TBK vision TBK-DVR1100 Series Manuale utente

User Manual

Digital Video Recorder

TBK-DVR1100 series

TBK-DVR1100 Digital Video Recorder User Manual

www.tbkvision.com 2

User Manual

About this Manual

This Manual is applicable to Digital Video Recorder (DVR) TBK-DVR1100 series.

The Manual includes instructions for using and managing the product. Pictures, charts, images and all

other information hereinafter are for description and explanation only. The information contained in

the Manual is subject to change, without notice, due to firmware updates or other reasons. Please

find the latest version in the company website.

Please use this user manual under the guidance of professionals.

Legal Disclaimer

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY

AT YOUR OWN RISKS. OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL

OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER

ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, OUR COMPANY WILL

PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR

JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE

APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED

WITH ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER

PREVAILS.

TBK-DVR1100 Digital Video Recorder User Manual V2

www.tbkvision.com 3

Regulatory Information

FCC Information

Please take attention that changes or modification not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

FCC compliance: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and

comply therefore with the applicable harmonized European standards listed under the EMC

Directive 2014/30/EU, the LVD Directive 2014/35/EU, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as

unsorted municipal waste in the European Union. For proper recycling, return this product

to your local supplier upon the purchase of equivalent new equipment, or

dispose of it at designated collection points. For more information see: www.recyclethis.info

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of

as unsorted municipal waste in the European Union. See the product documentation for

specific battery information. The battery is marked with this symbol, which may include

lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the

battery to your supplier or to a designated collection point. For more information see:

www.recyclethis.info

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

TBK-DVR1100 Digital Video Recorder User Manual

www.tbkvision.com 4

Applicable Models

This manual is applicable to the models listed in the following table.

Series

Model

TBK-DVR1100

TBK-DVR1104

TBK-DVR1108

TBK-DVR1116

Symbol Conventions

The symbols that may be found in this document are defined as follows.

Symbol

Description

Provides additional information to emphasize or

supplement important points of the main text.

Indicates a potentially hazardous situation, which

if not avoided, could result in equipment

damage, data loss, performance degradation, or

unexpected results.

Indicates a hazard with a high level of risk, which

if not avoided, will result in death or serious

injury.

TBK-DVR1100 Digital Video Recorder User Manual V2

www.tbkvision.com 5

Safety Instructions

⚫Proper configuration of all passwords and other security settings is the responsibility of the

installer and/or end-user.

⚫In the use of the product, you must be in strict compliance with the electrical safety regulations

of the nation and region. Please refer to technical specifications for detailed information.

⚫Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power

Source with 100 to 240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to

technical specifications for detailed information.

⚫Do not connect several devices to one power adapter as adapter overload may cause over-

heating or a fire hazard.

⚫Please make sure that the plug is firmly connected to the power socket.

⚫If smoke, odor or noise rise from the device, turn off the power at once and unplug the power

cable, and then please contact the service center.

Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

⚫Ensure unit is installed in a well-ventilated, dust-free environment.

⚫Unit is designed for indoor use only.

⚫Keep all liquids away from the device.

⚫Ensure environmental conditions meet factory specifications.

⚫Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of

dropping it may cause damage to the sensitive electronics within the unit.

⚫Use the device in conjunction with an UPS if possible.

⚫Power down the unit before connecting and disconnecting accessories and peripherals.

⚫A factory recommended HDD should be used for this device.

⚫Improper use or replacement of the battery may result in hazard of explosion. Replace with the

same or equivalent type only. Dispose of used batteries according to the instructions provided by

the battery manufacturer.

TBK-DVR1100 Digital Video Recorder User Manual

www.tbkvision.com 6

1.1 Product Key Features

General

⚫Connectable to HD-TVI and analog cameras;

⚫Supports UTC protocol for connecting camera over coax;

⚫Connectable to AHD cameras;

⚫Connectable to HDCVI cameras;

⚫Connectable to IP cameras;

⚫The analog signal inputs including HD-TVI, AHD, HDCVI, and CVBS can be automatically

recognized without configuration;

⚫Each channel supports dual-stream. And sub-stream supports up to WD1 resolution;

⚫The main stream support up to 720p resolution;

⚫1080p lite mode is applicable to all the channels;

⚫Independent configuration for each channel, including resolution, frame rate, bit rate, image

quality, etc.;

⚫Encoding for both video stream and video & audio stream; audio and video synchronization

during composite stream encoding;

⚫One-key enable or disable H.264+; Defog level, night to day sensitivity, day to night sensitivity,

and IR light brightness configurable for the connected analog cameras supporting these parameters;

4 MP/5 MP signal switch for the supported analog cameras; ⚫

Watermark technology.

Local Monitoring

⚫1/4/6/8/9/16 screen live view is supported, and the display sequence of screens is adjustable;

⚫Live view screen can be switched in group and manual switch and automatic cycle live view are

also provided, the interval of automatic cycle can be adjusted;

⚫CVBS output only serves as the aux output or live view output.

⚫Quick setting menu is provided for live view;

⚫The selected live view channel can be shielded;

⚫VCA information overlay in live view for the supported analog cameras and in smart playback for

the supported analog and IP cameras;

⚫Motion detection, video-tampering detection, video exception alarm, video loss alarm and VCA

alarm functions;

TBK-DVR1100 Digital Video Recorder User Manual V2

www.tbkvision.com 7

⚫Privacy mask;

⚫Several PTZ protocols (including Omnicast VMS of Genetec) supported; PTZ preset, patrol and

pattern;

⚫Zooming in/out by clicking the mouse and PTZ tracing by dragging mouse.

HDD Management

⚫Each disk with a maximum of 6 TB storage;

⚫8 network disks (8 NAS disks, 8 IP SAN disks or n NAS disks + m IP SAN disks (n+m ≤ 8)) can be

connected;

⚫Remaining recording time of the HDD can be viewed;

⚫S.M.A.R.T. and bad sector detection;

⚫HDD sleeping function;

⚫HDD property: redundancy, read-only, read/write (R/W);

⚫HDD group management;

⚫HDD quota management; different capacity can be assigned to different channels.

Recording and Playback

⚫Holiday recording schedule configuration;

⚫Cycle and non-cycle recording modes;

⚫Normal and event video encoding parameters;

Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm

and Event;

⚫8 recording time periods with separated recording types;

⚫Supports Channel-Zero encoding;

⚫Main stream and sub-stream configurable for simultaneous recording;

⚫Pre-record and post-record for motion detection triggered recording, and pre-record time for

schedule and manual recording;

⚫Searching record files by events (alarm input/motion detection);

⚫Customization of tags, searching and playing back by tags;

⚫Locking and unlocking of record files;

⚫Local redundant recording;

⚫When HD-TVI, AHD, or HDCVI input is connected, the information including the resolution and

frame rate will be overlaid on the bottom right corner of the live view for 5 seconds. When CVBS

TBK-DVR1100 Digital Video Recorder User Manual

www.tbkvision.com 8

input is connected, the information such as NTSC or PAL will be overlaid on the bottom right

corner of the live view for 5 seconds.

⚫Searching and playing back record files by camera number, recording type, start time, end time,

etc.;

⚫Smart playback to go through less effective information;

⚫Main stream and sub-stream selectable for local/remote playback;

⚫Zooming in for any area when playback;

⚫Multi-channel reverse playback;

⚫Supports pause, fast forward, slow forward, skip forward, and skip backward when playback,

locating by dragging the mouse on the progress bar;

⚫4/8/16-ch synchronous playback;

Backup

⚫Exports data by a USB, and SATA device;

⚫Exports video clips when playback;

⚫Management and maintenance of backup devices.

Alarm and Exception

⚫Configurable arming time of alarm input/output;

⚫Alarms for video loss, motion detection, video tampering, abnormal signal, video input/recording

resolution mismatch, illegal login, network disconnected, IP confliction, record exception, HDD

error, and HDD full, etc.;

Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email

and alarm output;

One-Key disarms the linkage actions of the alarm input;

⚫PTZ linking for the VCA alarm;

⚫VCA detection alarm is supported;

⚫Supports POS triggered alarm;

⚫Supports coaxial alarm;

⚫System will automatically reboot when a problem is detected in an attempt to restore normal

functionality.

Other Local Functions

⚫Manual and automatic video quality diagnostics;

⚫Operable by mouse and remote control;

TBK-DVR1100 Digital Video Recorder User Manual V2

www.tbkvision.com 9

⚫Three-level user management; admin user can create many operating account and define their

operating permission, which includes the permission to access any channel;

⚫Completeness of operation, alarm, exceptions and log writing and searching;

⚫Manually triggering and clearing alarms;

⚫Importing and exporting of configuration file of devices;

⚫Getting cameras type information automatically;

⚫Unlock pattern for device login for the admin;

⚫Clear-text password available;

⚫GUID file can be exported for password resetting;

⚫Multiple connected analog cameras supporting Turbo HD or AHD signal can be upgraded

simultaneously via DVR.

Network Functions

⚫1 self-adaptive 10M/100M/1000M network interface or 1 self-adaptive

10M/100Mbps network interface provided;

⚫IPv6 is supported;

⚫TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™ and HTTPS are

supported;

Supports access by Cloud P2P;

⚫TCP, UDP and RTP for unicast;

⚫Auto/Manual port mapping by UPnPTM;

⚫Remote search, playback, download, locking and unlocking the record files, and downloading

files broken transfer resume;

⚫Remote parameters setup; remote import/export of device parameters;

⚫Remote viewing of the device status, system logs and alarm status;

⚫Remote keyboard operation;

⚫Remote HDD formatting and program upgrading;

⚫Remote system restart and shutdown;

⚫Supports upgrading via remote FTP server;

⚫RS-485 transparent channel transmission;

⚫Alarm and exception information can be sent to the remote host;

⚫Remotely start/stop recording;

⚫Remotely start/stop alarm output;

TBK-DVR1100 Digital Video Recorder User Manual

www.tbkvision.com 10

⚫Remote PTZ control;

⚫Remote JPEG capture;

⚫Two-way audio and voice broadcasting;

⚫Output bandwidth limit configurable;

⚫Embedded WEB server;

⚫if DHCP is enabled, you can enable DNS DHCP or disable it and edit the Preferred DNS Server and

Alternate DNS Server.

Development Scalability

⚫SDK for Windows and Linux system;

⚫Source code of application software for demo;

⚫Development support and training for application system.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali TBK vision Registratore digitale

TBK vision

TBK vision TBK-NVR2100 Series Manuale utente

TBK vision

TBK vision NEO 4 Manuale utente

TBK vision

TBK vision TBK-DVR1200 Series Manuale utente

TBK vision

TBK vision TBK-DVR1104 Manuale utente

TBK vision

TBK vision 7000 SERIES Manuale utente

TBK vision

TBK vision NVR5004 Manuale utente

TBK vision

TBK vision NVR5016P8 Manuale utente

Manuali Registratore digitale popolari di altre marche

FLIR

FLIR M3100E Series Manuale utente

VTRACKPRO

VTRACKPRO FPRO300 Manuale utente

Swann

Swann NVR-7085 models Manuale utente

XtendLan

XtendLan DVR-1670C Manuale utente

urmet domus

urmet domus 1093/004AHD Manuale utente

Holux

Holux M1 Manuale utente

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuale utente

Whistler

Whistler D16VRS Manuale utente

Defender Security

Defender Security 82-20235 Manuale utente

MISUMI

MISUMI MP-WF100M Manuale utente

Speco

Speco D8HU Manuale utente

UST

UST DDR-E04AA Istruzioni per l’uso

Consolidated

Consolidated Digital Video Recorder Manuale utente

Mace

Mace DVR0404RW Guida rapida

RCA

RCA RTD315W Manuale utente

FSM

FSM Colibri Grande PRO Manuale utente

Hauppauge

Hauppauge HD PVR 2 Manuale utente

Identivision

Identivision ICR-PH161i PIONEER Manuale utente
