port setting on

the port replicator, refer to “Verifying Devices are

Installed” on page 11. To verify the COM port setting on

your handheld computer, refer to the documentation that

came with it.

Parallel Port

Connecting and Configuring a Printer for the First

Time

To connect a parallel printer:

1 Attach the cable connector to the parallel port on the

port replicator.

2 Install the printer software driver according to the

instructions that come with the device.

3 When prompted to select a port, choose PB1284-1

(USB port). If this port does not appear in the list,

choose the LPT1 port, complete the manufacturer’s

setup for your printer, and follow the instructions below

to redirect your printer.

Checking and Redirecting the Printer Port Settings

Follow these instructions to check the printer port settings

and redirect your printer from the LPT1 port to the PB1284-

1 (USB port) on the port replicator.

1 Unplug the printer cable from your computer and plug it

into the port replicator parallel port.

2 Select Start, Settings, and then Printers.

3 Right-click the printer device you are reassigning and

select Properties.

4 In the Printer Properties window, select Details or

Connection for the Printer. (Section titles vary, so check

your printer’s user manual for specific instructions.)

5 Change the setting to PB1284-1 (USB port) to redirect

printing to the port replicator.

(Model PA095 only) Ethernet Port

To connect an RJ-45 Ethernet cable, attach the cable

connector to the Ethernet port on the port replicator.

Additional procedures to connect to an actual network

depend on the type of network you are using. Contact your

network administrator for detailed instructions.

USB Port

To connect a USB device, plug it into a USB port on the

port replicator and follow the additional instructions

provided with the device.

Special Notes

Using a Device with the Port Replicator

When you connect a device to the USB Mobile Port

Replicator, you should be able to use it as you normally

would.

NOTE: devices that support custom programmability

or special features may not function properly. For

more information on using a device, refer to the

instructions provided with the device.

Global Suspend Mode

When your computer is in suspend mode, the port

replicator also enters suspend mode to avoid power

consumption. When your computer wakes up, the port

replicator wakes up automatically.

Product Limitations

General

The port replicator splits a single connection among a

variety of devices and connections. Some devices, which

use large amounts of bandwidth, such as printers and

digital cameras, can consume all available resources and

may interfere with the performance of other devices.

You may experience some temporary halting of some

devices when a high data transfer is occurring. For example,

your mouse may respond slowly while a graphic print job is

printing or while you are experiencing heavy network traffic.

We recommend the following guidelines:

• Do not transfer data to or from multiple high-speed

devices at the same time, such as a digital camera and

scanner.

• If speed degradation does occur, close other programs

that use a USB device to improve device performance.

Parallel Port

The parallel port is only compatible with printers and only

supports enhanced bi-directional printer features, such as

returning printer status. For best results, you should

connect high bandwidth external devices, which have a

parallel connection, such as a Zip®drive, directly to your

computer.

PS/2 Mouse and Keyboard

On the port replicator, a PS/2 mouse emulates a USB

mouse and a PS/2 keyboard emulates a USB keyboard.

This may result in a loss of enhanced features, such as

screen scrolling or programmable hot key features.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Targus Adattatore

Targus

Targus APM62US-02 Manuale utente

Targus

Targus Universal 70W Power Adapter Manuale utente

Targus

Targus ACA951 Manuale utente

Targus

Targus PA070U Manuale utente

Targus

Targus ACA934 Manuale utente

Targus

Targus ACA11EU Manuale utente

Targus

Targus ACA928EUZ Manuale utente

Targus

Targus ACA038US Manuale utente

Targus

Targus ACB20 Manuale utente

Targus

Targus APA01AP Manuale utente

Targus

Targus APA803 Manuale utente

Targus

Targus APA106 Manuale utente

Targus

Targus USB to Serial Digital Device Adapter Manuale utente

Targus

Targus CHILL MAT PLUS Manuale utente

Targus

Targus ACA932 Manuale utente

Targus

Targus 120 Watt Universal AC/DC Notebook Power... Manuale utente

Targus

Targus 120 Watt Universal AC/DC Notebook Power... Manuale utente

Targus

Targus Bluetooth 4.0 adapter Manuale utente

Targus

Targus APA803 Manuale utente

Targus

Targus Ultra-Mini Ultra-Mini Bluetooth 2.0 Adapter with... Manuale utente

Targus

Targus Travel Adapter Manuale utente

Targus

Targus Ultra-Mini Ultra-Mini Bluetooth 2.0 Adapter with... Manuale utente

Targus

Targus ACA958USZ Manuale utente

Targus

Targus APD10US Manuale utente

Manuali Adattatore popolari di altre marche

PCB Piezotronics

PCB Piezotronics 090B274 Manuale utente

Auvidea

Auvidea J20 Manuale del prodotto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuale utente

Akribis

Akribis ITF-21-BISS-MIT Manuale utente

Tenda

Tenda W54U Manuale utente

ROHO

ROHO AGILITY Manuale utente

PROLiNK

PROLiNK WN2001 Manuale utente

Hawking

Hawking HUF2 Manuale utente

Airlink101

Airlink101 AWLC4030 Manuale utente

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuale utente

Philips

Philips SWA4554S/10 Manuale utente

JVC

JVC TS-C9D2B Manuale di istruzioni

NETGEAR

NETGEAR A6100 Manuale utente

D-Link

D-Link DWA-121 Manuale utente

Philips

Philips SWA2037 Manuale utente

Basalte

Basalte 0610-20 Manuale utente

Yealink

Yealink EHS40 Manuale utente

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuale utente
