USER GUIDE
Visit our Website at www.targus.com Features and
specifications subject to change without notice.
© 2008 Targus Group International, Inc. and Targus, Inc.
AKM11US / 410-14-001A
Wireless
2.4GHz
Keyboard &
Mouse Combo
30
Introduction
Congratulations on your purchase of the Targus wireless
2.4 GHz keyboard and mouse combo. This keyboard/mouse
combo utilizes the latest wireless technology to eliminate
interference. Additionally, Free Smart Link technology
provides a plug-n-play experience.
Contents
•Targus Wireless Keyboard
• Targus Wireless Mouse
• USB Receiver
• 4 AAA Batteries (included)
• Software Driver CD
• User Guide
System Requirements
Hardware
• PC with an Intel® Pentium® processor or equivalent
• USB port
Operating System
• Windows® 2000/XP
• Windows Vista™
TARGUS WIRELESS 2.4 GHz
KEYBOARD & MOUSE COMBO
1
Targus wireless 2.4 GHz keyboard and mouse combo
Installing the Batteries
Wireless Keyboard
1 Remove the battery cover located on the bottom of the
keyboard.
2 Insert the supplied batteries, making sure that the positive
(+) and negative (-) ends of each battery match the polarity
indicators inside the battery compartment.
Removing the battery cover
2
Targus wireless 2.4 GHz keyboard and mouse combo
Optical Mouse
Removing the battery cover
1 Insert the supplied batteries, making sure that the positive
(+) and negative (-) ends of each battery match the polarity
indicators inside the battery compartment.
WARNINGS: WHEN REPLACING THE BATTERIES, YOU MAY USE ALKALINE OR
OTHER HEAVY-DUTY NIMH BATTERIES. NEVER COMBINE AN ALKALINE WITH
A NIMH BATTERY IN A DEVICE. AVOID MIXING NEW AND USED BATTERIES IN
A DEVICE.
2 Slide the battery cover back into position until it “clicks” firmly
into place.
The optical sensor, located on the bottom of the mouse should
glow red.
NOTE: THE MOUSE WILL OPERATE ON ONE BATTERY; USING TWO BATTERIES
WILL DOUBLE THE USAGE TIME.
3
Targus wireless 2.4 GHz keyboard and mouse combo
Establishing a Communications Link
Plug the USB receiver into an available USB port on your
computer.
NOTE: IT IS RECOMMENDED TO KEEP THE DEVICE(S) AT A DISTANCE OF LESS
THAN (6 FEET / 2 METERS) TO THE RECEIVER AT THE INITIAL CONNECTION.
• Press any key on the keyboard to connect.
• Move the mouse to automatically connect.
4
Targus wireless 2.4 GHz keyboard and mouse combo
Download the software driver (Model # AKM11) from the
official Targus web site: http://www.targus.com
Save the setup file to your computer and double click on the
icon to launch the installation process.
The Installation Wizard window will prompt.
Follow the on-screen instructions to complete the installation.
NOTE: THE DEVICE(S) CAN WORK WITHOUT INSTALLING THE SOFTWARE
DRIVER; HOWEVER, NOT ALL FUNCTIONS WILL BE AVAILABLE.
Installing the Software driver
The driver can be found on the CD-ROM (included)
or
Choose “Wireless Keyboard and Mouse” and click “Run
Setup”
5
Targus wireless 2.4 GHz keyboard and mouse combo
After the software driver is successfully installed, new icons
will show in the taskbar.
Double click on the “Keyboard Icon” to launch the key
configuration screen
There are 4 programmable “Hot Keys”. Click on the icons to
assign the new short-cut function.
Follow the on-screen instructions to setup the short-cut keys.
Keyboard Setup
Scroll LOCK - ON
CAP-LOCK - ON
Number LOCK - ON
6
Targus wireless 2.4 GHz keyboard and mouse combo
Using the Hot keys
Media keys
Key Function
Launch Default Media Program
Mute
Volume Up
Volume Down
Play / Pause
Stop
Key Function
Sleep
Default Internet browser
Default E-mail Program
Favorite
Calculator
My Computer
Internet and System keys
BY DEFAULT, THE HOT KEYS ARE PRESET AS FOLLOWS:
7
Targus wireless 2.4 GHz keyboard and mouse combo
Mouse Properties Setup
Double click on the “Mouse Icon” to launch the mouse
configuration screen
The side mouse buttons are programmable. Select the desired
pre-defined functions from the drop-down list and press Apply
to confirm.
Internet page forward
(programmable) Internet page backward
(programmable)
NOTE: BY DEFAULT, THE SIDE MOUSE BUTTONS ARE SET AS “INTERNET PAGE
FORWARD” AND “INTERNET PAGE BACKWARD”.
8
Targus wireless 2.4 GHz keyboard and mouse combo
Troubleshooting
• Check the receiver connection; try inserting the receiver
to another USB port on your computer.
• No connection between the device(s) and the receiver.
Re-insert the receiver. Remove and reinstall batteries.
9
