Targus ULTRA MINI BLUETOOTH Manuale utente
USER GUIDE
Ultra Mini
Bluetooth®Dongle
with EDR
TABLE OF CONTENTS
2
Targus Ultra Mini Bluetooth® Dongle with EDR .................. 5
7DUJXV8OWUD0LQL%OXHWRRWK'RQJOHɫ('5 ..................... 10
7DUJXV8OWUD0LQL%OXHWRRWK'RQJOHV('5 ..................... 15
Targus Ultra Mini Bluetooth® Dongle mit EDR .................. 20
Targus Ultra Mini Bluetooth® Adapter med EDR ............... 25
Targus Ultra Mini Bluetooth® pordilukk EDR-iga (suurenda-
tud andmekiirusega) .......................................................... 30
Dongle Targus Ultra Mini Bluetooth® con EDR ................. 35
Targus Ultra Mini Bluetooth® Dongle (EDR-nopeuden saavut-
tava) ................................................................................... 40
Ultra Mini Adaptateur Bluetooth® de Targus avec EDR .... 45
DE - Deutsch
DK - Dansk
ES - Español
CZ - Ceština
GB - English
EE - Eesti
FI - Suomi
FR - Français
3
ȈȣıțİȣȒ 8OWUD 0LQL %OXHWRRWK 'RQJOH ȝİ ('5 IJȘȢ7DUJXV
............................................................................................ 50
7DUJXV8OWUD0LQL%OXHWRRWKDGDSWHUV('5RP .............. 55
Targus Ultra Mini Bluetooth® Dongle EDR-rel ................... 60
Ultra mini adattatore Targus Bluetooth® con EDR ............ 65
Targus Ultra Mini Bluetooth® saugumo raktas su EDR ..... 70
³7DUJXV´ VHYLãƷL PD]DLV %OXHWRRWK VSUDXGQLV DU ('5
WHKQRORƧLMX......................................................................... 75
Targus Ultra Mini Bluetooth® Dongle with EDR ................ 80
Targus Ultra Mini Bluetooth®-programvarenøkkel med EDR
............................................................................................ 85
7DUJXV8OWUD0LQL%OXHWRRWK'RQJOH]IXQNFMą('5 ......... 90
Targus Ultra Mini Bluetooth® Dongle com EDR ................ 95
HR - Hrvatski
HU - Magyar
IT - Italiano
LT - Lietuviškai
LV - Latviešu
NL - Nederlands
NO - Norsk
PL - Polski
PT - Português
4
7DUJXV8OWUD0LQL%OXHWRRWK'RQJOHFX('5 ................. 100
7DUJXV ɍɫɬɪɨɣɫɬɜɨ 8OWUD 0LQL %OXHWRRWK ɫ ɡɚɳɢɬɧɵɦ
ɤɥɸɱɨɦɡɚɝɥɭɲɤɨɣɫ('5 .............................................. 105
Targus Ultra Mini Bluetooth® Dongle med EDR .............. 110
1DPL]QR]YH]GLãþH86%]DYGLRSUHKRGRP .............. 115
=DãþLWQLNOMXþ7DUJXV8OWUD0LQL%OXHWRRWKVSRYHþDQLPRE
VHJRPSRGDWNRY('5 ................................................... 120
('5¶OL7DUJXV8OWUD0LQL%OXHWRRWK<D]ÕOÕP.LOLGL ........... 125
SE - Svenska
SI - Slovensko
TR - Türkçe
5
TARGUS ULTRA MINI
BLUETOOTH®DONGLE
WITH EDR
Introduction
Congratulations on your purchase of the Targus Ultra Mini
Bluetooth Dongle with EDR. This adapter enables your PC or
laptop to wirelessly connect to Bluetooth devices up to 100m
away (for Bluetooth Class 1 model ACB74). It allows you to
connect up to seven Bluetooth devices including PDAs, smart
phones, keyboards, mice, printers, and other Bluetooth 1.1/1.2
compliant devices.
Devices that utilize Bluetooth are either Class 1 (model ACB74)
with a range of 100m or Class 2 (model ACB73) with a range
of 10m. This range will vary depending on the environment. To
connect at 100m, both devices need to be Class 1 devices. For
example, a Class 2 Bluetooth mouse will have a range of 10m
even when connecting to a Class 1 Bluetooth adapter.
The adapter also has built-in 128-bit encryption and authentication
to enable secure connections between Bluetooth devices and it
installs easily with Plug-and-Play convenience.
Targus Ultra Mini Bluetooth®Dongle with EDR
6
Contents
In addition to this user guide, the package contains:
• Targus Ultra Mini Bluetooth Dongle with EDR
• CD-ROM for installation software and documentation
System Requirements
• USB v1.1 compliant port
• Windows®2000/XP
• Windows VistaTM operating system
USB Adapter Installation
To use the Targus Ultra Mini Bluetooth Dongle with EDR, you
must first install the adapter software onto your computer.
WARNING: YOU MUST INSTALL THE SOFTWARE BEFORE CONNECTING
IT TO YOUR COMPUTER. OTHERWISE, THE ADAPTER WILL NOT WORK
PROPERLY.
Installing the Software
For Windows 2000/XP
1 Insert the driver software CD into your computer’s CD-ROM
drive.
2 If setup does not begin automatically, click Start, Run, then
enter D:\install.exe (where D: is the path of your disc drive) and
then click OK.
3 The installation screen will appear and choose Window’s
version (Windows 2000/XP) on the setup screen.
4 Click Next.
5 Follow the on-screen instructions.
NOTE: FOR WINDOWS 2000 USERS, A “DRIVER SIGNATURE NOTICE”
WINDOW APPEARS, PLEASE CLICK THE “OK” BUTTON.
6 The “Bluetooth device not found” window appears.
Insert the USB Bluetooth adapter in the USB port. Click OK.
7 Click Finish.
Targus Ultra Mini Bluetooth®Dongle with EDR
7
For Windows Vista
1 Insert the driver software CD into your computer’s CD-ROM
drive.
2 If setup does not begin automatically, click Start, Run, then
enter D:\install.exe (where D: is the path of your disc drive) and
then click OK.
3 The installation screen will appear and choose Window’s
version (Windows Vista) on the setup screen. Click Next.
NOTE: FOR WINDOWS VISTA USERS, A “USER ACCOUNT CONTROL”
WINDOW APPEARS, PLEASE CLICK THE “ALLOW” BUTTON.
4 The “No Bluetooth device was detected” window appears.
Insert the USB Bluetooth adapter in the USB port.
5 Follow the on-screen instructions.
6 Click Next.
7 Click Finish.
YOU CAN ALSO DOWNLOAD THE LATEST DRIVER FROM:
http://www.targus.com
Verifying the Adapter is Installed
After installing the adapter software (for Windows 2000/XP):
1 Click Start/Settings/Control Panel/System/Hardware/Device
Manager.
2 Check under ‘Bluetooth Devices’ that a ‘Broadcom 2046
Bluetooth 2.1 USB UHE Dongle’ is installed.
After installing the adapter software (for Windows Vista):
1 Click Start/Control Panel/Hardware/Device Manager.
2 Check under ‘Bluetooth Radios’ that a ‘Broadcom 2046
Bluetooth 2.1 + EDR USB Dongle’ is installed.
If the information is not present:
1 Unplug the adapter.
2 Plug the adapter into the USB port to initiate the driver.
Verify that the adapter is installed.
You are now ready to configure the Bluetooth.
Targus Ultra Mini Bluetooth®Dongle with EDR
8
&RQßJXULQJ%OXHWRRWK'HYLFHV
Bluetooth Tray
The Bluetooth tray resides in the Windows system tray, which is
normally located in the lower-right corner of the screen. The
Bluetooth tray provides fast access to most Bluetooth operations.
From the Bluetooth tray you can (Windows 2000/XP):
• Access My Bluetooth Places: double-click the Bluetooth icon, or
right-click the Bluetooth icon and then select Explore My
Bluetooth Places.
• Add a Bluetooth device: right-click the Bluetooth icon and then
select Add a Bluetooth device.
• Access the Bluetooth Configuration Panel:right-click the Bluetooth
icon, and then select Advanced Configuration.
• Access the Quick Connect option: right-click the Bluetooth icon,
select Quick Connect, and then select the type of service to which
you wish to connect.
• Start/Stop Bluetooth on this computer.
From the Bluetooth tray you can (Windows Vista):
• Add a Bluetooth device: right-click the Bluetooth icon and then
select Add a Bluetooth device.
• Show a Bluetooth device: right-click the Bluetooth icon and then
select Show Bluetooth device.
• Access the Bluetooth Configuration Panel: right-click or double-
click the Bluetooth icon, and then select Open Bluetooth
Setting.
• To send or receive a file: right-click the Bluetooth icon and then
select send or receive a file.
Targus Ultra Mini Bluetooth®Dongle with EDR
9
%DVLF2SHUDWLRQV
Start or Stop Bluetooth (for Windows 2000/
XP only)
To start Bluetooth
In the Windows system tray, right-click the Bluetooth icon and
select Start the Bluetooth Device. The Bluetooth icon is blue in
color with a white insert when the Bluetooth software is running.
To stop Bluetooth
In the Windows system tray, right-click the Bluetooth icon and
select Stop the Bluetooth Device. The Bluetooth icon is blue in
color with a red insert when Bluetooth is stopped.
Broadcom and the Broadcom logo are trademarks of Broadcom Corp. Bluetooth and the
Bluetooth logos are trademarks owned by Bluetooth SIG, Inc., U.S.A. and licensed to
Broadcom Corp. Microsoft, Windows, and Windows Vista are either registered trademarks
or trademarks of Microsoft Corporation in the United States and/or other countries. All
trademarks and registered trademarks are the properties of their respective owners. All rights
reserved.
10
TARGUS ULTRA MINI
BLUETOOTH®DONGLE
ɋ('5
ȼɴɜɟɞɟɧɢɟ
ɉɨɡɞɪɚɜɥɟɧɢɹɡɚɜɚɲɚɬɚɩɨɤɭɩɤɚɧɚ7DUJXV8OWUD0LQL%OXHWRRWK
'RQJOHɫ('5Ɍɨɡɢɚɞɚɩɬɟɪɩɨɡɜɨɥɹɜɚɧɚɜɚɲɢɹɤɨɦɩɸɬɴɪ
ɢɥɢɥɚɩɬɨɩɞɚɫɟɫɜɴɪɡɜɚɛɟɡɠɢɱɧɨɫ%OXHWRRWKɭɫɬɪɨɣɫɬɜɚ
ɧɚɪɚɡɫɬɨɹɧɢɟɞɨɦɡɚ%OXHWRRWKɤɥɚɫɦɨɞɟɥ$&%
Ɍɨɣ ɜɢ ɩɨɡɜɨɥɹɜɚ ɞɚ ɫɟ ɫɜɴɪɠɟɬɟ ɫ ɞɨ ɫɟɞɟɦ %OXHWRRWK
ɭɫɬɪɨɣɫɬɜɚɜɤɥɸɱɢɬɟɥɧɨ3'$VPDUWɬɟɥɟɮɨɧɢɤɥɚɜɢɚɬɭɪɢ
ɦɢɲɤɢɩɪɢɧɬɟɪɢɢɞɪɭɝɢɭɫɬɪɨɣɫɬɜɚɨɬɝɨɜɚɪɹɳɢɧɚ%OXHWRRWK
ɍɫɬɪɨɣɫɬɜɚɬɚɤɨɢɬɨɢɡɩɨɥɡɜɚɬ%OXHWRRWKɫɚɢɥɢɄɥɚɫɦɨɞɟɥ
$&%ɫ ɨɛɯɜɚɬɦ ɢɥɢɄɥɚɫ ɦɨɞɟɥ$&%ɫ ɨɛɯɜɚɬ
ɦɌɨɡɢɨɛɯɜɚɬɳɟɜɚɪɢɪɚɜɡɚɜɢɫɢɦɨɫɬɨɬɨɤɨɥɧɚɬɚɫɪɟɞɚ
Ɂɚɞɚɫɟɫɜɴɪɠɟɬɟɧɚɪɚɡɫɬɨɹɧɢɟɦɢɞɜɟɬɟɭɫɬɪɨɣɫɬɜɚ
ɬɪɹɛɜɚ ɞɚ ɛɴɞɚɬ Ʉɥɚɫ ɇɚɩɪɢɦɟɪ ɟɞɧɚ Ʉɥɚɫ %OXHWRRWK
ɦɢɲɤɚɳɟɢɦɚɨɛɯɜɚɬɦɞɨɪɢɤɨɝɚɬɨɫɟɫɜɴɪɡɜɚɤɴɦɄɥɚɫ
%OXHWRRWKɚɞɚɩɬɟɪ
Ⱥɞɚɩɬɟɪɴɬ ɫɴɳɨ ɢɦɚ ɜɝɪɚɞɟɧɨ ɛɢɬɨɜɨ ɤɪɢɩɬɢɪɚɧɟ ɢ
ɭɞɨɫɬɨɜɟɪɹɜɚɧɟ ɡɚ ɞɚ ɩɨɡɜɨɥɢ ɫɢɝɭɪɧɨ ɫɜɴɪɡɜɚɧɟ ɦɟɠɞɭ
%OXHWRRWKɭɫɬɪɨɣɫɬɜɚɬɚɢɫɟɢɧɫɬɚɥɢɪɚɥɟɫɧɨɫɭɞɨɛɫɬɜɨɬɨɧɚ
3OXJDQG3OD\
