BRUSSELS HANNOVER BARCELONA TOKYO MILANO AMSTERDAM SINGAPORE LONDON PARIS NEW YORK LOS ANGELES TORONTO HONG KONG SYDNEY

Mini Trackball

Optical Mouse

USER’S GUIDE

Visit our Web site at: www.targus.com

400-0122-001B

MINI TRACKBALL

OPTICAL MOUSE

Introduction

Congratulations on your purchase of the Targus Mini Trackball

Optical Mouse. This ergonomically designed mouse connects

directly to your computer’s USB port and allows you to:

•Alternate between the trackball and mouse modes, which

ever best suits your needs

•Enhance your Internet browsing capabilities

•Quickly access program feature options supported under the

Windows®operating system

This user’s guide describes how to connect the mouse to your

computer, install the device drivers and personalize the mouse

features.

In addition to this guide, this package contains:

•Targus Mini Trackball Optical Mouse

•Driver software CD-ROM

System Requirements

To use the mouse, your computer must meet the following

hardware requirements and run one of the operating systems

listed.

Mini Trackball Optical Mouse

Hardware

• 64 MB RAM or higher, depending on the operating system

• CD-ROM drive

• USB version 1.1 port

Operating System

• Windows®Me/2000/XP

Connecting the Mouse

To connect the mouse to an available USB port, plug the

standard USB end of the cable into an available USB port on

your computer.

You are now ready to install the device drivers for your

operating system.

Installing the Device Drivers

To install the supplied device driver:

1 Turn on your computer.

2 Insert the driver software CD into your computer’s

CD-ROM drive.

3ClickStart, Run, then enter D:\Setup.exe (where D:

is the path of your CD-ROM drive) and then click OK.

The Welcome screen appears.

4 Follow the on-screen instructions.

5ClickFinish to complete the driver installation and restart

your computer.

Once your computer restarts, the mouse icon appears in the

system tray.

Mini Trackball Optical Mouse

Activating the Trackball Feature

The mouse’s default setting is mouse mode, where the

trackball functions as a standard scroll wheel.

To enable the trackball mode:

1 Press and hold down the middle mouse button (the

trackball) and the right mouse button at the same time.

2 Release both buttons.

You are now able to control your cursor by moving the

trackball while the mouse is stationary or held in your hand.

To disable the trackball mode:

1 Press and hold down the middle mouse button (the

trackball) and the left mouse button at the same time.

2 Release both buttons.

NOTE: Turning off your computer or disconnecting and

reconnecting the mouse automatically disables the trackball

mode.

Personalizing the Mouse Features

NOTE: You may have to remove previously installed mouse or

touchpad software from your computer to fully customize the

mouse features.

You can assign functions to the scroll ball and third mouse

button and control cursor movement by personalizing the

mouse features from the Mouse Properties screen. To do this:

1ClickStart, Settings and Control Panel.

2 Double-click the Mouse icon.

The Mouse Properties screen appears.

Mini Trackball Optical Mouse

Depending on your operating system, this screen has either

five, six or seven tabs with options for selecting and

controlling mouse features. To save any changes, click Apply.

NOTE: The following option tabs are for all supported

operating systems, except where indicated.

Buttons Tab

Button configuration — allows you to assign the primary

mouse button for right- or left-handed use.

Files and Folders (Windows®2000 only) — allows you to

assign the number of clicks that are required to open an item.

Double-click speed — adjusts how fast you have to click the

mouse button to register a double-click.

ClickLock (Windows®XP only) — allows you to drag an

icon without holding down the mouse button.

Pointers Tab

This tab allows you to choose how the mouse pointer looks on

the screen.

Pointer Options Tab (Windows®Me/XP)

Motion — adjusts the speed at which the pointer moves across

the screen.

Snap to — allows you to assign the pointer to jump to default

buttons in dialog boxes.

Visibility — allows you to display pointer trails, hide the

pointer while typing and show pointer location when Ctrl is

pressed.

Mini Trackball Optical Mouse

Wheel Tab (Windows®XP only)

This tab allows you to adjust the scrolling speed. Select the

number of lines that are scrolled at one time or select to scroll

one screen at a time.

Motion Tab (Windows®2000 only)

Speed — adjusts the speed at which the pointer moves across

the screen.

Acceleration — adjusts the acceleration rate for the pointer.

Snap to default — allows you to assign the pointer to jump to

default buttons in dialog boxes.

Hardware Tab (Windows®2000/XP)

Selecting the Hardware tab displays general information about

the mouse.

Scroll Ball Tab

Wheel Mode — allows you to choose between the following

modes:

• System default (Intelli-Mouse) mode – enabling this mode

simulates Microsoft®IntelliMouse®and supports features

used with Microsoft®applications, such as zoom, scrolling

and Auto-scrolling.

• Enhanced Scroll Mode – this mode supports all applications

that use scroll bars, with zoom, Auto-panning and scrolling

functions.

Vertical Axis Setting — allows you to adjust the following

features for up and down scroll ball movement.

• Reverse – allows you to turn the reverse mode on and off.

Mini Trackball Optical Mouse

• Scroll – adjusts the scrolling speed, per line of text. The

settings range is 1 (slow) to 10 (fast).

• Scroll one page per scroll unit – adjusts the scrolling speed,

per one page of text.

Horizontal Axis Setting — allows you to adjust the following

features for left and right scroll ball movement.

• Use for horizontal axis – enabling this feature allows for side

scroll ball movement.

• Reverse – allows you to turn the reverse mode on and off.

• Scroll – adjusts the scrolling speed, per line of text. The

settings range is 1 (slow) to 10 (fast).

• Scroll one page per scroll unit – adjusts the scrolling speed,

per one page of text.

• Use for application switch – enabling this option allows you

to use the scroll ball as a toggle button to alternate between

two or more active applications or tasks. Emulates the Alt +

Tab keyboard shortcut.

• Use for Web site switch – enabling this option allows you to

use the scroll ball as a toggle button to alternate between two

active Internet sessions.

Third Button Tab

This tab allows you to assign a frequently used mouse or

keyboard function to the third mouse button. The options are:

Launch Default Browser — opens an active Internet session

via your default browser.

Launch Default E-Mail — opens your default email

application.

Mini Trackball Optical Mouse

Office 97 Document Zoom (Ctrl Lock) — allows you to

magnify or minimize documents in Microsoft® Office 97 and

enables quicker access to some keyboard shortcuts.

Shift Lock — locks the Shift key for alternate key strokes.

Emulates holding down the Shift key on the keyboard.

Zoom — allows you to increase (zoom in) or decrease (zoom

out) the magnification of a graphic.

• Zoomed Area – allows you to define the size of the section

for magnification. The settings range is 2 x 2 (smallest) to

64 x 48 (largest).

• Zoom Factor allows you to define the magnification level.

The settings range is 2 (lowest) to 8 (highest).

Auto Scroll — allows you to scroll a document, graphic or

Web site without the “trackball.” To disable this feature, click

the left mouse button one time.

Others — allows you to assign one of 38 available keyboard

functions, such as Enter, Page Up, Page Down, F1 - F10 and

Tab.

Things to Remember

Safety Measures

Never point the mouse’s optical sensor toward the face,

particularly the eyes, to avoid possible injury.

Operating Hints

When using an optical mouse, for optimal performance:

• Never use the mouse on a glass or mirrored surface or on

black velvet as these surfaces will cause the mouse to fail

temporarily.

Mini Trackball Optical Mouse

• Avoid using the mouse on surfaces with repetitive patterns,

such as printed magazine photographs, as this type of surface

may cause the mouse to respond slowly or fail temporarily.

Comfortable Usage

Research suggests that physical discomfort and injury to

nerves, tendons, and muscles may be related to repetitive

motion, an improperly set up work area, incorrect body

posture, or poor work habits.

To reduce the risk of injury, follow these precautions:

• Stand, stretch, and move around several times every hour.

• Switch hands while performing tasks. Use shortcut keys to

avoid repetitive or awkward mouse movements.

• Relax your shoulders and keep your elbows at your sides.

Adjust the keyboard’s position so that you don’t have to

stretch to reach it.

• Adjust your position so that you don’t have to bend your

wrists to type; avoid placing your wrists on a sharp edge.

If you feel discomfort or numbness in your hands, wrists, arms,

shoulders, neck, or back while typing, consult a qualified

medical professional.

Technical Support

For technical questions, please visit:

Internet: http://www.targus.com/support.asp

Australia

Internet: www.targus.com.au

Email: infoaust@targus.com

Monday through Friday, 8:30 a.m. (08:30) to 5:30 p.m. (17:30)

Eastern time: 1-800-641-645

Mini Trackball Optical Mouse

Canada

Monday through Friday, 9:00 a.m. (09:00) to 5:00 p.m. (17:00)

Eastern time: 888-827-4877

Europe

Belgium +32 0 02-717-2451

Denmark +45 0 35-25-8751

France +33 0 1-64-53-9151

Germany +49 0 21-16-579-1151

Italy +39 0 24-827-1151

Netherlands +31 0 53-484-9470

Spain +34 0 91-745-6221

Sweden +46 0 8-751-4058

Switzerland +41 0 1-212-0007

United Kingdom +44 0 20-7744-0330

Eastern Europe & others +31 0 53-484-9479

Product Registration

For more efficient customer service and to activate the product’s

warranty, Targus recommends that you register your Targus accessory

shortly after purchasing it.

To register your Targus accessory, go to:

http://www.targus.com/registration.asp

You will need to provide your full name, email address, phone number,

and company information (if applicable).

Warranty

Targus warrants this product to be free from defects in materials and

workmanship for one year. If your Targus accessory is found to be

defective within that time, we will promptly repair or replace it. This

warranty does not cover accidental damage, wear and tear, or

consequential or incidental loss. Under no conditions is Targus liable for

loss of, or damage to a computer; nor loss of, or damage to, programs,

records, or data; nor any consequential or incidental damages, even if

Altri manuali per Optical Bluetooth Mouse

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Targus Topo

Targus

Targus AMU76EU Manuale utente

Targus

Targus USB RETRACTABLE OPTICAL LAPTOP MOUSE Manuale utente

Targus

Targus Stow-N-Go Notebook Mouse Manuale utente

Targus

Targus W071 Manuale utente

Targus

Targus COMPACT LAPTOP CHARGER Manuale utente

Targus

Targus 410-0008-001A Manuale utente

Targus

Targus AMB580 Manuale utente

Targus

Targus Stow-N-Go Notebook Mouse Manuale utente

Targus

Targus Rechargeable Wireless Notebook Mouse Manuale utente

Targus

Targus AMW3001EU Manuale utente

Targus

Targus PAWM004E Manuale utente

Targus

Targus WIRELESS COMFORT LASER MOUSE Manuale utente

Targus

Targus WIRELESS OPTICAL LAPTOP MOUSE Manuale utente

Targus

Targus WIRELESS COMFORT LASER MOUSE Manuale utente

Targus

Targus W063 Manuale utente

Targus

Targus Kaleidoscope AMU0503US Manuale utente

Targus

Targus USB mouse Manuale utente

Targus

Targus AMU34EU Manuale utente

Targus

Targus AMU4501 Manuale di installazione e funzionamento

Targus

Targus AMW43US Manuale utente

Targus

Targus AMU40US Manuale utente

Targus

Targus retractable laser notebook mouse Manuale utente

Targus

Targus Notebook Mouse Manuale utente

Targus

Targus AMW56AP Manuale utente

Manuali Topo popolari di altre marche

Sven

Sven RX-G720 Manuale utente

3DConnexion

3DConnexion CadMouse Pro Manuale utente

Canyon

Canyon Puncher GM-20 Manuale utente

Sharkoon

Sharkoon Light2 180 Manuale utente

Cherry

Cherry MW 8C ERGO Manuale utente

NGS

NGS HIT RB Manuale utente

Sharkoon

Sharkoon FireGlider Manuale utente

Lenovo

Lenovo Wireless Mouse N3902 Manuale utente

BASETech

BASETech BN-S11 Manuale utente

Dell

Dell WM326 Manuale utente

Areson

Areson B213 Manuale utente

HP M17587-371 Manuale utente

Chatpen

Chatpen CHA-30 Manuale utente

GAMDIAS

GAMDIAS DEMETER GMS5000 Manuale utente

HP KJ453AA - Wireless Laser Mouse Manuale utente

Trust

Trust GRAPHIN GXT 960 Manuale utente

Lenovo

Lenovo SD-9082 Manuale utente

Alienware

Alienware AW320M Manuale utente
