Taylor 1383 Manuale utente

Get actual current temperatures and predict the weather

conditions for the next 24 hours as well as your local television

weatherperson! Taylor uses the temperature and changes in

relative humidity levels to forecast the upcoming day. Plan the

day with condence with Taylor® Today’s Weather.

Please read this instruction manual carefully before use and

keep these instructions handy.

Today’s Weather 24 Hour Forecaster

Instruction Manual

1383

Battery Power

2 AAA alkaline for base unit (not included).

2 AAA lithium for remote sensor (recommended, not included).

Remove the battery compartment cover on the back of the

base unit. Install 2 AAA batteries according to the polarity

markings in the compartment and replace the cover.

*Important: Install the base unit batteries rst, before installing

the remote sensor batteries, for proper signal connection. 1

To Power and Set Up the Weather Forecaster

Set Current Weather Conditions

1. After battery installation, the current weather icon ashes.

2. Press “Up” or “Down” to select the weather icon you believe

most closely reects the current conditions in your area.

(Partly Cloudy is the default setting).

3. Press “Time/Date” to select the displayed weather icon. The

icon stops ashing.

Icon ashes during setup, then steady when set

4.The selected weather icon appears on all screens.

(The temperature and forecast readings update after remote

sensor is added.)

Install Batteries into Remote Sensor

*Important: Install the remote sensor batteries after installing the

base unit batteries for proper signal connection.

Remote sensor – use 2 AAA lithium batteries (not included).

Remove the screws from the battery compartment on the back

of the remote (take care not to misplace the screws). Install the

batteries according to the polarity markings in the compartment.

Replace the cover and the screws.

Please note: The TX button does not operate any functions on

this unit ~ please disregard.

Battery Advice: Alkaline batteries will read outdoor temperatures

from 14°F to 122°F (-10°C to 50°C).

Lithium batteries will read outdoor temperatures from -4°F to

158°F (-20°C to 70°C).

Although alkaline batteries may be used, lithium batteries are

recommended for the wider temperature range.

Set Up Remote Sensor

1. After installing the batteries into the base unit and the remote

sensor, place the units close together for best setup connection.

2. Press the “SYNC” button on the back of the base unit to send

a transmission signal to the remote sensor. Allow a few minutes

for a connection as the icon ashes and the temperature

digits show dashes. When connected the icon disappears.

3. After a signal is received, position the remote sensor at an

outdoor location within 200 feet of the base unit in a dry,

shaded area. Direct sunlight will heat the casing and inate

temperatures readings.

Important: Though the remote is weather resistant, it should be

placed away from direct sunlight, rain, snow and should never

be submerged in water.

4. Allow at least 6 hours for the remote to analyze weather

conditions and report forecast readings. During that time, indoor

temperature will update every 30 seconds and appears on the

forecast screens. Outdoor temperature and humidity show “- -”,

and all weather icons are identical.

icon ashes while transmitting, disappears after connection

to remote.

Only the current temperature will update during rst 6 hours.

Temperature forecasts and weather icons stay identical while

analyzing 1st forecast.

5. After the rst 6 hours, when the units begin to forecast weather

conditions, all temperature and weather screens will update with

new forecasts.

6. The remote sensor will automatically transmit weather condi-

tions to the base unit.

• Indoor temperature readings will update approximately every 30 seconds.

• Current outdoor temperature readings will update approximately every

1 minute.

•Outdoor temperature, outdoor humidity and weather condition forecasts

will update every 6 hours during the rst 24 hours of operation.

•After the rst 24 hours, updates occur every 1 hour.

Please note: if the remote senses identical weather conditions over a

24 hour period, the screens will all show identical readings.

Temperature and Weather forecasts update

Reading the Weather Forecaster

1) Current outdoor temperature at

remote sensor location

2) Current outdoor humidity

at remote sensor location

3) Current weather condition icon

4) Current indoor temperature

5) Clock/Date

6) Base unit low battery indicator

7) Transmission signal icon

8) Remote sensor low battery indicator

9) 5 forecast displays over 24 hours

A) Weather condition forecast icon

B) Outdoor temperature forecast

C) Outdoor humidity forecast

Forecast screens will rotate as time periods change, with the next period

appearing at the left.

To Set Clock and Date

1. Press and hold “TIME/DATE” for 2

seconds, then release.

2. Press “UP” or “DOWN” to change

the hours. Press “TIME/DATE”.

3. Press “UP” or “DOWN” to change the minutes. Press “TIME/DATE”.

4. Press “UP” or “DOWN” to switch between a 12 or 24 hour clock.

Press “TIME/DATE”.

5. Press “UP” or “DOWN” to change the year. Press “TIME/DATE”.

6. Press “UP” or “DOWN” to change the month. Press “TIME/DATE”.

7. Press “UP” or “DOWN” to change the date. Press “TIME/DATE”.

8. Weather Forecaster and Clock/Date setup are complete.

9. Press “TIME/DATE” to toggle between the time and year displays.

Midday.............................................10AM-2PM

Afternoon......................................... 2PM-6PM

Evening............................................. 6PM-10PM

Overnight..........................................10PM-6AM

Morning............................................ 6AM-10AM

Additional Features

Low Battery Warning

Base unit – replace both batteries when the “ ” icon appears

on the right side of the screen.

°C/°F Selection

Press the “C/F” button on the back of the base unit to switch

between Fahrenheit and Celsius temperatures.

Backlight

Press the Backlight button on the top of the base unit. The LCD

screen will light up for approximately 5 seconds.

Remote sensor – replace both batteries when the “ ” icon

appears on the left side of the screen.

Setup:

Place the base unit as close as possible to the remote sensor during

setup. This will ensure the best reception of signals as you set up your

wireless forecaster.

Location:

Position the base unit and remote sensor within the effective trans-

mission range of 200 feet (60 meters).

Place the base unit indoors in a well-ventilated location away from

direct sunlight.

Place the remote sensor in a dry, shaded area. Direct sunlight will

heat the casing and inate temperatures readings.

Tips

Batteries:

Lithium batteries are recommended for the remote sensor, since

alkaline batteries may freeze or otherwise become damaged in

extreme temperatures. The sensor will function with alkaline

batteries, but are best suited for milder climates.

(See Specications.)

Important:

Though the remote unit is weather resistant, it should be placed

away from direct sunlight, rain, snow and should never be sub-

merged in water.

Note:

The effective range is greatly affected by the building materials

and where the base and remote units are positioned. Try various

set ups for the best results. Check to make sure the transmission

path is clear of obstacles and interference. Shorten the distance

between base and remote units when necessary.

Placement:

Table stand – use to sit the units on a at surface,

such as a desk or countertop.

Keyhole – use to hang on a wall.

Tips (continued)

Keyhole

Table stand

Back View

Problem Solving

1. If the LCD readout is faint, replace the batteries.

2. If outdoor temperature does not display on the base unit:

a) Press the “SYNC” button to trigger a signal from the base to the

remote;

b) Relocate remote sensor if it is obstructed from weather condi-

tions or in contact with an object that might affect tempera-

ture readings (hot metal object, snow, etc.)

c) Remove and reinstall all batteries, using new fully charged

batteries;

d) Repeat set-up procedures;

e) Place the remote sensor closer to the base unit;

e) Position the base and remote within range and without interfer-

ing obstructions between units.

3. If new batteries are faulty on the initial installation, install fresh

batteries. If you did not notice the Low Battery icon warning

and the product performed correctly after initial set up, the

batteries have lost their charge. Replace the batteries (see To

Power and Set Up the Weather Forecaster).

General Information

Display Information

If the base unit does not receive a transmission from a remote

channel for 1 hour, the display will show dashes. Press the “SYNC”

button to send a signal manually. Check that the base and re-

mote are within a 200 foot range. Check that there are no major

obstacles between the units that may block signals, such as build-

ings, trees, etc. Try to have no more than 2 or 3 walls between the

units. Try various locations and shorten the distance between units

if necessary.

Over- or under- temperature range displays: If the temperature

is outside the unit’s temperature range of -4°F to 158°F / -20°C to

70°C (with use of lithium batteries), the LCD will show “HH” (higher

than the temperaturerange) or “LL” (lower than the temperature

range). When temperatures are within the range, the readings will

return. If necessary, relocate the remote sensor away from loca-

tions with extreme temperatures (such as snow or a hot surface). 9

Transmission Information

The remote sensor sends temperature and weather condition

information to the base unit.

After installing batteries into both units, allow 6 hours to analyze

weather conditions and report forecasts.

Weather readings will update as follows:

• Current temperature updates approximately every 1 minute.

• Temperature and weather forecasts update every 6 hours

during the rst 24 hours of operation after battery installation.

• After 24 hours, updates occur every 1 hour.

If there are no changes on the display after 6 hours, press the “SYNC”

button to send a new signal to repeat the transmission cycle.

After an extreme temperature change (ex. relocating the sensor

from a warm indoor location to snowy outdoors), allow a few

minutes for the temperature reading to stabilize.

Transmission Collision

Signals from other household devices, such as doorbells, home

security systems and entry controls, may interfere. This is normal

and does not affect the general performance of this product.

The transmission will resume once the interference recedes.

Note: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

Modications not authorized by the manufacturer may void user’s authority to

operate this device.

Indice

Altri manuali Taylor Stazione meteorologica

Manuali Stazione meteorologica popolari di altre marche

Auriol

Auriol AHFL 433 A1 Manuale utente

NexSens

NexSens G2-HYDROMET Manuale utente

Hyundai

Hyundai WS 2202 Manuale utente

IROX

IROX HBVR761 UV-X Manuale utente

La Crosse Technology

La Crosse Technology C86371 Manuale utente

ADE

ADE WS 1711 Manuale utente

Auriol

Auriol z29592 Manuale utente

Auriol

Auriol 296289 Manuale utente

Hyundai

Hyundai WS 2266 Manuale utente

La Crosse Technology

La Crosse Technology WS-2210 Manuale utente

La Crosse Technology

La Crosse Technology WS-811561 Manuale utente

Ventus

Ventus W177 Manuale utente

National Geographic

National Geographic VA Colour RC Manuale utente

Renkforce

Renkforce 1208067 Manuale utente

Levenhuk

Levenhuk Discovery Report WA40 Manuale utente

Instant Transmission

Instant Transmission MA 10410 Manuale utente

Lutron Electronics

Lutron Electronics PHB-318 Manuale utente

WAREMA

WAREMA EWFS Weather station eco Manuale utente
