Taurus LAT PULLDOWN/ VERTICAL ROW IT95 Manuale utente

Owner‘s Manual

TF-IT9522

LAT PULLDOWN/

VERTICAL ROW IT95

TAURUS® is a registered brand of the company Sport-Tiedje GmbH.

Table Of Contents

CAUTION!

Read all precautions and instructions in this manual before using this equipment.

Please assemble according to the actual Weights you buy !

Important Safety Instructions----------------------------------------------------------- 3

Instructions-------------------------------------------------------------------------------- 5

Exploded View and Parts List------------------------------------------------------------ 6

Measurement Guide--------------------------------------------------------------------- 13

Assembly Instructions------------------------------------------------------------------ 14

Assembly--------------------------------------------------------------------------------- 15

Adjust Instructions---------------------------------------------------------------------- 28

Exercise Instructions-------------------------------------------------------------------- 29

Maintenance Schedule------------------------------------------------------------------ 30

General Maintenance Information----------------------------------------------------- 31

Weight Training Tips-------------------------------------------------------------------- 32

Important Safety Instructions

Before beginning any fitness program, you should obtain a complete physical

examination from your physician. When using exercise equipment, basic

precautions should always be taken, including the following:

1. Read all instructions before using the equipment.

These instructions are written to ensure your safety and to protect the unit.

2. Use the equipment only for its intended purpose as described in this guide.

Do not use accessory attachments that are not recommended by the

manufacturer: such attachments might cause injuries.

3. The product should only be used on a level surface and is with 0.5 meters

space around the product.

Do not use the equipment outdoors.

4. Do not allow children on or near the equipment. And children are not allowed

to use this equipment.

Teenagers should use this equipment with adult supervision.

5. Do not overexert yourself or work to exhaustion.

Do not attempt to lift more weight than you can control safely.

If you feel any pain or abnormal symptoms, stop your workout immediately

and consult your physician.

6. This equipment is not used as medical apparatus and instruments.

7. Never operate the unit when it has been dropped or damaged.

Never drop or insert anything into any opening in the equipment.

Always check the unit and its cables before each use. Make sure that all

fasteners and cables are secure and in good working condition.

Frayed or worn cables can be dangerous and may cause injury. Periodically

check these cables for any indication of wear.

Keep hands, limbs, loose clothing and long hair well out of the way of moving

parts.

8. Be careful when getting on or off the equipment.

9. Wear proper exercise clothing and shoes for your workout, no loose clothing.

Specifications

Class: S

Maximum Wt. Capacity: 134kg/ 295lbs

Maximum User Weight: 150kg/ 330lbs

Product Total Surface: 1231*1909mm

Product Total Mass: 131.6 kg/ 290 lbs

Training Area and Free Area

Important Safety Instructions

Personal Safety During Assembly

Read each step in the assembly instructions and follow the steps in sequence.

Do not skip ahead. If you skip ahead, you may learn later that you have to

disassemble components and that you may have damaged the equipment.

Assemble and operate the equipment on a solid, level surface. Locate the unit

a few feet from walls or furniture to provide easy access. The equipment is

designed for your enjoyment. By following these precautions and using

common sense, you will have many safe and pleasurable hours of healthful

exercise with the equipment.

Instructions

Tools Required

The equipment is designed to provide the smoothest, most effective exercise

motion possible. After assembly, you should check all functions to ensure correct

operation. If you experience problems, first recheck the assembly instructions to

locate any possible errors made during assembly. If you are unable to correct the

problem, call your authorized dealer. Be sure to have your serial number and this

manual when calling. When all parts have been accounted for, continue on.

Ratchet Wrench and Socket

Adjustable Wrench

Rubber Mallet

Hex Key Wrench Set

Phillips Screwdriver

Before beginning assembly please take the time to read instructions thoroughly.

Please use the various lists in this manual to make sure that all parts have been

included in your shipment. When ordering, use part number and description from

the lists. Use only our replacement part when servicing. Failure to do so will void

your warranty and could result in personal injury.

Exploded View and Parts List

Overall

Item No. Grade No. Part No. Description QTY

1 1 IT952201ASSY Weight Stack Frame ASSY 1

2 2 IT952202ASSY Seated Frame ASSY 1

3 3 IT952203ASSY Front Frame ASSY 1

4 4 IT952204ASSY FOAM Frame ASSY 1

5 5 IT952205ASSY Top Frame ASSY 1

6 6 IT95220600 Support Frame 1

7 8 IT95220800 Handle Frame 1

8 9 IT951709ASSY Circular Foot Frame ASSY 1

9 10 FS531300 Pulley Bracket 1

10 11 IT90222400 U Bracket 2

11 12 IT95223100 Lat Pull Cable 1

12 13 IT95223200 Row Cable 1

13 14 SD1000B3000ASSY Adjustable Foot Plate 2

14 15 SG500110400V5 4.5" Pulley 9

15 16 FTX7300V1 2" Pulley 1

16 17 V30900V1 Long Lat Bar 1

17 18 IT952218ASSY Lat Bar ASSY 1

18 19 IN-D10132900 Weight Rubber Bumper 2

19 23 IT952223ASSY Rear Bracket ASSY 1

20 24 IT952224ASSY Front Bracket ASSY 1

21 25 IT952225ASSY Bottom Bracket ASSY 1

22 26 IT95222600 Top Bracket 2

23 27 IT95222700 Bottom Bracket 1

24 42 IT95014200 Top Plate 1

25 44 IT95224400 Guide Rod Φ19*1597 2

26 51 IT95225100 Top Cover 1

27 52 IT95015200 Training Placard Cover 1

28 53 IT95015300 Front Shroud 2

29 55 IT95015500 Top Rear Shroud 1

30 56 IT95015600 Rear Shroud 1

31 60 IT95225500 Bottom Rear Shroud 1

32 61 IT95226100 Right Shroud 1

33 62 IT95226200 Left Shroud 1

Exploded View and Parts List

Overall

Item No. Grade No. Part No. Description QTY

34 76 IT95227600 Seat Pad 1

35 77 IE950221ASSY FOAM ASSY 2

36 92 IT801210300P11C Cup Holder 1

37 101 IT90012000V1 Selector Pin W/Coil 1

38 102 IT95016100 Guide Rod Fixing SleeveΦ25*Φ19*45 2

39 103 IT95016500 Spout Plug Φ16.5*6.88 2

40 104 HFOPT900-04A0602 Spring 2

41 105 IT95062000 Cap ASSY 2

42 106 HLG8DS2 Gear Hook 2

43 107 LHΦ5*5DS2 Chain 1

44 108 IE95029100 Plastic Ring 2

45 109 GB70BTM10*80DN18 Socket Head Cap Screw M10*80 2

46 110 GB70BTM10*75DN18 Socket Head Cap Screw M10*75 8

47 111 GB70BTM10*70DN18 Socket Head Cap Screw M10*70 3

48 112 GB70BTM10*65DN18 Socket Head Cap Screw M10*65 2

49 113 GB70BTM10*50DN18 Socket Head Cap Screw M10*50 6

50 114 GB70BTM10*25DN18 Socket Head Cap Screw M10*25 7

51 115 GB9310DS12 Spring WasherΦ10 4

52 116 GB5781M10*15DS20NL Hex Head Bolt M10*15 2

53 117 PNLM8*70DS20 Button Socket Head Cap Screw M8*70 2

54 118 GB70M8*20N19 Socket Head Cap Screw M8*20 2

55 119 GB70M8*10DS2 Socket Head Cap Screw M8*10 2

56 120 GB818M6*20DHS2 Cross Recessed Pan Head Screw M6*20 24

57 121 GB818M6*10DHS2 Cross Recessed Pan Head Screw M6*10 8

58 122 NM10DN2 Nylon Lock Nut M10 17

59 123 NM8DN2 Nylon Lock Nut M8 2

60 124 GB958DN2 Flat Washer Φ9*Φ16*1.6 8

61 125 GB9510DN2 Flat Washer Φ11*Φ20*2 44

62 126 NBS0.188DHS Hex Key S=3/16" 1

63 127 NBS5DHS Hex Key S=5 1

64 128 NBS6DHS Hex Key S=6 1

65 129 LW200BS Wrench Φ6*117 1

66 130 YHY Lube 1

Exploded View and Parts List

Overall

Exploded View and Parts List

Weight Stack Frame ASSY

Item No. Grade No. Part No. Description QTY

1 1.1 IT95220100 Weight Stack Frame 1

2 1.2 GB17880.5M6*16.5DS17 Rivet Nut M6 20

3 1.3 GB818M6*20DHS2 Cross Recessed Pan Head Screw M6*20 4

4 1.4 GB17880.5M8*16.5DCS17 Rivet Nut M8 2

5 1.5 IT95015900 Plastic Block 4

6 1.6 IT95015700 Foot Plate 2

7 1.7 IT95015800 Plug Φ95*81.1 2

Exploded View and Parts List

Seated Frame ASSY

Item No. Grade No. Part No. Description QTY

1 2.1 IT95220200 Seated Frame 1

2 2.2 IT95221700 Pin 1

3 2.3 IT95016200 Plastic Tube Plug 1

4 2.4 IT95016300 Plastic Corner Tube Glide 4

5 2.5 IT90013800P11C Plug RT50*100 1

6 2.6 IT95014300 Aluminum Tube Guide 1

7 2.7 GB70M6*10N19 Socket Head Cap Screw M6*10 1

8 2.8 GB956DN2 Flat WasherΦ6.6*Φ12*1.6 1
