Tatung TTAC Manuale utente
TATUNG
TOWER AIR COOLER
TTAC
USER MANUAL
Ⅰ.Features
*Strong wind
*Quiet motor
*ION generator to improve the quality of indoor air
*Swing to cover wide angle
*Large capacity of ice pot for excellence of cooling performance.
*Long distance control for convenient operation.
*0-9 hours timer setting
*LED luxury display window
*Water circulation from injection to cool temperature quicker.
*Dismountable water filter to wash with ease.
*Optical catalyst patch can deodorize and sterilize the indoor air. Optical
rebirth to ensure the long term performance
*Double filter setting to purify and clean the air.
◆Outside filter: Filter the big dust grain and fiber
◆Water curtain cloth filter: Filter the exiguity of dust grain and reduce
the temperature by circulation from water injection.
Ⅱ. Warning:
Please read explanation of each icon listed below. It will help you to avoid
the danger during the operation of this equipment.
◆Illustration for the icons :
1. Warning. It can cause death under incorrect operation if user
ignores this warning content.
3. Forbidden: Detailed forbidden content is attached in the icon
nearby with picture or words description
4. Compulsory: Detailed compulsory force content is attached in
the icon or nearby with picture or words description.
◆Explanation for symbol:
Warning; Notice.
Forbid to touch
Forbid to disassemble
Be careful of electric shock
Must be implemented
Normal forbid
No fire
Warning:
◆Power must be AC 120V
◆Power must comply with the rated power on the label .
◆Rating label sticker on the back of the appliance
◆Be careful of the operating appliance when moving .
Warning:
1. If any problem happens to the unit, please contact Tatung service
department. Please do not disassemble the unit or change any
components on your own.
A) Any unprofessional disassemble or alternate will effect the safety or
performance of operation.
B) Please contact with Tatung service department if any problem occurs.
2. Forbid to touch the plug when the hand is wet because it might cause
the electric shock.
3. Forbid to insert any wooden or metal stick into the input or output outlet.
Otherwise it will cause electric leakage, short circuit and damage the
product.
4. Please do not insufflate any insecticide or flammability spray around
the unit. Otherwise it will damage the product
5. Please shut off the unit and draw out the plug when the unit needs to
be cleaned. All the cleaning must be done after the unit completely stops
running to avoid any harm.
6.Please do not draw the cable to unplug.
7. This appliance is not intended for use by children or infirm persons
unless they have been adequately supervised by a responsible person to
ensure that they can use the unit safely.
Children should be supervised to ensure not play with the appliance.
Ⅲ.Notice:
zDo not fill water above “MAX” level.
zChoose normal wind when the humidity is high, because cooling
function is accompanied with humidity.
zDo not lean or crash the appliance to avoid water drifting out after
adding the water
zDo not put any objects on or in the unit.
zDisconnect power and pull out the plug before cleaning and
repairing.
zClean outside of the unit with wet mop (or add some detergent). Do
not use corrosive detergent or solvent to clean. Pouring water on the
unit is strictly forbidden.
zIf machine fallen down with water in it, plug should be pulled off
immediately. Machine can be switched on after 24 hours’ drying. The
appliance could be damaged if the instruction is not followed.
zDo not place the wind outlet and wind inlet of the unit close to wall or
curtain, otherwise air can be blocked to influence the efficiency.
zYou may find some noise from the unit and uneven wind volume
after using for a certain period of time. This is because the air
filtering net is dusty and blocks the airflow. It will be back to normal
after cleaning the air filtering net.
zWhen not using the appliance, pull out the plug from outlet.
zThe appliance must be taken to Tatung Service department for
repairing.
zIf the supply cord is damaged, it must be replaced by Tatung Service
Department to avoid a hazard.
NOTES: Any water will be strictly forbidden to leave on
control Panel.
As high pressure exists in the machine, plug has to be
pulled off when cleaning.
Ⅳ.Components
● Front
●Back
1. Control panel
2. LED display
3. Wind outlet
4. Water Level Indicator
5. Power cord
6. Wind inlet
7. Water cloth
8. Air-filter net
9. Water adding Door
10. Water adding window
11. Water stopper
12. Ice adding door button
● Accessory
Ice box remote control Consumer manual
● Display panel
TTAC
Ⅴ.Manual Operation
◆ Manual on control panel
On/Speed Key:
By pressing On/Speed key to change the wind speed. Wind speed
starts from medium to low speed 3 seconds later, then you can press
On/Speed key to set what you need. LCD display indicates the wind
speed from ”HIGH”, ”MEDIUM” and “LOW”.
Cooler/Humidifier Key:
Press this key when adding water or ice. Outlet temperature will be lower
20 seconds later and the indicator light will be on.
Oscillation Key:
Press this key, louver will swing from left to the right and the indicator light
will be on.
Timer:
It can be selected between 1-9hours.
Ion Key:
Connect power and then press this key, the built-in anion generator will
start to release anion, meanwhile, the light is on.
Mode Key:
Select the rotation of the wind in different mode as “Normal Wind”,
“Natural Wind”, and “Sleeping Wind”.
Normal Wind :
Constant rotation with different wind speed of “LOW”, “MED” and “HI” as
set.
Natural Wind :
The fan operates in Hi, Medium and Low speed in a circle as preset by
microcomputer program for 90 seconds per circle and 6 seconds for each
section (pause for 3 seconds.) High, medium or low wind can be
generated by using the Wind Speed Key that imitates the natural breeze
with gentleness and comfort.
Sleeping Wind :
Under this mode, the unit will be in computer-controlled mode. The speed
will lower down gradually.
◆Manual of assembly
1.Open the package and take out the unit. Connect power after
abandoning foam cover.
2.Adding Water:
Open the cover on the bottom left of the unit to add water (figure1,
figure2). Check the water level by the watermark to control within the
capacity.
Pay attention to the following:
1) When adding water, pay attention to the water level indicator on the
front of the unit.
2) Do not refill water above the red mark.
3) Please close the cover after finishing adding water, otherwise the unit
will not work.
4) If you want to reduce more temperature, you can put ice on the top of
the unit (operate same as figure1, figure2 ).
3.Instruction of “ICE BOX”
The unit assembles with two unique “Ice boxes”, as for its special ability
to keep it cool. This unique “Ice box” can keep the temperature of the
water around 460F lower than the temperature of the ambience.
Operation Method
1) Put the ICE BOXES into the refrigerator and keep them inside till
they are completely frozen.
2) Put them into the water tank. Keeping for 4 hours, the temperature of
the water will be 80C lower than that of the ambience and make the
wind cooler.
3) The unit assembles with two ICE BOXES that can be used
continuously
Ⅵ.Cleaning and maintenance
●Cleaning
◆ Air Filtering Net
Pull out electric plug, and then hold the handle of Air Filtering Net to pull
out the Air Filtering Net. (If the environment is dusty, wash it once in every
two months)
◆Cleaning method
Wash the net with thin soap water and soft brush
Water Tank No need to clean the unit usually.
◆Cleaning Method
Disconnect power and then discharge
the water in the water tank. Open the
Adding water cover and clean the
sediments in the water tank with gentle
detergent. Then screw down the
drainage stopper at the bottom of the unit and drain off the wastewater.
◆ Cleaning water screen cloth
Pull the plug out of the outlet first, take off the air filtering net (3), then
take the water screen cloth (2) out.
◆ Outer cover
Cleaning with thin soap and soft cloth Attention: Any parts of the control
panel should be forbidden to soak into water.
As high pressure exists in the machine, plug has to be pulled off when
cleaning.
